40 Navigation
7. Save the file with the extension.csv. For example:
myplacesfile.csv.
The name of the .csv file will
be used to create a My Points
of Interest category in the
system. Create separate .csv
files with different names to
create other My Points of
Interest categories.
8. Make sure to select the USB mass storage device as the
location to save, using the
exact folder name “/myPOIs”
for the User POIs or “/myPOIs/
myPOIwarnings.”
For POI-warnings, if the USB
mass storage device’s root
folder is represented by f:/,
save the file to the folder “f:/my
POIs” for User POIs or the
folder “f:/myPOIs/
myPOIwarnings.”
9. For POI-warnings, connect the USB mass storage device to
the vehicle’ s USB port. Adding User-Defined Points of
Interest (POIs)
To add your User POIs to the
system:
1. Press NAV on the center stack.
2. Touch Next Page.
3. Touch My Points of Interest.
4. If a USB mass storage device with the new POI data is
connected, the system will
automatically ask if you want to
transfer the POI data. Touch
Download to begin the transfer
or Cancel to cancel the
procedure.
New POI data will overwrite
POI data already in the internal
memory. 5. The POI data on the USB
mass storage device is
transferred to the vehicle.
A maximum of 8 MB of POI
data can be added to the
system.
6. Once the download process is complete, the available POIs
are showing in a list on the
display.
7. Touch the name of a POI on the list to set it as the
destination.
8. Touch Start to calculate the route.
A user-defined POI in the My Points
of Interest database can also be set
as the destination: 1. Press NAV on the center stack.
2. Touch Next Page.
3. Touch My Points of Interest.
4. Touch the name of the user-defined POI to set that
entry as a destination.

Chevrolet City Express Infotainment System (GMNA-Localizing-U.S./Canada-
11683801) - 2018 - crc - 7/12/17
Navigation 41
Deleting User-Defined Points of
Interest (POIs)
To delete the user-defined POIs
stored in the My Points of Interest
memory:1. Press APPS
hor MENU on
the center stack.
2. Touch Settings.
3. Touch Navigation.
4. Touch My Points of Interest Settings.
5. Touch Remove User POI From System.
6. A pop-up is displayed to confirm deletion of all User
POIs (My Points of Interest)
from the system. Touch Yes to
delete the User POIs or No to
cancel.
Other options are available on the
My Points of Interest Settings
display:
. My Points of Interest Alert
Select to adjust how alerts are
provided when approaching a
destination set by My Points of
Interest. Choose OFF to disable
the alert. Choose Show Only to
show the alert on the display.
Choose Show & Beep to show
the alert on the display and play
an audible sound.
. Points of Interest Alert Distance Select a distance away from the
My Points of Interest destination
at which the alert will activate.
Setting a Destination from the
Address Book
This option allows you to set and
store the destination in the address
book and use the stored
destinations to calculate a route.
Adding a New Entry to the
Address Book
1. Press NAV on the center stack.
2. Touch Next Page.
3. Touch Address Book.
4. Touch Add New Entry.

Chevrolet City Express Infotainment System (GMNA-Localizing-U.S./Canada-
11683801) - 2018 - crc - 7/12/17
42 Navigation
Up to 50 address book entries can
be stored. If the number exceeds
50, one entry must be deleted
before the new one can be added.
There are four possibilities shown:
.Street Address
Allows saving a new entry by
selecting the address.
. Previous Destination
Allows saving a destination in
the address book from a location
stored in the previous
destination memory.
Touch the destination desired to
save into the address book.
The touch keyboard gives the
option to change the name of
the selected destination.
Touch OK. The system confirms
the entry and adds it to the
address book.
. Current Destination Allows storing the currently set
destination in the address book
when a route is active. This
option is only available when a
route is active.
Touch Current Destination.
The touch keyboard gives the
option to change the name of
the destination.
Touch OK. The system confirms
the entry and adds it to the
address book.
. Current Position
Allows the setting of the current
position as a destination in the
address book.
Touch Current Position.
The touch keyboard gives the
option to change the name of
the destination.
Touch OK. The system confirms
the entry and adds it to the
address book. Setting an Entry as a Destination
Instead of touching Add New Entry,
touch any previously saved
address.
The detailed description of the entry
is shown. If information for the
destination is not available, latitude
and longitude coordinates will be
shown.
The entry can be renamed or
deleted. Touch OK to set the entry
as a destination.
The system will calculate the route
to the address chosen.
Setting a Destination from the
Address Book Using Voice
Recognition
Entries in the address book can be
set as destinations using the voice
recognition system.
1. Press
Von the center stack or
press
g/Von the steering
wheel. The system provides
prompts and waits for voice
commands.
2. Say “Navigation.”

