2. Remove the back window.3. Release header latches from the windshield frame.
Step TwoStep Three
3
GETTING TO KNOW YOUR VEHICLE 103

4. Release the sail panel retainers from the body sidechannel at the rear corners of the vehicle.
NOTE: When releasing the sail panel retainers, it is helpful
to pull down on the rear roof bow. 5. Make sure the plastic sleeves are slid rearward over the
Sunrider link to lock in the link (Sunrider Models only).
Step FourStep Five
104 GETTING TO KNOW YOUR VEHICLE

6. As you begin to lower the top, fold the sail panels so thatthey rest on top of the soft top. 7. Release the Sunrider latch (both sides).
Step Six
Step Seven
3
GETTING TO KNOW YOUR VEHICLE 105

8. Open the swing gate and lower the top.
NOTE:Ensure fabric does not overhang the sides of the
vehicle.Quick Steps To Raising The Soft Top
Refer to “Raising The Soft Top” in this section for further
information.
1. Open the swing gate and raise the top, engaging the Sunrider latches (another person may be needed to help
with this operation).
Step Eight
Step One
106 GETTING TO KNOW YOUR VEHICLE

2. Engage header latches.
Step One
Step Two
3
GETTING TO KNOW YOUR VEHICLE 107

3. Install rear corner panels.4. Install the back window.
Step ThreeStep Four
108 GETTING TO KNOW YOUR VEHICLE

5. Install the side windows.
6. To install the side windows, affix the window tempo-rarily by attaching to the Velcro in the rear corner. Start
the zipper but close only about 1 inch (2.5 cm). 7. Insert the front retainer of the window into the door
channel, making sure the retainer is fully seated and
properly positioned on the door frame. Failure to do so
can result in wind and water leaks or damage to the
window.
Step SixStep Seven
3
GETTING TO KNOW YOUR VEHICLE 109

8. Insert the retainer along the bottom edge of the windowinto the bottom side channel, beginning at the front and
working to the rear of the vehicle. Finish by closing the
zipper completely and attaching the Velcro along the top
and rear of the window. Repeat this step for the opposite
side.
Retainer Insertion
1 — Incorrect Insertion
2 — Correct Insertion
Step Eight
