NOTE:The vehicle will only unlock the doors when a
valid RKE key fob is detected inside the vehicle, and no
valid RKE key fob is detected outside the vehicle. The
vehicle will not unlock the doors when any of the
following conditions are met:
• The doors are manually locked using the door lock
knobs.
• There is a valid RKE key fob outside the vehicle and
within 3 ft (1 m) of either Passive Entry door handle.
• Three attempts are made to lock the doors using the
door panel switch and then close the doors.
NOTE: On the third attempt ALL doors will lock and
the RKE key fob can be locked in the vehicle. To Enter The Liftgate
With a valid RKE key fob within 3 ft (1 m) of the liftgate,
cycle the handle to open the liftgate and pull the liftgate
open with one fluid motion.
NOTE:
If “Unlock Driver Door 1st Press” is pro-
grammed, only the liftgate will unlock when the liftgate
release handle is pushed. If “Unlock All Doors 1st Press”
is programmed, all doors and the liftgate will unlock
when the liftgate release handle is pushed. To select
between “Unlock Driver Door 1st Press” and “Unlock All
Doors 1st Press,” refer to “Uconnect Settings” in “Multi-
media” for further information.
3
GETTING TO KNOW YOUR VEHICLE 47

To Lock The Vehicle’s Doors
With one of the vehicle’s RKE key fobs within 3 ft (1 m)
of the driver or passenger front door handle, push the
door handle LOCK button to lock all four doors and the
liftgate.Do NOT grab the door handle, when pushing the door
handle button. This could unlock the door(s).
Push The Door Handle Button To Lock
Do NOT Grab The Door Handle When Locking
48 GETTING TO KNOW YOUR VEHICLE

NOTE:
•After pushing the door handle button, you must wait
two seconds before you can lock or unlock the doors,
using either Passive Entry door handle. This is done to
allow you to check if the vehicle is locked by pulling
the door handle, without the vehicle reacting and
unlocking.
• The Passive Entry system will not operate if the RKE
transmitter battery is dead.
The vehicle doors can also be locked by using the RKE
transmitter lock button, or the lock button located on the
vehicle’s interior door panel.
Manual Sliding Side Door
The sliding door may be opened from the inside or the
outside. Pull outward on the exterior handle to open the
sliding door. The sliding door inside handle functions by rocking forward and back. Rocking the handle back-
wards opens the door and rocking forward releases the
hold open latch in order to close the door.
To keep your door operating properly, observe the fol-
lowing guidelines:
•
Always open the door smoothly.
• Avoid high impacts against the door stop when open-
ing the door. This is very important when your vehicle
is parked on an incline as the door will slide faster in
the downhill direction.
• There is a hold-open latch that is activated when the
sliding door is fully opened. This latch will keep your
sliding door open on any incline. To close the sliding
door after the hold-open latch is activated, you must
rock the inside handle forward or pull outward on the
exterior handle.
3
GETTING TO KNOW YOUR VEHICLE 49

Always make sure that the sliding door is fully latched
anytime the vehicle is in motion.
NOTE:The left side sliding door cannot be opened while
the fuel door is open.Power Sliding Side Door — If Equipped
Side Door Handle And Lock Functions1 — Door Handle
2 — Door Lock
50 GETTING TO KNOW YOUR VEHICLE

The power sliding door may be power opened or closed
in several ways:
•RKE key fob
• inside or outside handles
• the following buttons located
• in the overhead console
• just inside the sliding door
• on the outside handle
• Hands-Free Sliding Doors — If Equipped
Using any of the above ways:
• when the door is fully closed, the door will open.
• when the door is fully open, the door will close.
• when the door is moving, the door will reverse.
Push the button on the RKE key fob twice within five
seconds to open, close, or reverse a power sliding door. The RKE Key Fob and the overhead console button will
operate the door when the door is locked. All other ways
require the sliding door to be unlocked. If the vehicle is
equipped with Passive Entry, pressing the button on the
outside handle or Hands-Free feature (if equipped) will
unlock and open the sliding door, with a valid Passive
Entry RKE Key Fob within 3ft (1m) of the door handle.
NOTE:
Opening or closing the hands free sliding door (if
equipped) requires a valid RKE key fob within 3 ft (1 m)
of the door handle. If Passive Entry is turned off in the
Uconnect Settings this feature will not be functional.
To operate the sliding door manually with the handles or
to avoid unintentional operation of the power sliding
doors from the rear seats, push the power sliding door
power Off button, located in the overhead console, to
remove power to the handles and buttons just inside the
sliding doors. The power OFF LED, in the overhead
console, will be lit when the handles are manual. When
3
GETTING TO KNOW YOUR VEHICLE 51

the LED is lit, pushing the power sliding door power OFF
button will return the handles to power operation.
NOTE:Tones are sounded and the turn signals are
flashed with sliding door movements. These alerts can be
turned on or off in ‘Uconnect Settings’.
There are power sliding side door switches located on the
B-Pillar trim panel, just in front of the power sliding door
for the rear seat passengers.
Driver Side Power Sliding Side Door Switch
52 GETTING TO KNOW YOUR VEHICLE

If the inside or outside door handles are used while the
power sliding side door is activated, the power sliding
door will reverse direction.
To avoid unintentional operation of the power sliding
doors from the rear seats, push the power sliding doorpower Off button, located in the overhead console, to
remove power to the handles and buttons just inside the
sliding doors.
NOTE:
•
The sliding door will not power open or close if the
gear selector is not in Park or Neutral.
• If anything obstructs the power sliding side door while
it is closing or opening, the door will automatically
reverse to the closed or open position, provided it
meets sufficient resistance.
• If the power sliding door encounters multiple obstruc-
tions within the same cycle, the system will automati-
cally stop. If this occurs, the power sliding door must
be opened or closed manually.
Passenger Side Power Sliding Side Door Switch
3
GETTING TO KNOW YOUR VEHICLE 53

WARNING!
Personal injury or cargo damage may occur if caught
in the path of the sliding door. Make sure the door
path is clear before closing the door.
WARNING!
Before driving off, check the instrument cluster for a
sliding door or door open message or warning indi-
cator. Failure to do this could result in unintention-
ally leaving the sliding door open while driving.
Hands-Free Sliding Doors – If Equipped
Hands-Free Feature
To open or close the Hands-Free Sliding Doors, use a
gentle single forward and back kicking motion under the
Hands-Free Sliding Doors