Chevrolet City Express Infotainment System (GMNA-Localizing-U.S./Canada-
11683801) - 2018 - crc - 7/12/17
Navigation 43
3. Say“Address Book.”
4. Say the number of the entry in the address book showing on
the display.
If a route is active, say “Replace
Destination” to replace the current
destination with the address book
entry or say “Set as Waypoint” to
set the address book entry as a
waypoint on the current route.
If a route is not set, route guidance
is calculated to the address book
entry.
Say “Show Route on Map” to
display the location of the address
book entry on the map.
Setting an Intersection as a
Destination
An intersection of two streets can be
set as a destination. To set an
intersection as the destination:
1. Press NAV on the center stack.
2. Touch Next Page.
3. Touch Intersection.
4. Touch Change State or Province if the state or
province displayed is not
correct.
5. If necessary, enter the name of the state or province.
The display shows the touch
keyboard.
6. Touch List at any time and a list of remaining cities will be
shown. Touch the desired city.
7. Touch Street. The display shows the touch keyboard.
8. Touch the name of the desired street. 9. A list of intersecting streets will
be shown if six or fewer exist.
Otherwise, the touch keyboard
will be displayed again so that
the name of the second street
in the intersection can be
entered. Enter the second
street name.
10. Select the intersecting street.
11. Touch Start. The route to the intersection will be calculated.
Setting a City Center as a
Destination
The center of a city can be set as a
destination. To set a City Center as
a destination:
1. Press NAV on the center stack.
2. Touch Next Page.

Chevrolet City Express Infotainment System (GMNA-Localizing-U.S./Canada-
11683801) - 2018 - crc - 7/12/17
44 Navigation
3. Touch City Center.
4. If the state shown is notcorrect, touch Change State or
Province. Otherwise, proceed
to Step 7.
5. Enter the name of the state or province. The display shows
the touch keyboard.
The keyboard has an intelligent
spelling setting, so it excludes
non-existing combinations. On
the top right of the display, the
number of matches is shown.
6. Touch City.
7. Enter the name of the first street. The display shows the
touch keyboard. 8. Touch Start to calculate the
route to the City Center.
Traffic Feature
The navigation system receives
traffic information from SiriusXM
Traffic to inform of traffic events and
guide to an alternate route. Traffic
events include accidents, road
construction, heavy traffic, and other
factors that affect the route ahead.
Displaying Traffic Events Along
Route
When a route is active, press
APPS
hon the center stack and
then touch SiriusXM Traffic to
display the traffic event nearest the
current vehicle location. The
location and nature of the traffic event is displayed. There are
several menu options available on
the display.
This feature can also be accessed
using the voice recognition system
by pressing
Von the center stack
or
g/Von the steering wheel and
when prompted, saying
”Information” then“Traffic.”
. Avoid Road On Route
Touch Avoid On Route to direct
the navigation system to avoid
the area impacted by the listed
traffic event. The next display
lists multiple options.
Touch Detour by Distance to
avoid the road listed on the
traffic event. The distance can
be chosen over which the
system avoids the affected road.
Touch + or −to set the distance
and then touch Recalculate
Route to calculate the new
route.
Touch Avoid Segment of Route
List to avoid a series of roads on
the route list due to the traffic

