rear seating position and have the airbag
system inspected by your authorized Audi
dealer.
- Always buckle the child seat firmly in
place even if a child is not sitting in it. A
loose child seat can fly around during a
sudden stop or in a collision.
- Always read and heed all WARNINGS
whenever using a child restraint in a vehi­
cle
c!;> page 189, Safety belts, c!;> page 197,
Airbag system
and c!;> page 221, Impor­
tant information.
{D) Tips
Always replace child restraints that were in­
stalled in a vehicle dur ing a crash. Damage to
a child restraint that is not visible could cause
it to fail in another collision situation.
Advanced front airbag system and children
Your vehicle is equipped with a front "Advanced
Ai rbag System" in compliance with United States
F edera l Motor Vehicle Safety Standard ( FMVSS)
208 as applicable at the time your vehicle was manufactured.
The Advanced Airbag system in your vehi cle has
been certified to meet the "low-risk" require­
ments for 3- and 6-year old children on the pas­
senger side and small adults on the driver side.
The low risk deployment criteria are intended to
reduce the risk of injury through interaction with
the airbag that can occur, for example, by being
too close to the steering wheel and instrument
panel when the airbag inflates. In addition, the
system has been certified to comply with the
"s uppress io n " req uiremen ts of the Safety Stand­
ard, to turn of f the front airbag for infants up to
12 months who are restrained on the front pas­
senger seat in chi ld restraints that are listed in
the Standard.
E ven though your vehicle is equipped with an Ad­
vanced Ai rbag system, all children, especially
those 12 years and younger, should always r ide
in the back seat properly restrained for their age
and size. The airbag on the passenger side makes
the front seat a potentially dangerous place for a
Child safety
child to ride. The front seat is not the safest place
for a chi ld in a forward-facing chi ld safety seat . It
can be a very dangerous place for an infant or a
larger ch ild in a rearward-facing seat.
T he vehicle's Advanced A irbag System has a ca­
pacitive passenger detection system in the front
passenger seat cushion that can detect the pres­
ence of a baby or a ch ild in a child restraint sys­
tem on this seat.
The capacitive passenger detection system regis­
ters the changes that result in an electrical field
when a child, a child restraint, and a baby b lanket
are on the front passenger seat. The change in
the measured capacitance due to the presence of
a child, a ch ild restraint, and a baby blanket on
the front passenger seat is related to the child
restraint system resting on the seat . Th e meas­
ur ed capacitance of a child restraint system var­
ies depending on the type of system and specific
make and mode l.
T he elect rical capacitance of the various types,
makes, and models of child restra in ts specified
by the U.S .National Highway Traff ic Safety Ad­
ministration (NHTSA) in the relevant safety
standard are stored in the Advanced Airbag Sys­
tem control unit together with the capacitances
typ ica l of infants and a 1-year old child. When a
child restraint is used on the front passenger
seat w ith a typical 1 year -old infant, the Ad­
vanced Airbag System compares the capacitance measured by the capacitive passenge r detection
system with the data stored in the electronic con­
trol unit.
Child restraints and Advanced front airbag
system
Regardless of the ch ild restraint that you use,
make sure that it has been certified to meet Unit­
ed States Federal Motor Vehicle Safety Standards
and has been certified by its manufacturer for
use with an a irbag. Always be sure that the child
r estra int is properly installed at one of the rear
seating positions.
If in except ional circumstances
you must use it on the front passenger seat, care­
f ully read all of the information on child safety
and Advanced Airbags and heed all of the .,.
223

Child safet y
applicab le WARN INGS . Make certain that the
chi ld and child restraint are correct ly recognized
by the capacit ive passenger detection system in
the front passenger seat, that the front passen­
ger airbag is turned off, and that the airbag sta­
tus is always correctly signaled by the
PA SS EN ­
GER AIR BAG OFF,;; ON @
light .
Many types and models of child restraints have
been available over the years, new models are in­
troduced regularly incorporat ing new and im ­
proved designs and older models are taken out of
p roduct ion . Ch ild restraints are not standardized.
