400 Vehicle Care
Locate the notch on the
sheet metal weld flange.
Place the center of the
jack lift head on the center
of the sheet metal notch.
The jack must not be used
in any other position.
{Warning
Getting under a vehicle
when it is lifted on a jack is
dangerous. If the vehicle
slips off the jack, you could
be badly injured or killed.(Continued)
Warning (Continued)
Never get under a vehicle
when it is supported only by
a jack.
{Warning
Raising the vehicle with the
jack improperly positioned
can damage the vehicle and
even make the vehicle fall.
To help avoid personal injury
and vehicle damage, be sure
to fit the jack lift head into
the proper location before
raising the vehicle.
{Warning
Lifting a vehicle and getting
under it to do maintenance
or repairs is dangerous
without the appropriate
safety equipment and
training. If a jack is provided
with the vehicle, it is(Continued)
Warning (Continued)
designed only for changing a
flat tire. If it is used for
anything else, you or others
could be badly injured or
killed if the vehicle slips off
the jack. If a jack is provided
with the vehicle, only use it
for changing a flat tire.
Caution
Using a jack to raise the
vehicle without positioning it
correctly could damage your
vehicle. When raising your
vehicle on a jack, be sure to
position it correctly under
the frame and avoid contact
with the plastic molding.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 401
5. Turn the wheel wrenchclockwise to raise the jack
until the slot in the jack lift
head fits into the metal
flange located behind the
cut out on the plastic
molding.
Do not raise the
vehicle yet.
6. Put the compact spare tire near you.
7. Raise the vehicle by turning the jack handle
clockwise. Raise the
vehicle far enough off the ground so there is enough
room for the road tire to
clear the ground.
8. Remove all of the
wheel nuts.
9. Remove the flat tire.
{Warning
Rust or dirt on a wheel,
or on the parts to which it
is fastened, can cause
wheel nuts to become
loose over time. The
wheel could come off and
(Continued)
Warning (Continued)
cause a crash. When
changing a wheel, remove
any rust or dirt from
places where the wheel
attaches to the vehicle. In
an emergency, a cloth or
paper towel can be used;
however, use a scraper
or wire brush later to
remove all rust or dirt.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
402 Vehicle Care
10. Remove any rust or dirtfrom the wheel bolts,
mounting surfaces, and
spare wheel.
11. Place the compact spare tire on the wheel-mounting
surface.
{Warning
Never use oil or grease on
bolts or nuts because the
nuts might come loose. The
vehicle's wheel could fall off,
causing a crash.
12. Reinstall the wheel nuts. Tighten each nut by hand
until the wheel is held
against the hub.
13. Lower the vehicle by turning the jack handle
counterclockwise.
{Warning
Wheel nuts that are
improperly or incorrectly
tightened can cause the
(Continued)
Warning (Continued)
wheels to become loose or
come off. The wheel nuts
should be tightened with a
torque wrench to the proper
torque specification after
replacing. Follow the torque
specification supplied by the
aftermarket manufacturer
when using accessory
locking wheel nuts. See
Capacities and
Specifications0433 for
original equipment wheel nut
torque specifications.
Caution
Improperly tightened wheel
nuts can lead to brake
pulsation and rotor damage.
To avoid expensive brake
repairs, evenly tighten the
wheel nuts in the proper
sequence and to the proper (Continued)
Caution (Continued)
torque specification. See
Capacities and
Specifications0433 for the
wheel nut torque
specification.
14. Tighten the wheel nuts firmly in a crisscross
sequence, as shown.
15. Lower the jack all the way and remove the jack from
under the vehicle.
16. Tighten the wheel nuts firmly with the wheel
wrench.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 403
When reinstalling the wheel
cover or center cap on the
full-size tire, tighten all five
plastic caps hand snug with
the aid of the wheel wrench
and tighten them with the
wheel wrench an additional
one-quarter of a turn.
Caution
Wheel covers will not fit on
the vehicle's compact spare.
If you try to put a wheel
cover on the compact spare,
the cover or the spare could
be damaged.
Storing a Flat or Spare
Tire and Tools
{Warning
Storing a jack, a tire,
or other equipment in the
passenger compartment of
the vehicle could cause
injury. In a sudden stop or(Continued)
Warning (Continued)
collision, loose equipment
could strike someone. Store
all these in the proper place.
To store the flat or spare tire
and tools: 1. Open the liftgate. See Liftgate 024.
2. Replace the jack and tools in their original storage
location.
3. Lower the load floor.
4. Place the tire, lying flat, in the rear storage
compartment.
5. Place the loop end of the strap through the liftgate
striker.
6. Route the strap throughthe wheel as shown.
7. Attach the hook to the loop end of the strap.
8. Tighten the strap.
9. Replace the cargo cover, if equipped.
10. Close the liftgate and make sure it is fully
latched.
The compact spare is for
temporary use only. Replace
the compact spare tire with a
full-size tire as soon as
you can.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
404 Vehicle Care
Compact Spare Tire
{Warning
Driving with more than one
compact spare tire at a time
could result in loss of
braking and handling. This
could lead to a crash and
you or others could be
injured. Use only one
compact spare tire at a time.
If this vehicle has a compact
spare tire, it was fully inflated
when new; however, it can
lose air over time. Check the
inflation pressure regularly.
It should be 420 kPa (60 psi).
Stop as soon as possible and
check that the spare tire is
correctly inflated after being
installed on the vehicle. The
compact spare tire is designed
for temporary use only. The
vehicle will perform differently
with the spare tire installed
and it is recommended that
the vehicle speed be limited to
80 km/h (50 mph). To conserve the tread of the spare tire,
have the standard tire
repaired or replaced as soon
as convenient and return the
spare tire to the storage area.
