2016 NISSAN NOTE key

SEC-100
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B210C STARTER CONTROL RELAY
B210C STARTER CONTROL RELAY
DTC LogicINFOID:0000000012430422
DTC DETECTION LOGIC
NOTE:
• If DTC B210C is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• When IPDM E/R power supply voltage is low (Approx. 7 - 8 V for about 1 second), the DTC B210C may be detected.
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION
1. Turn ignition switch ON.
2. Turn ignition switch OFF and wait 1 second or more.
3. Turn ignition switch ON.
4. Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC B210C displayed?
YES >> Refer to SEC-100, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430423
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1. PERFORM SELF DIAGNOSTIC RESULT
Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is display history of DTC B210C CRNT?
YES >> GO TO 2.
NO >> Refer to GI-42, "
Intermittent Incident".
2.CHECK STARTER CONTROL RELA Y CONTROL CIRCUITS VOLTAGE
Check voltage between IPDM E/R connectors and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO (WITH M/T)>>GO TO 3.
NO (WITH CVT)>>GO TO 4.
CONSULT Display DTC Detection Condition Possible Cause
STR CONT RLY OFF CIRC
[B210C] When comparing the following items, IPDM E/R
detects that starter control relay is stuck in the
OFF position for 1 second or more:
• Starter control relay signal (CAN) from BCM.
• Starter relay status signal (CAN) from BCM.
• Starter control relay an
d starter relay status
signal. (IPDM E/R input)
• Starter control relay co ntrol signal. (IPDM E/R
output) • IPDM E/R
•BCM
•Battery
IPDM E/R
GroundVo l ta g e
(Approx.)
Connector Terminal
E44 (WITH M/T) 13
—Battery voltage
F42 (WITH CVT) 40
Revision: August 2015 2016 Versa Note

cardiagn.com

B210C STARTER CONTROL RELAYSEC-101
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
3.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connector E44 and clutch interlock switch connector E34.
2. Check continuity between IPDM E/R connector E44 and clutch interlock switch connector E34.
3. Disconnect BCM connector M98.
4. Check continuity between IPDM E/R connector E44 and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness or connectors.
4.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connector F42 and transmission range switch connector F52.
2. Check continuity between IPDM E/R connecto r F42 and transmission range switch connector F52.
3. Disconnect BCM connector M98.
4. Check continuity between IPDM E/R connector F42 and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness or connectors.
IPDM E/R Clutch interlock switch
Continuity
Connector TerminalConnector Terminal
E44 13E34 2Yes
IPDM E/R
GroundContinuity
Connector Terminal
E44 13—No
IPDM E/R Transmission range switch
Continuity
Connector TerminalConnector Terminal
F42 40F52 10Yes
IPDM E/R
GroundContinuity
Connector Terminal
F42 40 —No
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-102
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B210D STARTER RELAY
B210D STARTER RELAY
DTC LogicINFOID:0000000012430424
DTC DETECTION LOGIC
NOTE:
If DTC B210D is displayed with DTC U1000, first
perform the trouble diagnosis for DTC U1000. Refer to BCS-
63, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION
1. Turn ignition switch ON.
2. Turn ignition switch OFF and wait 1 second or more.
3. Turn ignition switch ON.
4. Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC B210D displayed?
YES >> Refer to SEC-102, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430425
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1. PERFORM SELF DIAGNOSTIC RESULT
Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is display history of DTC B210D CRNT?
YES >> GO TO 2.
NO >> Refer to GI-42, "
Intermittent Incident".
2.CHECK STARTER CONTROL RELA Y CONTROL CIRCUITS VOLTAGE
Check voltage between IPDM E/R connectors and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO (WITH M/T)>>GO TO 3.
NO (WITH CVT)>>GO TO 4.
3.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connectors E44, BCM connecto r M98, clutch interlock switch connector E34.
CONSULT DisplayDTC Detection Condition Possible Cause
STARTER RLY ON CIRC
[B210D] When comparing the following items, IPDM E/R
detects that starter control relay is stuck in the
ON position for 5 second or more:
• Starter control relay signal (CAN) from BCM.
• Starter relay status signal (CAN) from BCM.
• Starter control relay an
d starter relay status
signal. (IPDM E/R input)
• Starter control relay co ntrol signal. (IPDM E/R
output) • Harness or connectors (starter motor relay
control circuit open or short.)
• IPDM E/R
•BCM
IPDM E/R GroundVo l ta g e
(Approx.)
Connector Terminal
E44 13
—Battery voltage
F42 40
Revision: August 2015 2016 Versa Note

