2016 MAZDA MODEL CX-9 Owners Manual (in English)

5–27
Interior Features
Audio Set
*Some models.
Favorites Radio
Selected stations can be registered for
convenient operation. Up to 50 stations
can be registered. The Favorites list is
common to AM, FM, and satellite radio.
Registering to Favorites
Long-press the
icon to register the
current radio station. The registration can
also be performed using the following
procedure.

1. Select the icon to display the
Favorites list.
2. Select
.
3. Select
.
4. The station is added to the bottom of
the Favorites list.
N O T E
If the battery is disconnected, your
Favorites list will not be deleted.

Selecting radio station from Favorites
1. Select the
icon to display the
Favorites list.
2. Select the radio frequency to tune in the
radio station.

Deleting from Favorites
1. Select the
icon to display the
Favorites list.
2. Select
.
3. Select
.
4. Select the radio frequency you want to
delete.
5. Select
.

Changing Favorites list order
1. Select the
icon to display the
Favorites list.
2. Select
.
3. Select
.
4. Select a radio frequency. The selected
radio station can be moved.
5. Slide the radio station or move it using
the commander switch, then select
.
Radio Broadcast Data System
(RBDS) *
Radio text information display
Radio text information sent from a
broadcasting station is displayed in the
center display.
N O T E
Radio text information is a function of FM
radio of FM radio only. There is no text
function on AM radio. Text information is
not displayed in the following:



y During reception



y Not an RBDS broadcast



y RBDS broadcast, but radio text is not
transmitted from the radio station

Genre Seek
Some FM stations transmit Genre codes
(Program type like Rock, News, and so
on). This code enables alternative stations
transmitting the same Genre code to be
found quickly.

(To scan for Genre Seek:)

1. Select the icon while in the FM
mode.
2. Select
to open the genre list.
3. Select the genre type you want to
select.
4. Select the
, icon.
$9@'%&"#@&EJUJPOJOEC


$9@'%&"#@&EJUJPOJOEC










5–28
Interior Features
Audio Set
N O T E
To change the desired genre, select the
icon.


Ex.)
89.3 is currently being received. With
Rock selected as the Genre, the radio
stations broadcasting Rock are at the
following frequencies.
98.3
*1 , 98.7, 104.3 *1 , 107.1
*1 Radio stations with good reception
The frequency changes as follows each
time
is pressed.
89.3
:98.3
:104.3
:98.3
N O T E




y Only one Genre can be selected.



y It may not be possible to receive any
station even if the Genre Seek function
is used.



y If a program in the selected genre is not
broadcast to a region, reception is not
possible even if the Genre Seek function
is used.



y The Genre Seek function searches for
genre code (program type) which FM
analog broadcasts transmit.

specialty programs (HD2-HD8) cannot
be searched because they are not FM
analog broadcasts.



y If radio stations which are selected by
scanning using the Genre Seek function
are
broadcasting stations,
they are changed from analog
broadcasts to
broadcasts
after a few seconds if the reception
conditions are good. The genre is
displayed after the switch, however, the
genre for FM analog broadcasts may
differ.

HD Radio
What is HD Radio™ Technology and
how does it work?
HD Radio™ Technology is the digital
evolution of analog AM/FM radio. Your
radio product has a special receiver which
allows it to receive digital broadcasts
(where available) in addition to the analog
broadcasts it already receives. Digital
broadcasts have better sound quality than
analog broadcasts as digital broadcasts
provide free, crystal clear audio. For more
information, and a guide to available radio
stations and programming, please visit
www.hdradio.com.
B e n e¿ ts of HD Radio™ Technology
(Information)
The song title, artist name, album name
and genre will appear on the screen when
available by the radio station.
(Multicast)
On the FM radio frequency most digital
stations have “multiple” or supplemental
programs on each FM station.
Listening to HD Radio™ Technology
I f
icon turns on by selecting a radio
station which is an
broadcasting
station, the analog broadcast is switched to
an
broadcast automatically after
a few seconds and then received.
If the
broadcast is stopped and
changed to an analog broadcast, press
down
to turn off .
Multicast channel selection (FM)
If multi-cast channels are available for an

broadcast currently being
received, the multi-cast channel list is
displayed. Select the desired radio station.
$9@'%&"#@&EJUJPOJOEC


$9@'%&"#@&EJUJPOJOEC










5–29
Interior Features
Audio Set
N O T E



y If an analog broadcast is received once
and
is received while HD1 is
selected, the audio unit switches to the

station automatically.


y When the icon is illuminated, there
could be a noticeable difference in
sound quality and volume when a
change from digital to analog signals
occurs. If the sound quality and volume
become noticeably diminished or cut
off, select the
icon to turn off

( icon is not illuminated).


y Once an analog broadcast is received
when HD1 is selected from the Favorite
channels, it is switched to

automatically. If the radio reception
conditions are poor, or HD is off,
switching to
broadcasts is
not possible.



y When an HD specialty channel (HD2 to
HD8) is selected from the Favorite
channels, “Signal Lost” is displayed
and no audio is output until

is received. If the radio reception
conditions are poor, “Signal Lost”
continues to be displayed.



y If the icon is not illuminated,
information such as song titles of the

station are received,
however, the audio output is analog.

iTunes Tagging (for Apple devices with
USB use only)
By tagging a song currently being aired,
the song can later be purchased from
the iTunes Store. One hundred tags
can be stored. A maximum of 100 tags
(for 100 songs) can be stored for later
downloading.

