2021 HYUNDAI VENUE Owners Manual

Page 217 of 392

HYUNDAI VENUE 2021  Owners Manual 06
6-29
SPORT mode
SPORT mode manages
the driving dynamics by
automatically adjusting
the steering effort, and the
engine and transmission
control logic for enhanced
driving performance.
[�Whe

Page 218 of 392

HYUNDAI VENUE 2021  Owners Manual While Driving
6-30
LCD Display Message
Transmission hot! Park with engine
On
OJS058137L
OJS058138L
[�Under certain conditions, such as
harsh driving conditions (mud or sand
road), the transmissio

Page 219 of 392

HYUNDAI VENUE 2021  Owners Manual 06
6-31
System Description
Blind-Spot Collision Warning
Blind-Spot Collision Warning (BCW)
system uses radar sensors in the rear
bumper to monitor and warn the driver
of an approaching vehicle in t

Page 220 of 392

HYUNDAI VENUE 2021  Owners Manual While Driving
6-32
System Setting
OTMA058088MX
[�Setting Blind-Spot Safety function
The driver can activate the system
by placing the ignition switch to the
ON position and by selecting User
�6�

Page 221 of 392

HYUNDAI VENUE 2021  Owners Manual 06
6-33
Warning and System Control
Blind-Spot Collision Warning system
��„Left side
OQX069036L
��„Right side
OQX069008L
First stage alert
If a vehicle is detected within the
boundary of the sys

Page 222 of 392

HYUNDAI VENUE 2021  Owners Manual While Driving
6-34
 WARNING
[�The warning light on the outer side
view mirror will illuminate whenever
a vehicle is detected at the rear side
by the system.
To avoid accidents, do not focus only

Page 223 of 392

HYUNDAI VENUE 2021  Owners Manual 06
6-35
Warning message
OIK057092L
Blind-Spot Collision Warning system
disabled. Radar blocked
This warning message may appear when:
  - One or both of the sensors on the rear
bumper is blocked by d

Page 224 of 392

HYUNDAI VENUE 2021  Owners Manual While Driving
6-36
Limitations of the System
The driver must be cautious in the below
situations because the system may not
detect other vehicles or objects in certain
circumstances:
[�The vehicl
