2017 CHRYSLER PACIFICA Owners Manual

Pushing the center button will make the radio switch
between the various modes available (AM/FM/SXM/
AUX, etc.).
The left-hand control is a rocker-type switch with a
push-button in the center. The function of the left-hand
control is different depending on which mode you are in.
The following describes the left-hand control operation in
each mode.
Radio Operation
Pushing the top of the switch will “Seek” up for the next
listenable station and pushing the bottom of the switch
will “Seek” down for the next listenable station.
The button located in the center of the left-hand control
will tune to the next preset station that you have pro-
grammed in the radio preset button.
AUX/USB/MP3 CONTROL
There are numerous USB ports located throughout the
vehicle. This feature allows an external USB device to be
plugged into the USB port.
For further information, refer to the Uconnect Supple-
ment Manual.
10
MULTIMEDIA 743

There are multiple USB “charge only” ports in this
vehicle.•
In the center console
• On the back of the front row seats in the Uconnect
Theater Media hubs
• Above the rear cup holders in the third row of seats
Front Center Stack AUX Jack And USB Ports
1 — USB Port
2 — Aux Jack
3 — Uconnect Theater USB Port
Center Console USB Charging Port
744 MULTIMEDIA

NOTE:The USB “Charge Only” ports will recharge
battery operated USB devices when connected.
UCONNECT THEATER — IF EQUIPPED
Your Uconnect Theater is designed to give your family
years of enjoyment.
There are multiple ways to interact with your Uconnect
Theater system.
• Play your favorite CDs, DVDs or Blu-ray Discs
• Plug and play a variety of standard video games or
devices into the HDMI port
• Listen to audio over the wireless headphones
• Plug and play a variety of devices into the Video USB
port
• Plug in standard headphones to listen to audio
Please review this Owner’s Manual to become familiar
with its features and operation.
Rear USB Charging Ports
10
MULTIMEDIA 745

Getting StartedThere are three different ways to operate the features of
the Uconnect Theater:
•The Remote Control
• The Touchscreen Radio
• The Individual Video Screens
Uconnect Theater Screen
1 — Uconnect Theater Touchscreen
2 — Uconnect Radio
3 — Uconnect Theater Media Hub 746 MULTIMEDIA

Accessing The System From The Uconnect RadioYou can access your Uconnect Theater system from the
radio touchscreen following the steps below:
1. Press the “Media” button.
2. Press the “Uconnect Theater” button icon.
NOTE:The Uconnect Theater icon may be dragged and
dropped down to the personalized menu bar to create an
App/shortcut. Refer to “Personalized Menu Bar” in this
section for more information.
Uconnect Theater Button
10
MULTIMEDIA 747

Uconnect Theater ControlsParents can control certain features of the system with the
“Uconnect Theater Controls” screens, right from the
Uconnect touchscreen radio. Options are:
•Change media sources
• Lock one or both screens
• Mute an individual screen or both screens
• Turn On/Off one or both screens
• Select APPS
• View media while gear selector is in Park
Uconnect Theater Controls Screen
1 — Power All
2 — Mute All
3 — Lock All
4 — Source Drop Down List5—Lock On/Off current screen6 — Mute On/Off current
screen
7 — Power On/Off current
screen
748 MULTIMEDIA

Press this button and use the “Listen In” feature to listen
to audio through cabin speakers.
Accessing The System From The Uconnect
Theater Rear Screens
You can also access your Uconnect Theater system from
the rear screens from the steps below:
1. Lift screen upward, the system will automaticallypower on.
NOTE: A message asking if you would like to pair a
remote will pop up if one has not already been paired to
the system.
2. If “YES” is selected to Pair a Remote, Pairing will immediately start.
3. If “NO” is selected, the Uconnect Theater home screen will pop up.
Listen In
10
MULTIMEDIA 749

NOTE:
•There will be a touchscreen notification message when
pairing is successful. Repeat the above steps to pair the
second remote.
• If remote is ever non-operational, try pairing remote.
When watching a video source, pushing “Settings”
icon on the touchscreen activates the Settings
menu. These settings control the appearance of the
video on the screen. The factory default settings are
already set for optimum viewing, so there is no need
to change these settings under normal circumstances.
To change the settings, use one of the touchscreens. To
reset all values back to the original settings, select the
“Reset to Defaults” then select “YES.”
Pairing The Remote
If the remote needs to be paired to your Uconnect Theater
system, follow the procedure below:
1. Press the “Settings”
icon on the touchscreen.
Remote Pairing
750 MULTIMEDIA
