2016 NISSAN NOTE ESP

STC-8
< ECU DIAGNOSIS INFORMATION >
EPS CONTROL UNIT
ECU DIAGNOSIS INFORMATION
EPS CONTROL UNIT
Reference ValueINFOID:0000000012431945
VALUES ON THE DIAGNOSIS TOOL
CAUTION:
The output signal indicates the EPS control unit calculation data. The normal values will be displayed
even in the event that the output circuit (harness) is open.
*1: Almost in accordance with the value of “MOTOR S IG”. It is not a malfunction though these values are not
accorded when steering quickly.
*2: A fixed value is indicated regardless of steering turning.
*3: Normally displays 100%. In case of an excessive stat ionary steering, the assist curvature gradually falls.
However, it returns to 100% when left standing.
*4: It is not a malfunction, though it might not be co rresponding just after ignition switch in turned ON.
Monitor item Data monitor
Condition Display value
BATTERY VOLT Ignition switch: ON Battery voltage
TORQUE SENSOR Engine running Steering wheel: Not
steering (There is
no steering force) Approx. 0 Nm
Steering wheel: Right turn Positive value (Nm)
Steering wheel: Left turn Negative value (Nm)
MOTOR CURRENT Engine running Steering wheel: Not
steering (There is
no steering force) Approx. 0 A
Steering wheel: Right or left turn Displays consumption current of
EPS motor (A)
*1
MOTOR SIG
Engine runningSteering wheel: Not
steering (There is
no steering force) Approx. 0 A
Steering wheel: Right turn Positive value (A)
Steering wheel: Left turn Negative value (A)
ASSIST TORQUE Engine running Approx. 0 Nm
*2
C/U TEMPIgnition switch ON or engine running Displays temperature of inside of
EPS control unit (
°C or °F)
ASSIST LEVEL Engine running
100 %
*3
VEHICLE SPEEDVehicle stopped
0 km/h or mph
While driving Approximately equal to the indication
on speedometer*4
(inside of ±
10%)
WARNING LAMP EPS warning lamp: ON
On
EPS warning lamp: OFF Off
ENGINE STATUS Engine not running
Stop
Engine running Run
Revision: August 2015 2016 Versa Note

cardiagn.com

STRUCTURE AND OPERATIONTM-71
< SYSTEM DESCRIPTION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Mechanism
It is composed of a pair of pulleys (the groove width is changed freely in the axial direction) and the steel belt
(the steel plates are placed conti
nuously and the belt is guided with the multilayer steel rings on both sides).
The groove width changes according to wrapping radius of steel belt and pulley from low status to overdrive
status continuously with non-step. It is controlled with the oil pressures of primary pulley and secondary pulley.
Steel belt
It is composed of multiple steel plates (A) and two steel rings (B)
stacked to a several number. The feature of this steel belt transmits
power with compression of the steel plate in contrast with transmis-
sion of power in pulling with a rubber belt. Friction force is required
with the pulley slope to transmit power from the steel plate. The force
is generated with the following mechanism:
Oil pressure applies to the secondary pulley to nip the plate. ⇒The
plate is pushed and extended outward. ⇒The steel ring shows with-
stands. ⇒Pulling force is generated on the steel ring. ⇒ The plate of
the primary pulley is nipped between the pulley. ⇒Friction force is
generated between the steel belt and the pulley.
Therefore, responsibilities are divided by the steel plate that trans-
mits the power with compression and the steel ring that main tains necessary friction force. In this way, the
tension of the steel ring is distributed on the entire su rface and stress variation is limited, resulting in good
durability.
Pulley
The primary pulley (input shaft side) and the secondary pulley (output shaft side) have the shaft with slope
(fixed cone surface), movable sheave (movable cone surface that can move in the axial direction) and oil pres-
sure chamber at the back of the movable sheave.
Pulley gear shifting operation
• Pulley gear shifting operation The movable sheave slides on the shaft to change the groove width of the pulley. Input signals of engine
load (accelerator pedal opening), engine revolution and gear ratio (vehicle speed) change the operation
pressures of the primary pulley and the secondary pulle y, and controls the pulley groove width. Along with
change of the pulley groove width, the belt contact radi us is changed. This allows continuous and stepless
JSDIA1966ZZ
JSDIA1779GB
Revision: August 2015 2016 Versa Note

