2017 CHRYSLER PACIFICA Owners Manual

Front And Rear Side Marker Lamps
1. Remove the three fasteners from the inner wheel linerand carefully peel back liner for access. 2. Firmly grasp the front side marker lamp socket and
rotate 1/4 turn counterclockwise to remove it from the
lamp assembly.
3. Remove bulb from the front side marker lamp socket and replace with a new bulb.
Inner Wheel Liner FastenersFront Side Marker Lamp Bulb Removal
7
IN CASE OF EMERGENCY 543

4. Install front side marker lamp socket in lamp assemblyand rotate 1/4 turn clockwise to lock into place.
5. Position the inner wheel liner in place and install the three fasteners.
Front Fog Lamp — Halogen
1. Remove fasteners from inner wheel liner and carefullypeel back liner for access.
2. Reach through the front fascia to fog lamp housing to access the bulb.
3. Rotate the front fog lamp socket counterclockwise, and remove the bulb and socket assembly from the
front fog lamp housing. 4. Pull the bulb out of the socket and insert the replace-
ment bulb.
Front Fog Lamp Socket
544 IN CASE OF EMERGENCY

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean the
bulb with rubbing alcohol.
5. Install the front fog lamp socket assembly into the into the front fog lamp housing, and rotate the connector
clockwise to lock it in place.
6. Position the inner wheel liner in place and install fasteners.
Rear Liftgate Mounted Back-Up Lamps And Tail
Lamps (If Bulb Equipped)
1. Raise the liftgate.
2. Use a fiber stick or flat blade screw driver to pry offthe bulb access cover on the lower liftgate trim. 3. Back-up lamps/tail lamp (if bulb equipped) are now
visible. Rotate socket(s) counter clockwise.
4. Remove/replace bulb(s).
5. Reinstall the socket(s)
6. Reverse process to reinstall the liftgate trim.
Rear Bodyside Mounted Taillamps
1. Raise the liftgate.
2. Remove two torx head screws on bodyside lamp using a T30 screwdriver.
3. Remove lamp from vehicle body and locate bulb socket on rear of lamp. Rotate socket counter-
clockwise.
4. Remove/replace bulb(s).
5. Reinstall the socket(s)
7
IN CASE OF EMERGENCY 545

6. Reverse process to reinstall the lamp onto vehicle.
Center High-Mounted Stop Lamp (CHMSL)
The center high-mounted stop lamp is an LED assembly.
See your authorized dealer for replacement.
Rear License Lamp
The rear license lamps are LED. See your authorized
dealer for replacement.
FUSES
WARNING!
•When replacing a blown fuse, always use an ap-
propriate replacement fuse with the same amp
rating as the original fuse. Never replace a fuse
with another fuse of higher amp rating. Never
(Continued)
WARNING! (Continued)
replace a blown fuse with metal wires or any other
material. Failure to use proper fuses may result in
serious personal injury, fire and/or property dam-
age.
• Before replacing a fuse, make sure that the ignition
is off and that all the other services are switched off
and/or disengaged.
• If the replaced fuse blows again, contact an autho-
rized dealer.
• If a general protection fuse for safety systems (air
bag system, braking system), power unit systems
(engine system, gearbox system) or steering system
blows, contact an authorized dealer.
546 IN CASE OF EMERGENCY

General Information
The fuses protect electrical systems against excessive
current.
When a device does not work you must check the
electrical circuit inside the fuse for a break/melt.
Also please be aware that when using power outlets for
extended periods of time with the engine off may result
in vehicle battery discharge.
Blade Fuses
1 — Electrical Circuit
2 — Blade Fuse With Good Electrical Circuit
3 — Blade Fuse With Bad Electrical Circuit
7
IN CASE OF EMERGENCY 547

Fuse Location
The fuses are grouped into four controllers located in the
engine compartment and under the instrument panel.
Underhood Fuses
The Power Distribution Center is located in the engine
compartment near the battery. This center contains car-
tridge fuses, mini-fuses, micro-fuses, circuit breakers and
relays. A label that identifies each component is printed
on the inside of the cover.
CavityCartridge Fuse Blade FuseDescription
F06 ––Not Used
F07 –25 Amp Clear Ignition Coil/Fuel Injector
F08 ––Not Used
F09 –25 Amp Clear Amplifier/ANC
Power Distribution Center
548 IN CASE OF EMERGENCY

CavityCartridge Fuse Blade FuseDescription
F10 ––Not Used
F11 ––Not Used
F12 –5 Amp Tan Battery Sensor (IBS)
F13 ––Not Used
F14 –10 Amp Red ECM
F15 40 Amp Green –Power Locks
F16 –20 Amp Yellow ECM
F17 30 Amp Pink –Starter
F18 40 Amp Green –CBC Feed #4 (Exterior
Lights #1)
F19 25 Amp Clear –2nd Row Folding Seats
Solenoid LT
F20 –10 Amp Red A/C Compressor Clutch
F21 25 Amp Clear –2nd Row Folding Seat
Solenoid RT
7
IN CASE OF EMERGENCY 549

CavityCartridge Fuse Blade FuseDescription
F22 ––Not Used
F23 ––Not used
F24 –20 Amp Yellow RR Wiper
F25B –10 Amp Red LT RR Door/RT RR Re-
lease Module/Active GrillShutter/Power Mirror
F26 40 Amp Green –Front HVAC Blower Mo-
tor
F27 25 Amp Clear –RR Slide Door Module
F28 –10 Amp Red Diagnostic Port/ USB
Port/ AUX Port/ Video USB Port
F29 ––Not Used
F30 –15 Amp Blue Media Hub 1, 2/ Power
Lumbar
F31 ––Not Used
550 IN CASE OF EMERGENCY