Ch ild rest raints of the same type typ ica lly have
d ifferent weights and s izes and differen t "foot­
prints", the s ize and shape of the bottom of the
child restraint that sits on the seat, when they
are insta lled on a vehicle seat. These differences
make it virtually impossible to certify compliance
with the requirements for advanced airbags with
each and every ch ild restraint that has ever been
sold in the past or will be sold over the course of
the useful life of your veh icle .
For this reason, the Un ited States National High­
way Traffic Safety Administration has published a list of specific type, makes and models of child
restraints that must be used to cert ify compli­
ance of the Advanced Airbag System in your vehi­
cle with the supp ression requ irements of Fede ral
Motor Vehicle Safety Standard 208. These child
rest raints are :
Subpart A - Car bed child restraints
Mod el Manufactured on or
after
Angel G uard Angel September 25, 200 7
Ride AA2403 FOF
Subpart B - Rear-facing child re straints
Model Manufactured on or
after
Century SmartFit 4543 December 1, 1999
Cosco Arriva September 25, 2007
22-0 13PAW and base
22-999WHO
Evenflo Discovery Ad- December 1, 1999
just Right 212
224 Model
Manufactured on or
after
Evenflo First Choice December 1, 1999
204
Graco Infan t 845 7 December 1, 1999
Graco Snugr ide September 25, 2007
Peg Perego Primo Viag- September 25, 2007
gio SIP IMUNOOUS
Subpart C - Forward-facing and convertible
child re str aint s
Model Manufactured on or
after
Br itax Roundabout September 25, 2007
E9L02xx
Cosco Touriva 025 19
December 1, 1999
Cosco Summit Deluxe September 25, 2007 H igh Back Booster
22-262
Cosco High Back Boos- September 25, 2007
ter 22-209
E venflo Tribu te V September 25, 2007
379xxxx
Evenflo Medallion 254 December 1, 1999
Evenflo Generations September 25, 2007
352xxxx
Graco ComfortSport September 25, 2007
Graco Todd ler Safety
September 25, 2007
Seat Step 2
Graco Plat inum Cargo September 25, 200 7
_&. WARNING
To reduce the risk of serious injury, ma ke sure
that the
PASSENGER AIR BAG OFF,;; light
comes on and stays on whenever a ch ild re­
stra int is installed on the front passenger seat
and the ign ition is switched on.
-Take the child restra int off the front passen­
ger seat and install it properly at one of the rear seat positions if the
PA SSENGER AIR
BAG OFF,;;
light does not stay on .
- Have the airbag system inspected by your
author ized Audi dealer immed iately.

co
co
.... N
" N .... 0
0
Vl c:o
@ Tips
The chi ld seats listed in categories A to C have
been statically tested by Audi only for the Ad­
vanced Airbag function .
Important safety instructions for using
child safety seats
Correct use of child safety seats substantially re­
duces the risk of injury in an accident!
As the driver, you are responsible for the safety
of everybody in the vehicle, especially children:
~ Always use the right child safety seat for each
child and a lways use it properly~
page 22 7.
~ Always carefully follow the child safety seat
manufacturer's instructions on how to route
the safety belt properly through the child safe­
ty seat .
~ When using the vehicle safety be lt to install a
child safety seat , you must first activate the
convertible locking retractor on the safety be lt
to prevent the child safety seat from moving
~ page 232.
~ Push the child safety seat down w ith your full
weight to get the safety be lt rea lly t ight so that
the seat cannot move forward and sideways more than 1 in (2 .5 cm).
~ Secure unused safety belts on the rear seat
~ page 227.
Always remember: Even though your vehicle is
equipped with an Advanced Airbag system, all
children, especially those 12 years and younger,
should always ride in the back seat properly re­
stra ined for their age and size.
_&, WARNING
Not using a ch ild safety seat , using the w rong
child sa fety seat or imp roperly installing a
child restraint increases the risk of serious
personal injury and death.
- All vehicle occupants and especia lly children
must be restrained properly whenever riding
in a vehicle . An unrestrained or improperly
restrained child could be injured by striking
the interior or by being ejected from the ve­ hicle during a sudden maneuver or impact.
Ch ild safety
An unrestrained or improperly restrained
child is also at greater r isk of injury or death
through contact with an inf lating airbag.