cardiagn.com

STRUCTURE AND OPERATIONTM-73
< SYSTEM DESCRIPTION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
TRANSAXLE : Oil Pressure System INFOID:0000000012431013
Oil pressure required for operation of the transaxle transmission mechanism is generated by oil pump, oil
pressure control valve, solenoid valve, etc.
TRANSAXLE : Component DescriptionINFOID:0000000012431014
JSDIA1826GB
Part name Function
Torque converter It is composed of the cover converter, turbine assembly, stator, pump impeller assem-
bly, etc. It increases the engine torque and transmits the power to the transaxle.
Oil pump Through the oil pump drive chain, it uses the vane oil pump driven by the engine. It gen-
erates necessary oil pressure to circulate fluid and to operate the clutch and brake.
Counter gear set The power from the torque converter is transmitted to the primary pulley through the
counter drive gear and the counter driven gear.
Belt & pulley (Continuously variable transmis-
sion) It is composed of the primary pulley, secondary pulley, steel belt, etc. and the mecha-
nism performs shifting, changes the gear ratio and transmits the power with oil pressure
from the control valve.
Auxiliary gearbox (stepped transmission) It is composed of the planetary gear, multi-disc clutch, multi-disc brake, etc. and the
mechanism performs shifting (1-2 gear shifting and reverse) with oil pressure from the
control valve.
Reduction gear set Conveys power from the transmission mechanism to the reduction gear and the final
gear.
Parking mechanism When the shift lever is changed to P position, the mechanism fixes the parking gear (in-
tegrated with the reduction gear) and the fixes the output shaft.
Control valve Controls oil pressure from the oil pump to the pressure suitable for the line pressure
control system, shift control system, lock-up control system and lubrication system.
Pressure regu lator valve Adjusts the discharge pressure from the oil pump to the optimum pressure (line pres-
sure) corresponding to the driving condition.
Torque converter regulator valve Adjusts the feed pressure to the torque converter to the optimum pressure correspond-
ing to the driving condition.
Pilot valve Adjusts line pressure and produces a constant pressure (pilot pressure) necessary for
activating each solenoid valve.
Revision: August 2015
2016 Versa Note

cardiagn.com

TM-74
< SYSTEM DESCRIPTION >[CVT: RE0F11A]
STRUCTURE AND OPERATION
FLUID COOLER & FL
UID WARMER SYSTEM
FLUID COOLER & FLUID WARMER SYSTEM : System DescriptionINFOID:0000000012431015
CVT FLUID COOLER SCHEMATIC
COMPONENT DESCRIPTION
CVT Oil Warmer
• The CVT oil warmer (1) is installed on the front part of transaxle
assembly.
• When engine is started while engine and CVT are cold, engine coolant temperature rises more quickly than CVT fluid tempera-
ture. CVT oil warmer is provided with two circuits for CVT and
engine coolant respectively so that warmed engine coolant warms
CVT quickly. This helps shorten CVT warming up time, improving
fuel economy.
• A cooling effect is obtained when CVT fluid temperature is high.
CVT Fluid Cooler (Water-cooling)
• The CVT fluid cooler (water-cooling) is installed in the radiator side tank (right side).
• CVT fluid is cooled by engine coolant.
SHIFT LOCK SYSTEM
Manual valve Distributes the clutch and brake operation pressures (pilot pressure) corresponding to
each shift position.
High clutch/reverse brake switching valve Switches the circuit for the high clutch and the reverse brake.
Torque converter clutch control valve It is operated with the torque converter clutch solenoid valve and it adjusts the tighten-
ing pressure and non-tightening pressure of the torque converter clutch piston of the
torque converter.
Primary pressure control valve It is operated with the primary pressure solenoid valve and adjusts the feed pressure to
the primary pulley.
Primary pressure solenoid valve TM-65, "
CVT CONTROL SYSTEM : Primary Pressure Solenoid Valve"
Low brake solenoid valve TM-65, "CVT CONTROL SYSTEM : Low Brake Solenoid Valve"
High clutch & reverse brake solenoid valveTM-66, "CVT CONTROL SYSTEM : High Clutch & Reverse Brake Solenoid Valve"
Torque converter clutch solenoid valve TM-66, "CVT CONTROL SYSTEM : Torque Converter Clutch Solenoid Valve"
Line pressure solenoid valve TM-66, "CVT CONTROL SYSTEM : Line Pressure Solenoid Valve"
Part name Function
JSDIA4074GB
JSDIA2586ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

