2016 TOYOTA HIGHLANDER Owners Manual

4576-3. Using the storage features
6
Interior features
HIGHLANDER_U (OM48F09U)
Raise the hooks to use.
Cargo hooks are provided for
securing loose items.
Luggage compartment features
Cargo hooks
Grocery bag hooks
NOTICE
Do not hang any object heavier than 6.6 lb. (3 kg) on the grocery bag hooks.

4586-3. Using the storage features
HIGHLANDER_U (OM48F09U)■
Center deck under tray
Pull the strap upwards to
open the center deck board.
To secure the center deck
board, remove the hook on
the backside of the center
deck board and attach the
hook to the head restraint on
the third seats as shown.
■Deck side box
Pull the strap upwards to open
the side deck board.
Auxiliary boxes
1
2
WARNING
Do not drive with any of the deck boards opened. Items may fall out and
cause injury.

459
6
Interior features
HIGHLANDER_U (OM48F09U)
6-4. Using the other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Open the cover.
The vanity light turns on.
■ To prevent battery discharge
If the vanity lights remain on for 20 minutes while the engine is off, the lights
will turn off automatically.
Other interior features
Sun visors
1
2
3
Vanity mirrors

4606-4. Using the other interior features
HIGHLANDER_U (OM48F09U)
Push the lid.
Push the lid back up half way.
■To use the overhead console from the conversation mirror state
Fully close the lid, then open it again. (
P. 455)
Conversation mirror
1
2

4616-4. Using the other interior features
6
Interior features
HIGHLANDER_U (OM48F09U)
The clock can be adjusted by pressing the buttons.Adjusts the hours
Adjusts the minutes
■The clock is displayed when
Vehicles without a smart key system
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart key system
The engine switch is in ACCESSORY or IGNITION ON mode.
■ When the battery is disconnected
The time display will automatically be set to 1:00.
Clock
1
2

4626-4. Using the other interior features
HIGHLANDER_U (OM48F09U)
The temperature display shows temperatures within the range of -40 F
(-40 C) to 122 F (50 C).
■ The outside temperature is displayed when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The engine switch is in IGNITION ON mode.
■ Display
In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change.
●When the vehicle is stopped, or moving at low speeds (less than 15 mph
[25 km/h]).
● When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)
■ When the outside temp erature display flashes
Vehicles with monochrome display
If the outside temperature is 37 F (3 C) or less, the temperature display
flashes 10 times, and then illuminates.
Vehicles with color display
If the outside temperature is 37 F (3°C) or less, the ice warning indicator
flashes 10 times, and then illuminates.
■ When “--” or “E” is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer.
Outside temperature display
Vehicles with monochrome dis-
playVehicles with color display

4636-4. Using the other interior features
6
Interior features
HIGHLANDER_U (OM48F09U)
The power outlet can be used for the following components:12 V: Accessories that run on less than 10 A
120 VAC: Accessories that use less than 100 W
■12 V
Front
Open the lid.
Console box
Open the console box lid ( P.
451) and open the lid.
Rear
Open the lid.
Power outlets

4646-4. Using the other interior features
HIGHLANDER_U (OM48F09U)■
120 VAC (if equipped)
Open the lid.
■
The power outlets can be used when
12 V
Vehicles without a smart key system:
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart key system:
The engine switch is in ACCESSORY or IGNITION ON mode.
120 VAC
The engine switch is in IGNITION ON mode.