- Commercially available child safety seats
are required to comply with U.S . Federal
Motor Vehicle Safety Standard (FMVSS) 213
(in Canada CMVSS 213) .
- When buying a child restra int, select one
that fits your chi ld and the vehicle.
- Only use child restraint systems that fully
contact the flat portion of the seat cush­
ion . The child restraint must not tip or
lean to either side. Audi does not recom­
mend using child safety seats that rest on
legs or tube-like frames. They do not pro­
vide adequate contact with the seat.
- Always heed all lega l requirements per­
ta ining to the insta llation and use of child
safety seats and carefully follow the in­
structions provided by the manufacturer
of the seat you are using .
- Never allow children under 4 ft
9 in (57 in/
1.45 m) to wear a normal safety belt . H ow­
eve r, the rear seat in the TT Coupe is de­
signed to permit children who are between
4 ft 3 in (1.3 m) and 4
ft 9 in (57 in/1.45 m)
tall to use the available three-point lap and
shoulder safety belts.
- Never let more than one child occupy a chi ld
safety seat .
- Never let babies or o lder children ride in a
veh icle while sitting on the lap of another
passenger.
- Holding a child in your arms is never a sub­
stitute for a child restraint system .
- The strongest person cou ld not ho ld the
ch ild with the forces that exist in an acci­
dent . The child will strike the interior of
the vehicle and can also be struck by the passenger.
- The child and the passenger can also in­
jure each other in an accident.
- Never install rear-fac ing child safety seats
or infant car riers on the front passenger
seat. A child w ill be seriously injured and
can be killed when the passenger a irbag in­
flates -even with an Advanced Airbag Sys­
tem .
225

Child safety
-The inflating airbag will hit the child safety
seat or infant carrier with great force and
will smash the child safety seat and child
against the backrest, center armrest, door
or roof .
- Always install rear-facing child safety seats
or infant carriers on the rear seat .
- Make sure there is enough space in front of
the child in the child seat . If necessary, ad­
just the angle and position of the seat in front of the child seat.
- Forward -facing child safety seats installed
on the front passenger's seat can interfere
with the airbag when it inflates and cause serious injury to the child . Always install for­
ward-facing child safety seats on the rear
seat.
- If exceptional circumstances require the use
of a forward-facing child restraint on the
front passenger's seat, the child's safety and well-being require that the following
special precautions be taken:
- Make sure the forward-facing seat has
been designed and certified by its manu­
facturer for use on a front seat with a pas­ senger front and side airbag .
- Always carefully follow the manufacturer's
instructions provided with the child safety
seat or carrier .
- Always move the front passenger seat into
the rearmost position of the passenger
seat's fore and aft adjustment range, and
as far away from the airbag as possible be­
fore installing the child restraint.
- Always make sure that nothing prevents
the front passenger's seat from being
moved to the rearmost position in its fore
and aft adjustment range .
- Always make sure that the backrest is in
the upright position .
- Never place or use any electrical device
(such as a laptop, CD player, electronic
games device, power inverter or seat heat­
er for child seats) on the front passenger
seat if the device is connected to the 12-
volt socket or the cigarette lighter socket.
- If a seat heater has been retrofitted or
otherwise added to the front passenger
226
seat, never install any child restraint sys­
tem on this seat.
- Make sure that there are no wet objects
(such as a wet towel) and no water or oth­
er liquids on the front passenger seat
cushion.
- Never place objects on the seat (such as a
laptop, CD player, electronic games de­
vice, power inverter or seat heater for
child seats) . These may influence the elec­
trical capacitance measured by the capaci­
tive passenger detection system and can
also fly around in an accident and cause
serious personal injury.
- Always buckle the child safety seat firmly in
place even if a child is not sitting in it. A
loose child safety seat can fly around during
a sudden stop or in a collision .
-Always read and heed all WARNINGS when­
ever using a child restrained in a vehicle is
being used
c::!;> page 189, Safety belts,
c::!;> page 197, Airbag system and
c::!;> page 221, Child safety .
