SEC-52
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
P1611 ID DISCORD, IMMU-ECM
P1611 ID DISCORD, IMMU-ECM
DTC LogicINFOID:0000000012430358
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check DTC in “Self Diagnostic Result” of “ENGINE” using CONSULT.
Is DTC detected?
YES >> Go to SEC-52, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430359
1.PERFORM INITIALIZATION
Perform initialization of BCM and registration of all In telligent Keys using CONSULT. Refer to the CONSULT
Immobilizer mode and follow t he on-screen instructions.
Can the system be initialized and can the engine be started with registered Intelligent Key?
YES >> Inspection End.
NO >> GO TO 2.
2.CHECK SELF DIAGNOSTIC RESULT
1. Select “Self Diagnostic Result” of “ENGINE” using CONSULT.
2. Erase DTC.
3. Perform DTC CONFIRMATION PROCEDURE for DTC P1611. Refer to SEC-52, "
DTC Logic".
Is DTC detected?
YES >> GO TO 3.
NO >> Inspection End.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Perform initialization of BCM and registration of all Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
Can the system be initialized and can the engine be started with registered Intelligent Key?
YES >> Inspection End.
NO >> GO TO 4.
4.REPLACE ECM
1. Replace ECM. Refer to EC-477, "
Removal and Installation".
2. Perform “ADDITIONAL SERVICE WHEN REPLACING ECM”. Refer to EC-125, "
Work Procedure".
>> Inspection End.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
P1611 ID DISCORD, IMMU-ECM The ID verification results between BCM
and ECM are invalid. •BCM
•ECM
Revision: August 2015
2016 Versa Note
cardiagn.com
P1612 CHAIN OF ECM-IMMUSEC-53
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
P1612 CHAIN OF ECM-IMMU
DTC LogicINFOID:0000000012430360
DTC DETECTION LOGIC
NOTE:
• If DTC P1612 is displayed with DTC U1000 (for BC M), first perform the trouble diagnosis for DTC U1000.
Refer to BCS-63, "
DTC Logic".
• If DTC P1612 is displayed with DTC U1010 (for BC M), first perform the trouble diagnosis for DTC U1010.
Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check DTC in “Self Diagnostic Result” of “ENGINE” using CONSULT.
Is DTC detected?
YES >> Go to SEC-53, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430361
1.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Perform initialization of BCM and registration of al l Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
Does the engine start?
YES >> Inspection End.
NO >> GO TO 2.
2.REPLACE ECM
1. Replace ECM. Refer to EC-477, "
Removal and Installation".
2. Perform “ADDITIONAL SERVICE WHEN REPLACING ECM”. Refer to EC-125, "
Work Procedure".
>> Inspection End.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1612 CHAIN OF ECM-IMMU Inactive communication between ECM
and BCM. • Harness or connectors
(The CAN communication line is open or
shorted.)
•BCM
•ECM
Revision: August 2015 2016 Versa Note
cardiagn.com
SEC-54
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2192 ID DISCORD, IMMU-ECM
B2192 ID DISCORD, IMMU-ECM
DTC LogicINFOID:0000000012430362
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-54, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430363
1.PERFORM INITIALIZATION
Perform initialization of BCM and registration of all In telligent Keys using CONSULT. Refer to the CONSULT
Immobilizer mode and follow t he on-screen instructions.
Can the system be initialized and can the engine be started with registered Intelligent Key?
YES >> Inspection End.
NO >> GO TO 2.
2.CHECK SELF-DIAGNOSIS RESULT
1. Select “Self Diagnostic Result” of “BCM” using CONSULT.
2. Erase DTC.
3. Perform DTC CONFIRMATION PROCEDURE for DTC B2192. Refer to SEC-54, "
DTC Logic".
Is DTC detected?
YES >> GO TO 3.
NO >> Inspection End.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Perform initialization of BCM and registration of all Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
Can the system be initialized and can the engine be started with registered Intelligent Key?
YES >> Inspection End.
NO >> GO TO 4.
4.REPLACE ECM
1. Replace ECM. Refer to EC-477, "
Removal and Installation".
2. Perform “ADDITIONAL SERVICE WHEN REPLACING ECM”. Refer to EC-125, "
Work Procedure".
>> Inspection End.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B2192 ID DISCORD BCM-ECM The ID verification results between
BCM and ECM are NG.•BCM
•ECM
Revision: August 2015
2016 Versa Note
cardiagn.com
B2193 CHAIN OF ECM-IMMUSEC-55
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2193 CHAIN OF ECM-IMMU
DTC LogicINFOID:0000000012430364
DTC DETECTION LOGIC
NOTE:
• If DTC B2193 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to BCS-63, "
DTC Logic".
• If DTC B2193 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-55, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430365
1.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Perform initialization of BCM and registration of al l Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
Does the engine start?
YES >> Inspection End.
NO >> GO TO 2.
2.REPLACE ECM
1. Replace ECM. Refer to EC-477, "
Removal and Installation".
