2016 NISSAN NOTE key

SEC-68
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2601 SHIFT POSITION
B2601 SHIFT POSITION
DTC LogicINFOID:0000000012430381
DTC DETECTION LOGIC
NOTE:
• If DTC B2601 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B2601 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Shift the selector lever to the P position.
2. Turn ignition switch ON and wait 2 seconds or more.
3. Shift the selector lever to any position other than P and wait 2 seconds or more.
4. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-68, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430382
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK CVT SHIFT SELECTOR CIRCUIT (BCM)
1. Turn ignition switch OFF.
2. Disconnect CVT shift selector (park position switch) connector.
3. Disconnect BCM connector.
4. Check continuity between CVT shift selector (p ark position switch) harness connector and BCM harness
connector.
5. Check continuity between CVT shift selector (park position switch) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B2601 SHIFT P SIGNAL When there is a difference between P range
signal from CVT shift selector (park position
switch) and P position signal from IPDM E/R
(CAN). • Harness or connectors
(CAN communication line is open or
shorted.)
• Harness or connectors [CVT shift selector (park position
switch) circuit is open or shorted.]
• IPDM E/R
•BCM
CVT shift selector (park position switch) BCM
Continuity
Connector TerminalConnector Terminal
M38 8M97 37Yes
CVT shift selector (park position switch) GroundContinuity
Connector Terminal
M38 8 No
Revision: August 2015 2016 Versa Note

cardiagn.com

B2601 SHIFT POSITIONSEC-69
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
2.CHECK CVT SHIFT SELECTOR CIRCUIT (IPDM E/R)
1. Disconnect IPDM E/R connector.
2. Check continuity between CVT shift selector (par k position switch) harness connector and IPDM E/R har-
ness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Perform initialization of BCM and registration of al l Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
3. Perform DTC CONFIRMATION PROCEDURE for DTC B2601. Refer to SEC-68, "
DTC Logic".
Is DTC B2601 detected again?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO >> Inspection End.
CVT shift selector (park position switch) IPDM E/R
Continuity
Connector TerminalConnector Terminal
M38 8E47 80Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-70
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2602 SHIFT POSITION
B2602 SHIFT POSITION
DTC LogicINFOID:0000000012430383
DTC DETECTION LOGIC
NOTE:
• If DTC B2602 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B2602 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine.
2. Drive vehicle at a speed of 4 km/h (2.5 MPH) or more for 10 seconds or more.
3. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-70, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430384
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Check DTC in “Self Diagnostic Re sult” of “ABS” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to BRC-43, "DTC Index".
NO >> GO TO 2.
2.CHECK DTC OF COMBINATION METER
Check DTC in “Self Diagnostic Result” of “METER/M&A” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to MWI-24, "DTC Index".
NO >> GO TO 3.
3.CHECK CVT SHIFT SELECTOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect CVT shift selector (park position switch) connector.
3. Check voltage between CVT shift selector (park position switch) harness connector and ground.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B2602 SHIFT P DIAG BCM detects the following status for 10 seconds:
• Selector lever is in the P position.
• Vehicle speed is 4 km/h (2.5 MPH) or more.
• Ignition switch is in the ON position. • Harness or connectors
(The CAN communication line is
open or shorted.)
• Harness or connectors [CVT shift selector (park position
switch) circuit is open or shorted.]
• CVT shift selector (park position switch)
• Combination meter
Revision: August 2015 2016 Versa Note

cardiagn.com

B2602 SHIFT POSITIONSEC-71
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 4.
4.CHECK CVT SHIFT SELECTOR POWER SUPPLY CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between CVT shift selector (park position switch) harness connector and BCM harness connector.
3. Check continuity between CVT shift selector (park position switch) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness.
5.REPLACE BCM
1. Replace BCM. Refer to PCS-30, "
Removal and Installation".
2. Perform initialization of BCM and registration of al l Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
>> Inspection End.
6.CHECK CVT SHIFT SELECTOR CIRCUIT
1. Disconnect BCM connector and IPDM E/R connector.
2. Check continuity between CVT shift selector (park position switch) harness connector and BCM harness connector.
3. Check continuity between CVT shift selector (park position switch) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness.
7.CHECK CVT SHIFT SELECTOR (PARK POSITION SWITCH)
Refer to SEC-72, "
Component Inspection".
Is the inspection result normal?
(+)
(–)Voltage (V)
(Approx.)
CVT shift selector (park position switch)
Connector Terminal
M38 7GroundBattery voltage
CVT shift selector (park position switch) BCM
Continuity
Connector TerminalConnector Terminal
M38 7M98 104Yes
CVT shift selector (park position switch) GroundContinuity
Connector Terminal
M38 7 No
CVT shift selector (park position switch) BCM
Continuity
Connector TerminalConnector Terminal
M38 8M97 37Yes
CVT shift selector (park position switch) GroundContinuity
Connector Terminal
M38 8 No
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-72
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2602 SHIFT POSITION
YES >> GO TO 8.
NO >> Replace CVT shift selector. Refer to
TM-231, "
Removal and Installation".
8.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Component InspectionINFOID:0000000012430385
1.CHECK CVT SHIFT SELECTOR (PARK POSITION SWITCH)
1. Turn ignition switch OFF.
2. Disconnect CVT shift selector connector.
3. Check continuity between CVT shift se lector (park position switch) terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace CVT shift selector. Refer to TM-231, "
Removal and Installation".
CVT shift selector (park position switch)
ConditionContinuity
Terminal
78 Selector lever: P positionSelector button: Released
No
Selector button: Pressed Ye s
Selector lever: Other than P position
Revision: August 2015 2016 Versa Note

