2017 JEEP WRANGLER Owners Manual

GETTING TO KNOW YOUR VEHICLE
CONTENTS
KEY FOBS .............................19
▫ KeyFob..............................19
 IGNITION SWITCH .......................21
▫ Ignition Key Removal ....................21

REMOTE STARTING SYSTEM — IF EQUIPPED ....22
▫Remote Start Abort Message ...............22
▫ To Enter Remote Start ....................23
▫ To Exit Remote Start Mode Without Driving
The Vehicle ............................23
▫ To Exit Remote Start Mode And Drive
The Vehicle ............................24
▫ General Information .....................24
 SENTRY KEY ...........................24
▫ Replacement Key Fobs ...................25
▫ Customer Key Programming ...............25▫
General Information .....................26

VEHICLE SECURITY ALARM — IF EQUIPPED ....26
▫Rearming The System ....................27
▫ To Arm The System .....................27
▫ To Disarm The System ...................27
 DOORS ...............................28
▫ Manual Door Locks .....................28
▫ Power Door Locks — If Equipped ...........30
▫ Child-Protection Door Lock System —
Rear Doors ............................31
▫ Upper Half Door Window Removal —
If Equipped ............................32
▫ Front Door Removal .....................32
▫ Rear Door Removal (Four-Door Models) .......34
 SEATS ................................37
3

▫Manual Front Seats ......................37
▫ Manual Rear Seats .......................42
▫ Heated Seats — If Equipped ...............45
 HEAD RESTRAINTS ......................46
▫ Front Head Restraints ....................46
▫ Rear Head Restraints — 2 Door Model ........47
▫ Rear Head Restraints — 4 Door Model ........48
 STEERING WHEEL .......................48
▫ Tilt Steering Column .....................48
 MIRRORS ..............................49
▫ Inside Day/Night Mirror — If Equipped ......49
▫ Automatic Dimming Mirror — If Equipped .....50
▫ Outside Mirrors ........................50
▫ Power Mirrors — If Equipped ..............51
▫ Heated Mirrors — If Equipped .............51
▫ Vanity Mirrors .........................52
 EXTERIOR LIGHTS .......................52 ▫
Headlights And Parking Lights .............52
▫ Daytime Running Lights — If Equipped .......52
▫ High/Low Beam Switch ..................53
▫ Flash-To-Pass ..........................53
▫ Automatic Headlights — If Equipped .........53
▫ Front Fog Lights ........................53
▫ Turn Signals ...........................54
▫ Lane Change Assist — If Equipped ..........54
▫ Lights-On Reminder ......................54
 INTERIOR LIGHTS .......................54
▫ Courtesy/Reading Lights ..................54
▫ Instrument Panel Dimmer .................55
▫ Cargo Lamp ...........................56
 WINDSHIELD WIPERS AND WASHERS ........57
▫ Windshield Wiper Operation ................57
▫ Intermittent Wiper System .................58
▫ Windshield Washers ......................58
16 GETTING TO KNOW YOUR VEHICLE

▫Mist Feature ...........................59
▫ Rear Window Wiper/Washer — If Equipped ....60
 CLIMATE CONTROLS .....................60
▫ Manual Climate Control Overview ...........60
▫ Automatic Climate Control Overview .........64
▫ Operating Tips .........................68
 POWER WINDOWS — IF EQUIPPED ..........71
▫ Wind Buffeting .........................72
 DUAL TOP — TWO-DOOR MODELS —
IF EQUIPPED ...........................72
▫ Removing The Soft Top — Two-Door Models ....72
▫ Installing The Soft Top — Two-Door Models ....74
 DUAL TOP — FOUR-DOOR MODELS —
IF EQUIPPED ...........................76
▫ Removing The Soft Top — Four-Door Models . . .77
▫ Installing The Soft Top — Four-Door Models ....80
 FREEDOM TOP THREE-PIECE MODULAR
HARD TOP — IF EQUIPPED ................83 ▫
Front Panel(s) Removal ...................84
▫ Freedom Top Storage Bag ..................86
▫ Front Panel(s) Installation ..................90
▫ Front Panel(s) Installation With Rear Hard
Top Removed ..........................90
▫ Rear Hard Top Removal ..................91
▫ Rear Hard Top Installation .................94
 DOOR FRAME ...........................94
▫ Door Frame Removal .....................95
▫ Door Frame Installation —
Two-Door Models — If Equipped ............96
▫ Door Frame Installation —
Four-Door Models — If Equipped ...........98
 SOFT TOP — TWO-DOOR MODELS ..........100
▫ Quick Steps To Lowering The Soft Top ........102
▫ Quick Steps To Raising The Soft Top .........106
▫ Lowering The Soft Top ...................111
▫ Raising The Soft Top ....................120
3
GETTING TO KNOW YOUR VEHICLE 17