cardiagn.com

B210D STARTER RELAYSEC-103
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
2. Check continuity between IPDM E/R connector E44 and ground.
Is the inspection result normal?
YES >> Refer to SEC-82, "Diagnosis Procedure".
NO >> Repair or replace harness or connectors.
4.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connectors F42, BCM connec tor M98, transmission range switch connector F52.
2. Check continuity between IPDM E/R connector F42 and ground.
Is the inspection result normal?
YES >> Refer to SEC-82, "Diagnosis Procedure".
NO >> Repair or replace harness or connectors.
IPDM E/R GroundContinuity
Connector Terminal
E44 13—No
IPDM E/R
GroundContinuity
Connector Terminal
F42 40 —No
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-104
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B210E STARTER RELAY
B210E STARTER RELAY
DTC LogicINFOID:0000000012430426
DTC DETECTION LOGIC
NOTE:
• If DTC B210E is displayed with DTC U1000, first
perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B210E is displayed with DTC B2605, first perform the trouble diagnosis for DTC B2605. Refer to
SEC-80, "
DTC Logic".
• When IPDM E/R power supply voltage is low (Approx. 7 - 8 V for about 1 second), the DTC B210F may be
detected.
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION
1. Turn ignition switch ON.
2. Turn ignition switch OFF and wait 1 second or more.
3. Turn ignition switch ON.
4. Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC B210E displayed?
YES >> Refer to SEC-104, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430427
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1. PERFORM SELF DIAGNOSTIC RESULT
Perform "Self Diagnostic Result" of "IPDM E/R" using CONSULT.
Is display history of DTC B210E CRNT?
YES >> GO TO 2.
NO >> Refer to GI-42, "
Intermittent Incident".
2.CHECK STARTER CONTROL RELA Y CONTROL CIRCUITS VOLTAGE
Check voltage between IPDM E/R connectors and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO (WITH M/T)>>GO TO 3.
CONSULT Display DTC Detection Condition Possible Cause
STARTER RELAY OFF
[B210E] When comparing the following items, IPDM E/R
detects that starter control relay is stuck in the
OFF position for 5 second or more:
• Starter control relay signal (CAN) from BCM.
• Starter relay status signal (CAN) from BCM.
• Starter control relay an
d starter relay status
signal. (IPDM E/R input)
• Starter control relay co ntrol signal. (IPDM E/R
output) • IPDM E/R
•BCM
•Battery
IPDM E/R
GroundVo l ta g e
(Approx.)
Connector Terminal
E44 13
—Battery voltage
F42 40
Revision: August 2015 2016 Versa Note

cardiagn.com

B210E STARTER RELAYSEC-105
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
NO (WITH CVT)>>GO TO 4.
3.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connector E44 and clutch interlock switch connector E34.
2. Check continuity between IPDM E/R connector E44 and clutch interlock switch connector E34.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness or connectors.
4.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connector F42 and transmission range switch connector F52.
2. Check continuity between IPDM E/R connecto r F42 and transmission range switch connector F52.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness or connectors.
IPDM E/R Clutch interlock switch
Continuity
Connector TerminalConnector Terminal
E44 13E34 2Yes
IPDM E/R Transmission range switch
Continuity
Connector TerminalConnector Terminal
F42 40F52 10Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-106
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B210F SHIFT POSITION/CLUTCH INTERLOCK SWITCH
B210F SHIFT POSITION/CLUTCH INTERLOCK SWITCH
DTC LogicINFOID:0000000012430428
DTC DETECTION LOGIC
NOTE:
If DTC B210F is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-
63, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Shift selector lever to the P position.
2. Turn ignition switch ON and wait 1 second or more.
3. Shift selector lever to the N position and wait 1 second or more.
4. Shift selector lever to the position other than P and N, and wait 1 second or more.
5. Check DTC in “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC detected?
YES >> Go to SEC-106, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis Procedure INFOID:0000000012430429
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF BCM
Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to BCS-50, "DTCIndex".
NO >> GO TO 2.
2.CHECK IPDM E/R SIGNAL CIRCUIT OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Disconnect transmission range switch connector.
4. Check continuity between IPDM E/R harness connector and transmission range switch harness connec- tor.
5. Check continuity between IP DM E/R harness connector and ground.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B210F INTRLCK/PNP SW ON IPDM E/R detects a difference between the
following signals:
• P/N position signal from transmission
range switch and P/N position signal
(CAN) from BCM . • Harness or connectors
(The CAN communication line is open
or shorted.)
• Harness or connectors (Transmission range switch circuit is
open or shorted.)
• Transmission range switch
•IPDM E/R
•BCM
IPDM E/R Transmission range switch
Continuity
Connector TerminalConnector Terminal
F42 40F52 10Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

B210F SHIFT POSITION/CLUTCH INTERLOCK SWITCHSEC-107
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO >> Repair or replace harness.
(+)
(–)Continuity
IPDM E/R
Connector Terminal
F42 40Ground No
Revision: August 2015 2016 Versa Note

cardiagn.com