cardiagn.com

B2603 SHIFT POSITIONSEC-73
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2603 SHIFT POSITION
DTC LogicINFOID:0000000012430386
DTC DETECTION LOGIC
NOTE:
• If DTC B2603 is displayed with DTC B2601, first perform the trouble diagnosis for DTC B2601. Refer to SEC-68, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE 1
1. Shift the selector lever to the P position.
2. Turn ignition switch ON and wait 1 second or more.
3. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-73, "Diagnosis Procedure".
NO >> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE 2
1. Shift the selector lever to the position other than P and N, and wait 1 second or more.
2. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-73, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430387
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.INSPECTION START
Perform inspection in accordance with procedure that confirms DTC.
Which procedure confirms DTC?
DTC confirmation procedure 1>>GO TO 2.
DTC confirmation procedure 2>>GO TO 8.
2.CHECK FUSE
1. Turn power switch OFF.
2. Check that the following fuse in IPDM E/R is not blown.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting conditionPossible causes
B2603 SHIFT POSITION BCM detects the following status when ignition
switch is in the ON position:
• Transmission range switch signal: approx. 0
V.
• CVT shift selector (park position switch) sig- nal: approx. 0 V. • Harness or connector
[CVT shift selector (park position
switch) circuit is open or shorted.]
• Harness or connectors (Transmission range switch circuit is
open or shorted.)
• CVT shift selector (park position switch)
• Transmission range switch
•BCM
Signal name Fuse No.
Ignition power supply 49 (10 A)
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-74
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2603 SHIFT POSITION
YES >> GO TO 3.
NO >> Replace the blown fuse after repairing the cause of blowing.
3.CHECK TRANSMISSION RANGE SWITCH POWER SUPPLY
1. Disconnect transmission range switch connector.
2. Turn ignition switch ON.
3. Check voltage between transmission range switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.CHECK TRANSMISSION RANGE SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between transmission range s witch harness connector and IPDM E/R harness connec-
tor.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO >> Repair or replace harness.
5.CHECK BCM INPUT SIGNAL
1. Turn ignition switch OFF.
2. Connect transmission range switch harness connector.
3. Turn ignition switch ON.
4. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 13.
NO >> GO TO 6.
6.CHECK BCM INPUT SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect transmission range switch connector.
3. Disconnect BCM connector.
4. Check continuity between transmission range switch harness connector and BCM harness connector.
Is the inspection result normal?
(+)
(–)Voltage (V)
(Approx.)
Transmission range switch
Connector Terminal
F52 7GroundBattery voltage
Transmission range switch IPDM E/R
Continuity
Connector TerminalConnector Terminal
F52 7E45 21Yes
(+)
(–)Condition Voltage (V)
(Approx.)
BCM
Connector Terminal
M98 102Ground Selector lever P or N position Battery voltage
Other than above 0
Transmission range switch BCM
Continuity
Connector TerminalConnector Terminal
F52 10M98 102Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

B2603 SHIFT POSITIONSEC-75
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
YES >> GO TO 7.
NO >> Repair or replace harness.
7.CHECK TRANSMISSION RANGE SWITCH
Refer to SEC-76, "
Component Inspection (Transmission Range Switch)".
Is the inspection result normal?
YES >> GO TO 12.
NO >> Replace transmission range switch.
8.CHECK CVT SHIFT SELECTOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect CVT shift selector (park position switch) connector.
3. Check voltage between CVT shift selector (p ark position switch) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 9.
9.CHECK CVT SHIFT SELECTOR POWER SUPPLY CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between CVT shift selector (park position switch) harness connector and BCM harness connector.
3. Check continuity between CVT shift selector (park position switch) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair or replace harness.
10.CHECK CVT SHIFT SELECTOR CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between CVT shift selector (park position switch) harness connector and BCM harness connector.
3. Check continuity between CVT shift selector (park position switch) harness connector and ground.
Is the inspection result normal?
(+) (–)Voltage (V)
(Approx.)
CVT shift selector (park position switch)
Connector Terminal
M38 7GroundBattery voltage
CVT shift selector (park position switch) BCM
Continuity
Connector TerminalConnector Terminal
M38 7M98 104Yes
CVT shift selector (park position switch) GroundContinuity
Connector Terminal
M38 7 No
CVT shift selector (park position switch) BCM
Continuity
Connector TerminalConnector Terminal
M38 8M97 37Yes
CVT shift selector (park position switch) GroundContinuity
Connector Terminal
M38 8 No
Revision: August 2015 2016 Versa Note

cardiagn.com
