3. Release header latches from the windshield frame. 4. Release the sail panel retainers from the body sidechannel at the rear corners of the vehicle.
NOTE: When releasing the sail panel retainers, it is helpful
to pull down on the rear roof bow.
Step Three
Step Four
3
GETTING TO KNOW YOUR VEHICLE 135

5. Fold the sail panels so that they rest on top of the softtop. 6. Fold header rearward, pulling the fabric to the rear.
Step Five
Step Six
136 GETTING TO KNOW YOUR VEHICLE

7. Release Sunrider latch (both sides).
Step SixStep Seven
3
GETTING TO KNOW YOUR VEHICLE 137

8. Open the swing gate and lower the top.
NOTE:Ensure the fabric does not overhang the sides of the
vehicle.Quick Steps For Raising The Soft Top
1. Open the swing gate and raise the top, engaging the Sunrider latches (another person may be needed to help
with this operation).
Step Eight
Step One
138 GETTING TO KNOW YOUR VEHICLE

2. Install rear corner panels.
Step One
Step Two
3
GETTING TO KNOW YOUR VEHICLE 139

3. Rotate the header forward.4. Engage the header latches.
Step ThreeStep Four
140 GETTING TO KNOW YOUR VEHICLE

5. Install the back window.6. Install the side windows.
Step FiveStep Six
3
GETTING TO KNOW YOUR VEHICLE 141

7. To install the side windows, affix the window tempo-rarily by attaching to the Velcro in the rear corner. Start
the zipper but close only about 1 in (2.5 cm). 8. Insert the front retainer of the window into the door
channel, making sure the retainer is fully seated and
properly positioned on the door frame. Failure to do so
can result in wind and water leaks or damage to the
window.
Step Seven
Retainer Insertion
1 — Incorrect Insertion
2 — Correct Insertion