A WARNING
To reduce the risk of serious injury, make sure
that the
PASSENGER AIR BAG OFF '-i; light
comes on and stays on whenever a child re ­
straint is installed on the front passenger seat
and the ignition is switched on.
-Take the child restraint off the front passen­
ger seat and install it properly at one of the
rear seat positions if the
PASSENGER AIR
BAG OFF
'-i; light does not stay on .
- Have the airbag system inspected by your
authorized Audi dealer immediately.

CD
CD
.... N
" N .... 0
0
Ill co
Secure unused safety belts on the rear seat
Fig. 170 Sche matic overview : keep unu sed sa fety belt s
away from c hildre n in c hild safety seats .· outer rear safety
belt,
If a child safety seat is used on the rear bench,
especially with LATCH universal lower anchorag­
es, the unused safety belts
mu st be secured so
that the child in the ch ild restraint cannot reach
them 9&, .
- Fasten the unused safety belt behind the child
seat and let the be lt retractor w ind up the safe ­
ty be lt webbing.
.,&. WARNING
A child in a child safe ty seat ins talled with the
LA TC H l ower anchorages or w ith the standard
safety belt or a ch ild in a booste r seat on the
rear seat could play with u nused rear seat
safety belts and become entangled. This
co uld cause the chi ld serious personal in jury
and even death.
- Always secure unused rear seat safety belts
out of reach of chi ldren in child seats such
as by fastening the unused safety belt be­
hind the child seat and letting the belt re·
tractor wind up the webb ing .
Ch ild sa fety
Child seats
Infant seats
Babies and infants up to about one year old and
20 lbs or
9 kg need special rearward -facing child
restraints that support the back , neck and head
in a crash .
Fig . 17 1 Schem atic overv ie w : rearward -fac ing in fan t seat,
p rope rly i nsta lled o n the rea r sea t
.,. When using the vehicle safety belt to install a
child safety seat, yo u must first activate the
convertib le loc king re tractor on the safety belt
to p revent the ch ild safety seat from moving
9 page232 .
.,. Push the ch ild safety seat down with your full
weight to g et the saf ety belt really tight so that
the seat cannot move forward and sideways
more than 1 in (2.5 cm) .
"' Secure unused safety belts on the rear seat
~ page 227.
Infants up to about one yea r (20 lbs or 9 kg) a re
best protected in special infant carr iers and child
safety seats designed for the ir age group. Many
expe rts believe that infants and small ch ild ren
shou ld ride o nly in special restra ints in wh ich the
ch ild fa ces the back of the vehicle. These infant
seats support the baby's back, neck and head in a
crash
~ fig. 171 .
The airbag on the passenge r side makes the front
sea t a potent ially dangerous place for a child to
ride. The fron t seat is not the safest place for a
c h ild in a forward -fac ing ch ild seat. It is a
very
dange rous p lace for an infant or a larger chi ld in
a rearward-fac ing seat . .,..
227

Child safety
_& WARNING
Not using a child safety seat, using the wrong
child safety seat or improperly install ing a
child restra int increases the risk of serious
personal injury and death in a crash.
- Never install rear-facing child safety seats or infant carr iers on the front passenger
seat -
even with an Advanced Airbag System.
A chi ld will be seriously injured and can be
k illed when the inflating airbag hits the
child safety seat or infant carrier with great
force and smashes the child safety seat and
child against the backrest, center armrest,
door or roof
c::> page 198, Child restraints on
the front seat -some important things to
know.
- Always install rear-facing child safety seats
or infant carr iers on the rear seat.
- Never install a rear-facing child restraint in
the forward-facing direction. Such restraints
are designed for the spec ial needs of infants
and
very small children and cannot protect
them properly if the seat is forward-facing.
- If you must install a rearward fac ing ch ild
safety seat on the front passenger seat be­
cause of exceptional circumstances and the
PAS SENGER AIR BAG OFF~; light does not
come on and stay on, immed iate ly install
the rear-facing child safety seat in a rear
seat ing position and have the airbag system
inspected by your Audi dealer.
- Never place or use any electrical device (such as a laptop, CD player, electronic
games device, power inverter or seat heater
for child seats) on the front passenger seat
if the device is connected to the 12-volt
socket or the cigarette lighter socket.
