2017 CHRYSLER PACIFICA Owners Manual

Cigar Lighter — If Equipped
NOTE:Cigar lighters can be purchased at an authorized
dealer through MOPAR parts. To ensure proper cigar
lighter operation, a MOPAR knob and element must be
used.
The cigar lighter is located at the bottom of the instru-
ment panel. Push lighter inward to heat.
After a few seconds, the lighter automatically returns to
its initial position and is ready to be used.
WARNING!
When the cigar lighter is in use it becomes very hot.
To avoid serious injury, handle the cigar lighter with
care. Always check that the cigar lighter has turned
off.
CAUTION!
Do not connect devices with power higher than 180
Watts (15 Amps) to the socket. Do not damage the
socket by using unsuitable adaptors. If the 180 Watt
(15 Amp) power rating is exceeded the fuse protect-
ing the system will need to be replaced.
Smoker’s Package Kit — If Equipped
With the optional authorized dealer-installed Smoker’s
Package Kit, a removable ash receiver is inserted into one
of the two cupholders in the center floor console. To
install the ash receiver, align the receiver so the thumb
grip on the lid is facing rearward. Push the ash receiver
into either of the cup wells to secure. Pull upward on the
ash receiver to remove for cleaning and/or storage.
The left rear trim panel cupholder is designed to accom-
modate a second ash receiver, if desired.
3
GETTING TO KNOW YOUR VEHICLE 199

Overhead Storage With Sunglass Storage
At the front of the overhead console, a compartment is
provided for the storage of one pair of sunglasses.
From the closed position, push the door latch to open the
compartment.The door will slowly rotate to the full open position.
Over Head Sunglass Door Latch
Full Open Position
200 GETTING TO KNOW YOUR VEHICLE

ROOF LUGGAGE RACK — IF EQUIPPED
The crossbars and side rails are designed to carry weight
on vehicles equipped with a luggage rack.The load must
not exceed 150 lbs (68 kg), and should be uniformly
distributed over the luggage rack crossbars.
The crossbars on your vehicle are delivered stowed
within the roof rack side rails. Crossbars should always
be used whenever cargo is placed on the roof rack. Check
the straps frequently to be sure that the load remains
securely attached.
Roof Rack
1 — Side Rail
2 — Crossbar
3
GETTING TO KNOW YOUR VEHICLE 201

The roof rack does not increase the total load carrying
capacity of the vehicle. Be sure the total load of cargo
inside the vehicle plus that on the external rack does not
exceed the maximum vehicle load capacity.
Deploying The Crossbars
To deploy the crossbars, completely loosen the thumb
screws at both ends of the crossbar and lift the crossbar
from its stowed position in the side rail. Repeat with
crossbar on the opposite side.NOTE:The thumb screws cannot be fully removed.
Thumb Screw
202 GETTING TO KNOW YOUR VEHICLE

CAUTION!
Use care when removing and handling the crossbars
to prevent damage to the vehicle.Bend the crossbar supports at each end, taking care to
keep hand clear of pivoting joint. Slide the thumb screw
down.
Position the crossbars across the roof making sure the
letters on the crossbars align with the matching letters on
the side rail.
Removing Crossbars
Bending Pivot
3
GETTING TO KNOW YOUR VEHICLE 203

Once the crossbar is in place, tighten both thumb screws
completely.Deploy and tighten the second crossbar to complete the
deployment of the crossbars.
NOTE:
The crossbars are not identical and have fixed
deployment positions. Rear crossbar can deployed in two
different positions.
Positioning CrossbarsInstalling Crossbars
204 GETTING TO KNOW YOUR VEHICLE

Stowing The Crossbars
Starting with one crossbar, completely loosen the thumb
screws at both ends. Lift the crossbar away from the
matching letter to remove it from the deployed position.
Repeat with the other crossbar.
CAUTION!
Use care when removing and handling the crossbars
to prevent damage to the vehicle.
Starting with the one crossbar, bend up the pivot sup-
ports at each end.
Crossbar Pivot
3
GETTING TO KNOW YOUR VEHICLE 205

Then, position the crossbar along the correct side rail.
Make sure the letters on the crossbar align with the
matching letters on the side rail.The crossbar will nest fully within the side rail.
Stowing Crossbars
Crossbar To Side Rail
206 GETTING TO KNOW YOUR VEHICLE