SUNRIDER (TWO-DOOR MODELS) —
IF EQUIPPED ......................... .129
▫ Opening The Sunrider ...................129
▫ Closing The Sunrider ....................131
 SOFT TOP — FOUR-DOOR MODELS .........131
▫ Quick Steps For Lowering The Soft Top .......134
▫ Quick Steps For Raising The Soft Top .........138
▫ Folding Down The Soft Top ...............144
▫ Putting Up The Soft Top ..................154
 SUNRIDER (FOUR-DOOR MODELS) —
IF EQUIPPED ......................... .163
▫ Opening The Sunrider ...................163
▫ Closing The Sunrider ....................166
 FOLDING WINDSHIELD ..................166 ▫
Lowering The Windshield And Removing
Side Bars ............................ .167
▫ Raising The Windshield And Replacing
Side Bars ............................ .170
 HOOD .............................. .171
▫ Opening The Hood .....................171
▫ Closing The Hood ..................... .172
 REAR SWING GATE .....................172
 INTERNAL EQUIPMENT ..................173
▫ Storage ............................. .173
▫ Cupholders .......................... .175
▫ Electrical Power Outlets ..................176
▫ Power Inverter — If Equipped .............178
18 GETTING TO KNOW YOUR VEHICLE

KEY FOBS
Your vehicle uses a key start ignition system. The ignition
system consists of a Remote Keyless Entry (RKE) key fob
with an ignition switch.
Key Fob
The key fob allows you to lock or unlock the doors and
liftgate from distances up to approximately 66 ft (20 m)
using a handheld key fob. The key fob does not need to be
pointed at the vehicle to activate the system.
NOTE:In the ON/RUN position, the lock button is dis-
abled. Only the unlock button is enabled.
To Unlock The Doors And Swing Gate
Push and release the key fob unlock button once to unlock
the driver’s door only, or twice to unlock all the doors and
swing gate. When the key fob unlock button is pushed, the
Illuminated Entry will initiate, and the turn signal lights
will flash twice.
To Lock The Doors And Swing Gate
Push and release the lock button on the key fob to lock all
doors. The turn signals will flash, and the horn will chirp
once to acknowledge the lock signal.
Key Fob
3
GETTING TO KNOW YOUR VEHICLE 19

Key Fob Battery Replacement
The recommended replacement battery is CR2032.
NOTE:Perchlorate Material – special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
1. With the key fob buttons facing down, use a flat blade screwdriver to pry the two halves of the key fob apart.
Use extreme care not to damage the seal or internal
components. 2. Remove and replace the battery. Avoid touching the new
battery with your fingers. Skin oils may cause battery
deterioration. If you touch a battery, clean it with
rubbing alcohol.
3. To reassemble the key fob case, snap the two halves together.
Programming Additional Key Fobs
Refer to “Sentry Key” in “Getting To Know Your Vehicle”
for further information.
If you do not have a programmed key fob, contact your
authorized dealer for details.
General Information
The following regulatory statement applies to all Radio
Frequency (RF) devices equipped in this vehicle:
This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, in-cluding interference that may cause undesired opera-
tion.
Separating Key Fob Halves
20 GETTING TO KNOW YOUR VEHICLE

NOTE:Changes or modifications not expressly approved
by the party responsible for compliance could void the
user ’s authority to operate the equipment.
IGNITION SWITCH
Ignition Key Removal
1. Place the gear selector in PARK (if equipped with an automatic transmission).
2. Turn the ignition switch to the ACC (Accessory) posi- tion.
3. Push the key and cylinder inward and rotate the key to the LOCK position.
4. Remove the key from the ignition switch lock cylinder.
Ignition Switch Positions
1 — LOCK
2 — ACC (ACCESSORY)
3 — ON/RUN
4 — START
3
GETTING TO KNOW YOUR VEHICLE 21

WARNING!
•Before exiting a vehicle, always shift the automatic
transmission into PARK or the manual transmission
into FIRST gear or REVERSE, apply the parking brake,
turn the engine OFF, remove the key fob from the
vehicle and lock your vehicle.
• Never leave children alone in a vehicle, or with
access to an unlocked vehicle.
• Allowing children to be in a vehicle unattended is
dangerous for a number of reasons. A child or others
could be seriously or fatally injured. Children
should be warned not to touch the parking brake,
brake pedal or the gear selector.
• Do not leave the key fob in or near the vehicle, or in
a location accessible to children. A child could oper-
ate power windows, other controls, or move the
vehicle.
• Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build-up may
cause serious injury or death.
CAUTION!
An unlocked vehicle is an invitation for thieves. Al-
ways remove key fob from the vehicle and lock all
doors when leaving the vehicle unattended.
REMOTE STARTING SYSTEM — IF EQUIPPED
This system uses the key fob to start the engine conve-
niently from outside the vehicle while still maintaining
security. The system has a range of approximately 300 ft (91
m).
NOTE:
• The vehicle must be equipped with an automatic trans-
mission to be equipped with Remote Start.
• Obstructions between the vehicle and key fob may
reduce this range.
Remote Start Abort Message
The following messages will display in the instrument
cluster display if the vehicle fails to remote start or exits
remote start prematurely:
• Remote Start Aborted — Door Open
22 GETTING TO KNOW YOUR VEHICLE