- If a seat heater has been retrofitted or oth­
erwise added to the front passenger seat,
never install any ch ild restraint system on
th is seat.
- Make sure that there are no wet objects
(such as a wet towel) and no water or other
liquids on the front passenger seat cushion.
- Never place objects on the seat (such as a
laptop, CD player, electronic games dev ice,
power inverter or seat heater for child
228
seats). These may inf luence the electrical
capacitance measured by the capacitive pas­
senger detect ion system and can also fly
around in an accident and cause serious per­
sonal injury.
-Always read and heed all WARNINGS when­
ever using a child restrained in a vehicle is
be ing used
c::> page 189, Safety belts,
c::>page 197, Airbag syste,n
and
c::>page 221, Important information.
Convertible child safety seats
Properly used convertible child safety seats can
help protect toddlers and children over age one who weigh between 20 and 40 lbs (9 and 18 kg)
in a crash.
Fig . 172 Schematic overview: installat ion of the attach­
me nts applicable to a LATCH seat
Fig. 173 Schemat ic overv iew: installation of the seat using
the vehicle's safety belt system
.,. When using the vehicle safety belt to install a
child safety seat, you must first activate the
convertible locking retractor on the safety belt
to prevent the child safety seat from moving
c::>page 232 or install the seat using the LATCH
attachments.
.,. Push the child safety seat down wi th yo ur full
weight to get the safety belt rea lly tight so that
Iii>

co
co
.... N
" N .... 0
0
Vl c:o
the seat cannot move forward or sideways more than 1 in (2.5 cm)
¢ page 232.
~ If the child safety seat is equ ipped with a tether
strap, attach it to the tether anchors
¢ page 238.
~ Secure unused safety belts on the rear seat
¢page 227 .
A toddler or child is usually too large for an in­
fant restraint if it is more than one year old and
weighs more than 20 lbs (9 kg) .
T oddlers and children who are o lder than one
year up to about 4 years old and weigh more than 20 lbs (9 kg) up to 40 lbs (18 kg) must always be
properly restrained in a ch ild safety seat cert ified
for the ir s ize and weight ¢
fig. 172 and
¢ fig. 173 .
The airbag on the passenger side makes the front
seat a potentially dangerous place for a child to
ride . The front seat is not the safest place for a
chi ld in a fo rward-facing chi ld safety seat. It is a
ve ry dangero us p lace for an infant or a la rger
ch ild in a rearward -facing seat.
_.6 WARNING
-Not using a ch ild safety seat, using the wrong
child safety seat or improper ly installing a
child restraint increases the risk of serious
personal injury and death in a collis ion or oth­
er emergency situation.
- Children on the front seat of any car, even
with Advanced Airbags, can be seriously in­
jured or even killed when an a irbag inflates.
A ch ild in a rearward-facing child safety seat
installed on the front passenger seat will be
seriously injured and can be killed if the
front airbag inflates - even with an Ad­
vanced Airbag System.
- T he inflating a irbag w ill hit the child safety
seat or infant carrier with great force and
will smash the ch ild safety seat and chi ld
against the backrest, center arm rest, door
or roof.
- Always install rear-facing child safety seats
on the rear seat.
- If you must install a rearward facing ch ild
safety seat on the front passenger seat be -
Child safety
cause of exceptional circumstances and the
PASS ENGER AIR BAG OFF~; light does not
come on and stay on, immediately install
the rear-facing child safety seat in a rear
seating position and have the a irbag system
inspected by your Audi dealer.
- The rear side of the ch ild safety seat should
be positioned as close as possible to the
backrest on the veh icle seat.
-Always read and heed all WARNINGS when­ eve r us ing a child restrained in a vehicle is
be ing used <>
page 189, Safety belts,
<> page 197, Airbag sys tem and
<> page 221, Important information.
_& WARNING
If exceptional c ircumstances req uire the use
of a forward -facing chi ld restraint on the
front passenger's seat, the child's safety and
well-being req uire that the following special
precautions be taken:
- Make sure the forward-fac ing seat has been
des igned and certified by its manufacturer
for use on a front seat with a passenger
front and side airbag.