Chevrolet City Express Infotainment System (GMNA-Localizing-U.S./Canada-
11683801) - 2018 - crc - 7/12/17
Navigation 45
event. The route list is displayed.
Touch the names of two streets
on the list to avoid that portion of
the route and then touch
Recalculate Route to calculate
the new route.
. List All Traffic Events
Touch List All Traffic Events to
display a list of all traffic events
in the area, including those that
are not directly along the current
route. Touch the line of a specific
event on the display to see more
details about that item.
Traffic Flow Feature
Using information received from
SiriusXM Traffic, the system informs
of traffic levels on certain highways
and roads in the area along the
route. When a route is active, touch
MAP to display the map of the
current vehicle location. Any roads
with traffic flow information will
appear colored as follows:
. Green: traffic is light and moving
at normal speeds >72 km
(>45 mph). .
Yellow: traffic is heavy and
moving slowly 16-72 km
(10-45 mph).
. Red: traffic is grid-locked and
not moving <16 km (<10 mph).
Traffic Settings
To access the settings for the traffic
feature:
1. Press APPS
hor MENU on
the center stack.
2. Touch Settings.
3. Touch Traffic. The following settings can be
adjusted:
.
Dynamic Guidance: Touch to
view all reported traffic events
while on or off a planned route.
. Show Traffic Incidents: Touch to
view traffic events while on a
planned route.
. Show Traffic Flow: Touch to view
traffic flow information while on a
planned route.
. Announce Traffic Alerts: Touch
to turn traffic alert
announcements On or Off.
Weather Feature
NavWeatherXM information is a
subscription service offered by
SiriusXM Satellite Radio.
This service provides real-time
information regarding current
weather and forecasts where
available. The weather information
is broadcast to the vehicle by the
SiriusXM satellites.

Chevrolet City Express Infotainment System (GMNA-Localizing-U.S./Canada-
11683801) - 2018 - crc - 7/12/17
46 Navigation
{Warning
NavWeatherXM information is not
a substitute for attentive driving.
Weather conditions change
constantly and emergency
situations can arise without
warning. Relying only on
NavWeatherXM information could
result in serious personal injury.
NavWeatherXM information is
available in limited markets. To
subscribe or check if this service is
available in the area, call
1-888-601-6296 or see
www.siriusxm.com/navweather.
Displaying Weather Information 1. Press APPS
hor MENU on
the center stack.
2. Touch SiriusXM Travel Link.
3. Touch Weather.
The weather conditions for the
current location are displayed.
In some areas, the location name at
the top of the display may not match
the location shown for the Weather
Station due to differences in where
weather information is collected. Touch Forecast to see the weather
forecast for the selected area for the
next five days.
Touch Location to view weather
information for a different location.
.
Near Current Location
Select to view weather
information for the current
location.
. Near Destination
Select to view weather
information near the destination
of the current route. Route
guidance must be active for this
option to be available.

Chevrolet City Express Infotainment System (GMNA-Localizing-U.S./Canada-
11683801) - 2018 - crc - 7/12/17
Navigation 47
.In Another City
Select to view weather
information for a different city.
Follow the on-screen prompts
and character input display to
select the desired location.
When the weather function is
accessed for the first time of the
day, the GPS location may not be
used. If this occurs, touch Location
to update the location.
This feature can also be accessed
using the voice recognition system.
Press
g/Von the steering wheel
and when prompted, say
“Information” then“Current Weather”
or “Weather Forecast.”
Fuel Pricing
To display fuel prices at gas stations
in the surrounding area on the
display:
1. Press APPS
hor MENU on
the center stack.
2. Touch SiriusXM Travel Link.
3. Touch Fuel Prices. This feature can also be
accessed using voice
recognition. Press
g/Von the
steering wheel. When
prompted, say “Information”
then “Fuel Prices.”
4. A list of gas stations is displayed with the distance and
direction to each entry. Touch
any entry on the display to
view information about that gas
station. 5. The name, address, and phone
number of the gas station are
displayed. If available, the
prices for each grade of
gasoline are also displayed.
.Touch Store to store the
location in the
address book.
. Touch Call to call the
location using the Bluetooth
Hands-Free Phone System.
. Touch Map to view the
location on the map.
. Touch Start to begin route
guidance to the location.
SiriusXM Travel Link Movie
Listings
When SiriusXM Travel Link
information is available the movie
feature provides movie show time
and theater information for movies
close to the vehicle location. The
Movie feature provides detailed
theater and movie information
including showtimes.
