SEC-108
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2110 SHIFT POSITION/CLUTCH INTERLOCK SWITCH
B2110 SHIFT POSITION/C
LUTCH INTERLOCK SWITCH
DTC LogicINFOID:0000000012430430
DTC DETECTION LOGIC
NOTE:
If DTC B2110 is displayed with DTC U1000, first per form the trouble diagnosis for DTC U1000. Refer to BCS-
63, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Shift selector lever to the P position.
2. Turn ignition switch ON and wait 1 second or more.
3. Shift selector lever to the N position and wait 1 second or more.
4. Shift selector lever to the position other than P and N, and wait 1 second or more.
5. Check DTC in “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC detected?
YES >> Go to SEC-108, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis Procedure INFOID:0000000012430431
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF BCM
Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to BCS-50, "DTCIndex".
NO >> GO TO 2.
2.CHECK IPDM E/R SIGNAL CIRCUIT OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Disconnect transmission range switch connector.
4. Check continuity between IPDM E/R harness connector and transmission range switch harness connec- tor.
5. Check continuity between IP DM E/R harness connector and ground.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B210F INTRLCK/PNP SW OFF IPDM E/R detects a difference between the
following signals:
• P/N position signal from transmission
range switch and P/N position signal
(CAN) from BCM. • Harness or connectors
(The CAN communication line is open
or shorted.)
• Harness or connectors (Transmission range switch circuit is
open or shorted.)
• Transmission range switch
• IPDM E/R
•BCM
IPDM E/R Transmission range switch
Continuity
Connector TerminalConnector Terminal
F 424 0F 521 0Y es
Revision: August 2015 2016 Versa Note

cardiagn.com

B2110 SHIFT POSITION/CLUTCH INTERLOCK SWITCHSEC-109
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO >> Repair or replace harness.
(+)
(–)Continuity
IPDM E/R
Connector Terminal
F42 40Ground No
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-110
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
VEHICLE SECURITY INDICATOR
VEHICLE SECURITY INDICATOR
DescriptionINFOID:0000000012542522
• Vehicle security indicator is built in combination meter.
• NATS (Nissan Anti-Theft System) condition is indicated by blink or illumination of vehicle security indicator.
Component Function CheckINFOID:0000000012542523
1.CHECK FUNCTION
1. Perform “Active Test” of “THEFT IND” in the “IMMU” using CONSULT.
2. Check vehicle security indicator operation.
Is the inspection result normal?
YES >> Inspection End.
NO >> Refer to SEC-110, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012542524
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.SECURITY INDICATOR LAMP ACTIVE TEST
With CONSULT
Check “THEFT IND”” in “Active Test” of “IMMU”.
Without CONSULT
1. Disconnect BCM.
2. Check voltage between BCM harness connector M97 terminal 23 and ground.
Is the inspection result normal?
YES >> Security indicator lamp is OK.
NO >> GO TO 2.
2.SECURITY INDICATOR LAMP CHECK
Check security indicator lamp condition.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace combination meter. Refer to MWI-115, "
Removal and Installation".
3.CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect BCM and security indicator lamp connector.
3. Check continuity between BCM connector M97 term inal 23 and combination meter connector M24 termi-
nal 18.
Test item Description
THEFT IND ON
Vehicle security indicator ON
OFF OFF
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M97 23Ground ON
0
OFF Battery voltage
Revision: August 2015 2016 Versa Note

cardiagn.com

VEHICLE SECURITY INDICATORSEC-111
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
4. Check continuity between BCM connector M97 terminal 23 and ground.
Is the inspection result normal?
YES >> Check the following: • 10A fuse No. 8, located in fuse block (J/B)
• Harness for open or short between security indicator lamp and fuse.
NO >> Repair or replace harness.
BCM Combination meter
Continuity
Connector TerminalConnector Terminal
M97 23M24 18Yes
BCM GroundContinuity
Connector Terminal
M97 23 No
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-112
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
ENGINE DOES NOT START WHEN INTELLI
GENT KEY IS INSIDE OF VEHICLE
SYMPTOM DIAGNOSIS
ENGINE DOES NOT START WHEN INTELLIGENT KEY IS INSIDE OF VE-
HICLE
DescriptionINFOID:0000000012430432
Engine does not start when push-button ignition swit ch is pressed while carrying Intelligent Key.
NOTE:
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and check each symptom.
• The engine start function, door lock function, power di stribution system, and NATS-IVIS/NVIS in the Intelli-
gent Key system are closely related to each other regarding control. The vehicle security function can oper-
ate only when the door lock and power dist ribution system are operating normally.
Conditions of Vehicle (Operating Conditions)
• “ENGINE START BY I-KEY” setting in “Work suppor t” in “INTELLIGENT KEY” of “BCM” is ON.
• One or more of Intelligent Keys with registered Intelligent Key ID is in the vehicle.
Diagnosis ProcedureINFOID:0000000012430433
1.PERFORM WORK SUPPORT
Perform “INSIDE ANT DIAGNOSIS” in “Work Support” of “INTELLIGENT KEY” of “BCM” using CONSULT.
Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Func tion (BCM - INTELLIGENT KEY)".
>> GO TO 2.
2.PERFORM SELF-DIAGNOSIS RESULT
Select “Self Diagnostic Result” mode of “BCM”, and check whether or not DTC of inside key antenna is
detected.
Is DTC detected?
YES >> Perform the trouble diagnosis for detected DTC. Refer to BCS-50, "DTCIndex".
NO >> GO TO 3.
3.CHECK PUSH-BUTTON IGNITION SWITCH
Check push-button ignition switch.
Refer to SEC-66, "
Component Inspection".
Is the operation normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning parts.
4.CONFIRM THE OPERATION
Confirm the operation again.
Is the inspection normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> GO TO 1.
Revision: August 2015 2016 Versa Note

cardiagn.com

SECURITY INDICATOR LAMP DOES NOT TURN ON OR BLINKSEC-113
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
SECURITY INDICATOR LAMP DOES NOT TURN ON OR BLINK
DescriptionINFOID:0000000012430434
Security indicator lamp does not blink when power supply position is other than the ON position.
NOTE:
• Before performing the diagnosis, perform “Work Flow”. Refer to SEC-46, "
Work Flow".
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and check each symptom.
Conditions of Vehicle (Operating Conditions)
Power supply position is other than the ON position.
Diagnosis ProcedureINFOID:0000000012430435
1.CHECK SECURITY INDICATOR LAMP
Check security indicator lamp.
Refer to SEC-110, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> GO TO 1.
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-114
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
NATS ANTENNA AMP.
REMOVAL AND INSTALLATION
NATS ANTENNA AMP.
Removal and InstallationINFOID:0000000012430436
REMOVAL
1. Remove cluster lid A. Refer to
IP-21, "Removal and Installation".
2. Release pawls and remove NATS antenna amp. (1). : Pawl
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
• If NATS antenna amp. is not installed correctly, NV IS (NATS) system will not operate properly and "SELF-
DIAG RESULTS" on CONSULT screen will show "LOCK MODE" or "CHAIN OF IMMU-KEY".
• Initialization is not necessary when only t he NATS antenna amp. is replaced with a new one.
ALKIA3179ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

PUSH-BUTTON IGNITION SWITCHSEC-115
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
PUSH-BUTTON IGNITION SWITCH
Removal and InstallationINFOID:0000000012430437
REMOVAL
1. Remove NATS antenna amp. Refer to SEC-114, "Removal and Installation".
2. Release pawls and remove the push-button ignition switch (1). : Pawl
INSTALLATION
Installation is in the reverse order of removal.
ALKIA3180ZZ