-Always follow the manufacturer's instruc­ tions provided with the child safety seat or infant carrier .
- Always move the front passenger seat into
the rearmost pos ition of the passenger
seat's fore and aft adjustment range, and as
far away from the airbag as possible before installing the ch ild rest raint .
- Always make sure that nothing prevents the
front passenger's seat from being moved to
the rea rmost pos ition in its fore and aft ad­
justment range.
- Always make sure the backrest is in an up­
right position.
- Never p lace or use any electr ica l device
(such as a laptop, CD player, e lectron ic
games device, power inve rter or sea t hea ter
for child seats) on the front passenger seat
if the device is connected to the 12-volt
socket or the cigarette lighter socket. .,,.
229

Child safety
-If a seat heater has been retrof itted or oth­
erwise added to the front passenger seat,
never install any child restraint system on
this seat .
- Make sure that there are no wet objects
(such as a wet towe l) and no water or other
liquids on the front passenger seat cushion .
- Never place objects on the seat (such as a
laptop, CD player, electronic games device,
power inverter or seat heater for child
seats) . These may influence the e lectr ica l
capacitan ce measured by the capacitive pas­
senger detection system and can also fly
around in an acc ident and ca use serio us pe r­
sonal injury .
- Make s ure tha t the
PASSENGER AIR BAG
OFF ~;
light comes on and stays on a ll the
time whenever the ignition is switched on.
- If the PASSENGER AIR BAG OFF 1i; light
does not come on and stay on, immediate ly
insta ll the forward-facing child seat at a
seating position on the rear seat and have
the a irbag system inspected by your author­
ized Audi dealer.
- Take the ch ild restraint off the front passen­
ger seat and install it properly at one of the
rear seat positions if the
PASSEN GER AIR
BAG OFF ~;
light does not stay on whenever
the ignition is switched on .
Booster seats and safety belts
Properly used booster sea ts can help protect
children weighing between about 40 lbs and
80 lbs (18 kg and 36 kg) who are less than 4 ft 9
in (57 in/1 .45 m) tall.
F ig . 17 4 Rea r seat: chi ld p roper ly restra ined in a booster
seat
230
The vehicle's safety belts alone wi ll not fit most
children until they are at least 4
ft 9 in (57 in/
1.45 m) tall and weigh about 80 lbs (36 kg) .
Booster seats raise these children up so that the
safety be lt will pass properly over the stronger
parts of their bodies and the safety belt can help
protect them in a crash.
.. Do not use the convertib le locking retractor
when us ing the ve hicle's safety belt to restra in
a child on a booster seat .
.., The shoulder belt must lie as close to the cen­
ter of the child's collar bon e as possib le and
must l ie flat and snug on the uppe r body.
It
must never lie across the throat or neck. The
lap belt must lie ac ross the pelvis and never
across t he stomach or abdomen . Make sure the
belt lies flat and snug. Pu ll on the belt to tight­
en if necessary.
.. Secure unused safety belts on the rear seat
¢page 227.
Children up to at least 8 years o ld (over 40 lbs or
18 kg) are best protected in child safety seats de ­
s igned for their age and weight. Experts say that
the skeletal structure, part icu larly the pelvis, of
these children is not fully developed, and they must not use the vehicle safety belts without a
su itab le child restra int.
It is usually best to put these children in appro­
pr iate booster seats . Be sure the booster seat
meets a ll applicab le safety standards .
Booster seats raise the seating position of the
c hi ld and reposition both the lap and shoulder
parts of the safety belt so that they pass across
the chi ld's body in the right places . The rou ting of
the be lt over the ch ild's body is very important
fo r the child's protection, whet he r or not a boos ­
ter seat is used. C hildren age 12 and under m ust
a lways ride in the rear seat.
Never use the lap belt port ion of the vehicle's
safety belt alone to restra in any child, regard less
of how b ig the child is. A lways remember that
c hi ldre n do not have the pronounced pe lvic struc ­
ture requ ired for the proper function of lap belt
portion of the vehicle 's three point lap and
shou lder belts. The chi ld's safety absolutely re­
quires that a lap belt port ion of the safety belt be ...,