STRUCTURE AND OPERATIONTM-75
< SYSTEM DESCRIPTION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SHIFT LOCK SYSTEM : System DescriptionINFOID:0000000012431016
The selector lever cannot be shifted from “P” position to any other position unless the ignition switch is in the
ON position and the brake pedal is depressed.
KEY LOCK SYSTEM
KEY LOCK SYSTEM : System DescriptionINFOID:0000000012431017
• The key lock mechanism also operates as a shift lock: With the ignition switch turned to ON, selector lever cannot be shifted from “P” position to any other position
unless brake pedal is depressed.
With the key removed, selector lever cannot be shifted from “P” position to any other position.
The key cannot be removed unless selector lever is placed in “P” position.
• The shift lock and key lock mechanisms are controlled by the ON-OFF operation of the shift lock solenoid and by the operation of the rotator and slider located inside key cylinder, respectively.
Revision: August 2015 2016 Versa Note

cardiagn.com

DIAGNOSIS SYSTEM (TCM)TM-97
< SYSTEM DESCRIPTION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
STRDWNSW (On/Off) ו Displays the operation status of the paddle shifter
(down switch).
• It is displayed although not equipped.
STRUPSW (On/Off) ו Displays the operation status of the paddle shifter (up
switch).
• It is displayed although not equipped.
DOWNLVR (On/Off) ו Displays the operation status of the selector lever
(down switch).
• It is displayed although not equipped.
UPLVR (On/Off) ו Displays the operation status of the selector lever (up
switch).
• It is displayed although not equipped.
NONMMODE (On/Off) ו Displays if the selector lever position is not at the man-
ual shift gate.
• It is displayed although not equipped.
MMODE (On/Off) ו Displays if the selector lever position is at the manual
shift gate.
• It is displayed although not equipped.
INDLRNG (On/Off) Displays the transmission status of the shift position (L
position) signal transmitted through CAN communica-
tion.
INDDRNG (On/Off) Displays the transmission status of the shift position (D
position) signal transmitted through CAN communica-
tion.
INGNRNG (On/Off) Displays the transmission status of the shift position (N
position) signal transmitted through CAN communica-
tion.
INGRRNG (On/Off) Displays the transmission status of the shift position (R
position) signal transmitted through CAN communica-
tion.
INGPRNG (On/Off) Displays the transmission status of the shift position (P
position) signal transmitted through CAN communica-
tion.
CVT LAMP (On/Off) Displays the transmission status of the OD OFF indicator
lamp signal transmitted through CAN communication.
SPORT MODE IND (On/Off) Displays the transmission status of the OD OFF indicator
lamp signal transmitted through CAN communication.
MMODE IND (On/Off) • Displays the transmission status of the manual mode
signal transmitted through CAN communication.
• It is displayed although not equipped.
VDC ON (On/Off) ו Displays the reception status of the VDC (ESP) oper-
ation signal received through CAN communication.
• It is displayed although not equipped.
TCS ON (On/Off) ו Displays the reception status of the TCS operation sig-
nal received through CAN communication.
• It is displayed although not equipped.
ABS FAIL SIGNAL (On/Off) ×Displays the reception status of the ABS malfunction sig-
nal received through CAN communication.
ABS ON (On/Off) ×Displays the reception status of the ABS operation signal
received through CAN communication.
RANGE ×Displays the gear position recognized by TCM.
M GEAR POS ×Display the target gear of manual mode
Monitored item
(Unit)Monitor item selection
Remarks
MAIN SIG-
NALS ECU IN-
PUT SIG-
NALS
Revision: August 2015 2016 Versa Note

cardiagn.com

TORQUE CONVERTER AND CONVERTER HOUSING OIL SEALTM-263
< UNIT DISASSEMBLY AND ASSEMBLY > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
UNIT DISASSEMBLY AND ASSEMBLY
TORQUE CONVERTER AND CO NVERTER HOUSING OIL SEAL
Exploded ViewINFOID:0000000012431226
DisassemblyINFOID:0000000012431227
1. Remove transaxle assembly. Refer to TM-259, "Removal and Installation".
2. Remove torque converter. CAUTION:
Never damage the bushing on the inside of to rque converter sleeve when removing torque con-
verter.
3. Remove converter housing oil seal using an oil seal remover (commercial service tool). CAUTION:
Be careful not to scratch converter housing.
AssemblyINFOID:0000000012431228
Note the followings and install in the reverse order of removal.
CAUTION:
• Never reuse converter housing oil seal.
• Apply CVT fluid to converter housing oil seal.
• Drive converter housing oil seal evenly using a drift (commercial
service tool) so that converter housing oil seal protrudes by the
dimension (A) respectively.
NOTE:
Converter housing oil seal pulling direction is used as the refer-
ence.
1. Torque converter 2. Converter housing oil seal3. Transaxle assembly
: Always replace after every disassembly.
: Genuine NISSAN CVT Fluid NS-3
JPDIA0837ZZ
Dimension (A) : 1.3 ±0.5 mm (0.051 ±0.02 in)
JPDIA0839ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com