When using a compact spare
tire, the AWD (if equipped),
ABS, and Traction Control
systems may engage until the
spare tire is recognized by the
vehicle, especially on slippery
roads. Adjust driving to reduce
possible wheel slip.
Caution
When the compact spare is
installed, do not take the
vehicle through an
automatic car wash with
guide rails. The compact
spare can get caught on the
rails which can damage the
tire, wheel, and other parts
of the vehicle.
Do not use the compact spare
on other vehicles. Do not mix the compact spare
tire or wheel with other
wheels or tires. They will not
fit. Keep the spare tire and its
wheel together.
Caution
Tire chains will not fit the
compact spare. Using them
can damage the vehicle and
the chains. Do not use tire
chains on the compact
spare.
Jump Starting
Jump Starting - North
America
For more information about
the vehicle battery, see
Battery - North America
0346.
If the battery has run down,
try to use another vehicle and
some jumper cables to start
your vehicle. Be sure to use
the following steps to do it
safely.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 405
{Warning
WARNING:Battery posts,
terminals and related
accessories can expose you
to chemicals including lead
and lead compounds, which
are known to the State of
California to cause cancer
and birth defects or other
reproductive harm. Wash
hands after handling. For
more information go to
www.P65Warnings.ca.gov.
See California Proposition
65 Warning 01.
{Warning
Batteries can hurt you. They
can be dangerous because:
.They contain acid that can
burn you.
.They contain gas that can
explode or ignite.
.They contain enough
electricity to burn you.
(Continued)
Warning (Continued)
If you do not follow these
steps exactly, some or all of
these things can hurt you.
Caution
Ignoring these steps could
result in costly damage to
the vehicle that would not
be covered by the vehicle
warranty. Trying to start the
vehicle by pushing or pulling
it will not work, and it could
damage the vehicle.
Caution
If the jumper cables are
connected or removed in the
wrong order, electrical
shorting may occur and
damage the vehicle. The
repairs would not be
covered by the vehicle
warranty. Always connect
and remove the jumper
(Continued)
Caution (Continued)
cables in the correct order,
making sure that the cables
do not touch each other or
other metal.
Connection Points and
Sequence
1. Discharged BatteryPositive (+) Terminal
2. Good Battery Positive (+) Terminal
3. Good Battery Negative (−) Terminal

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
406 Vehicle Care
4. Discharged BatteryNegative (−) Terminal
The discharged battery
positive (+) terminal and the
discharged battery negative
(–) terminal are on the driver
side of the vehicle.
The good battery negative (–)
terminal and good battery
positive (+) terminal are on the
battery of the vehicle
providing the jump start.
The discharged battery
positive (+) terminal is under a
cover. Remove the cover to
expose the terminal.
1. Check the other vehicle. It must have a 12-volt
battery with a negative
ground system.
Caution
If the other vehicle does not
have a 12-volt system with a
negative ground, both
vehicles can be damaged.
Only use a vehicle that has a
(Continued)
Caution (Continued)
12-volt system with a
negative ground for jump
starting.
2. Position the two vehicles so that they are not
touching.
3. Set the parking brake firmly and put the
transmission in P (Park).
See Shifting Into Park
0254.
Caution
If any accessories are left on
or plugged in during the
jump starting procedure,
they could be damaged. The
repairs would not be
covered by the vehicle
warranty. Whenever
possible, turn off or unplug
all accessories on either
vehicle when jump starting. 4. Turn the ignition off. Turn
off all lights and
accessories in both
vehicles, except the hazard
warning flashers if needed.
{Warning
An electric fan can start up
even when the engine is not
running and can injure you.
Keep hands, clothing, and
tools away from any
underhood electric fan.
{Warning
Using a match near a
battery can cause battery
gas to explode. People have
been hurt doing this, and
some have been blinded.
Use a flashlight if you need
more light.
Battery fluid contains acid
that can burn you. Do not
get it on you. If you
accidentally get it in your
(Continued)

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 407
Warning (Continued)
eyes or on your skin, flush
the place with water and get
medical help immediately.
{Warning
Fans or other moving engine
parts can injure you badly.
Keep your hands away from
moving parts once the
engine is running.
5. Connect one end of the red positive (+) cable to the
discharged battery
positive (+) terminal.
6. Connect the other end of the red positive (+) cable to
the good battery
positive (+) terminal.
7. Connect one end of the black negative (–) cable to
the good battery negative
(–) terminal. 8. Connect the other end of
the black negative (–) cable
to the discharged battery
negative (–) terminal on the
driver side shock tower.
9. Start the engine in the vehicle with the good
battery and run the engine
at idle speed for at least
four minutes.
10. Try to start the vehicle that had the dead battery.
If it will not start after a
few tries, it probably needs
service.
Jumper Cable Removal
Reverse the sequence exactly
when removing the jumper
cables.
After starting the disabled
vehicle and removing the
jumper cables, allow it to idle
for several minutes.
Towing the
Vehicle
Transporting a
Disabled Vehicle
Caution
Incorrectly transporting a
disabled vehicle may cause
damage to the vehicle. Use
proper tire straps to secure
the vehicle to the flatbed
tow truck. Do not strap or
hook to any frame,
underbody, or suspension
component not specified
below. Do not move vehicles
with drive axle tires on the
ground. Damage is not
covered by the vehicle
warranty.
Caution
The vehicle may be equipped
with an electric parking
brake and/or an electronic (Continued)