2. Perform “ADDITIONAL SERVICE WHEN REPLACING ECM”. Refer to EC-125, "
Work Procedure".
>> Inspection End.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B2193 CHAIN OF BCM-ECM Inactive communication between BCM
and ECM. • Harness or connectors
(The CAN communication line is open or
shorted.)
•BCM
•ECM
Revision: August 2015 2016 Versa Note
cardiagn.com
SEC-56
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2195 ANTI-SCANNING
B2195 ANTI-SCANNING
DTC LogicINFOID:0000000012430366
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Refer to SEC-56, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430367
1.CHECK SELF DIAGNOSTIC RESULT 1
1. Select “Self Diagnostic Result” of “BCM” using CONSULT.
2. Erase DTC.
3. Perform DTC CONFIRMATION PROCEDURE for DTC B2195. Refer to SEC-56, "
DTC Logic".
Is DTC detected?
YES >> GO TO 2.
NO >> Inspection End.
2.CHECK EQUIPMENT OF THE VEHICLE
Check that unspecified accessory part re lated to engine start is not installed.
Is unspecified accessory part related to engine start installed?
YES >> GO TO 3.
NO >> GO TO 4.
3.CHECK SELF DIAGNOSTIC RESULT 2
1. Obtain the customers approval to remove unspecified accessory part related to engine start, and then remove it.
2. Select “Self Diagnostic Result” of “BCM” using CONSULT.
3. Erase DTC.
4. Perform DTC CONFIRMATION PROCEDURE for DTC B2195. Refer to SEC-56, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> Inspection End.
4.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Perform initialization of BCM and registration of all Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
>> Inspection End.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B2195 ANTI-SCANNING ID verification between BCM and ECM that is
out of the specified specification is detected. ID verification request out of the
specified specification
Revision: August 2015
2016 Versa Note
cardiagn.com
B2196 DONGLE UNITSEC-57
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2196 DONGLE UNIT
DescriptionINFOID:0000000012430368
BCM performs ID verification between BCM and dongle unit.
When verification result is OK, BCM permits cranking.
DTC LogicINFOID:0000000012430369
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Turn ignition switch OFF.
3. Turn ignition switch ON.
4. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is the DTC detected?
YES >> Refer to SEC-57, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430370
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.PERFORM INITIALIZATION
1. Perform initialization of BCM and registration of all mechanical keys using CONSULT. For initialization and registration procedures, refe r to CONSULT Immobilizer mode and follow the on-
screen instructions.
2. Start the engine.
Dose the engine start?
YES >> Inspection End.
NO >> GO TO 2.
2.CHECK DONGLE UNIT CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector and dongle unit connector.
3. Check continuity between BCM harness connector and dongle unit harness connector.
4. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B2196 DONGLE NG The ID verification results between BCM
and dongle unit is invalid. • Harness or connectors
(Dongle unit circuit is open or shorted.)
• Dongle unit
BCM Dongle unit
Continuity
Connector TerminalConnector Terminal
M97 24M6 1Yes
BCM GroundContinuity
Connector Terminal
M97 24 No
Revision: August 2015 2016 Versa Note
cardiagn.com
SEC-58
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2196 DONGLE UNIT
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK DONGLE UNIT GROUND CIRCUIT
Check continuity between dongle unit harness connector and ground.
Is the inspection result normal?
YES >> Replace dongle unit.
NO >> Repair or replace harness.
Dongle unit
GroundContinuity
Connector Terminal
M6 4 Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
B2198 NATS ANTENNA AMP.SEC-59
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2198 NATS ANTENNA AMP.
DTC LogicINFOID:0000000012430371
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Make the conditions that BCM enters in the low power consumption mode (BCM sleep condition).
Refer to BCS-13, "
POWER CONSUMPTION CONTROL SY STEM : System Description".
2. Turn ignition switch ON.
3. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-59, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430372
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK FUSE
1. Turn power switch OFF.
2. Check that the following fuse in IPDM E/R is not blown.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the blown fuse after repairing the cause of blowing.
2.CHECK NATS ANTENNA AMP. POWER SUPPLY
1. Disconnect NATS antenna amp. connector.
2. Check voltage between NATS antenna amp. harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK NATS ANTENNA AMP. POWER SUPPLY CIRCUIT
1. Disconnect IPDM E/R connector.
2. Check continuity between IPDM E/R har ness connector and NATS antenna amp. connector.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B2198 NATS ANTENNA AMP Inactive communication between NATS
antenna amp. and BCM is detected when
BCM enters in the low power consumption
mode. (BCM sleep condition) • Harness or connectors
(NATS antenna amp. circuit is open or
shorted.)
• NATS antenna amp.
•BCM
Signal name Fuse No.
Battery power supply 53 (20 A)
(+)
(–)Voltage (V)
(Approx.)
NATS antenna amp.
Connector Terminal
M21 1GroundBattery voltage
Revision: August 2015 2016 Versa Note
cardiagn.com