1. Select the icon. The tag is stored in
the audio unit.
2. Connect the device via the vehicle's
USB. Any stored tag(s) will be sent
automatically to the connected device.
3. Once at home or after parking the
vehicle safely, log onto the iTunes
Store with your device. Your previously
tagged song(s) can now be easily
purchased.

N O T E



y Both AM and FM can be
used.



y Because iTunes tagging only supports
purchases from the iTunes Store, direct
downloading of music from the vehicle's
audio unit is not possible.



y If the available memory for the
connected device is insuf¿ cient, the tag
is not sent.



y If an error occurs while the tag is being
sent, reconnect the device.

$9@'%&"#@&EJUJPOJOEC


$9@'%&"#@&EJUJPOJOEC










5–30
Interior Features
Audio Set
*Some models.
Operating the Satellite
Radio
*
What is satellite radio?
With over 130 channels, SiriusXM
Satellite Radio brings you more of what
you love. Get channels and channels of
commercial-free music, plus sports, news,
talk, entertainment and more.
Commercial-free music from nearly
every genre — rock to pop, hip-hop to
country, jazz, classical and more. Plus
live performances and artist-dedicated
channels.
Live sports Play-by-Play & Expert Talk
— every NFL game, every NASCAR
®
race, 24/7 sports talk, college sports and
more.
Exclusive entertainment, comedy and
talk — The biggest names, compelling
talk, hilarious comedy.
World-class news plus local traf¿ c and
weather.
Sign up for SiriusXM Satellite Radio
today!
N O T E



y To listen to SiriusXM, a prior
subscription (fee-based) is required.



y The channels which you can receive
depend on the package you subscribe
to.



y Satellite radio is broadcast as Sirius,
XM, and SiriusXM in the U.S.A.,
and Sirius and XM in Canada. In
this owner’s manual, only the name
SiriusXM is used.



y For traf¿ c and weather channels, map
information is not displayed and only
audio broadcasts can be received.
 y Call 877-447-0011 (U.S.A.)/
877-209-0079 (Canada) to activate.
For more information, visit www.
siriusxm.com (U.S.A.)/www.siriusxm.
ca (Canada). Satellite radio is only
available in regions providing satellite
radio service (some areas of the United
States and Canada). Contact Authorized
Mazda Dealer for details.

$9@'%&"#@&EJUJPOJOEC


$9@'%&"#@&EJUJPOJOEC










5–31
Interior Features
Audio Set
How to Activate Satellite Radio
You must call SiriusXM to activate your
service. Activation is free and takes only a
few minutes.
New customers can receive a free
introductory subscription with a limited
term trial offer by calling 877-447-0011
(U.S.A.)/877-209-0079 (Canada) to
activate.
SiriusXM service uses an ID code to
identify your radio. This code is needed to
activate SiriusXM service, and report any
problems.

Please have the following information
ready:
 y Radio ID (8-digit electronic serial No.)
Refer to Displaying the Radio ID (ESN)
on page 5-31 .




y Valid credit card information (may not
be required at initial sign-up)

Be sure you are parked outside with a clear
view of open sky, you will be instructed
to turn on your radio (in SiriusXM mode
and tuned to channel 184 (Sirius)/1 (XM
and SiriusXM)). Activation typically takes
only 2—5 minutes.
Displaying the Radio ID (ESN)
When channel 0 is selected, the radio ID is
displayed. Use the PREVIOUS or NEXT
channel buttons to select channel 0.
$9@'%&"#@&EJUJPOJOEC


$9@'%&"#@&EJUJPOJOEC










5–32
Interior Features
Audio Set
SiriusXM operation
Select the icon on the home screen to display the Entertainment screen. When is
selected, the following icons are indicated in the bottom part of the center display.

Icon Function

Displays the Entertainment menu. Use to switch to a different audio source.

Displays the channel list of the current category.

Displays the favorites list. Long-press to store the channel currently being aired.
Refer to Operating the Radio on page 5-26 .

Indicates that the parental lock function is in use.
Switching of Lock/Unlock and PIN code setting changes can be performed.

Plays each channel in the current channel list for 5 seconds.
Select again to continue receiving the channel.

Plays the previous channel.

Plays the next channel.

Displays sound settings to adjust audio quality level.
Refer to Volume/Display/Sound Controls on page 5-24 .

$9@'%&"#@&EJUJPOJOEC


$9@'%&"#@&EJUJPOJOEC










5–33
Interior Features
Audio Set
Selection from channel list
Receivable channels can be displayed on
the channel list screen. You can easily
select the channel you want to listen
from the list. Each category can be also
displayed.

1. Select the icon to display the
channel list.
2. Select a desired channel.

(Select from category list)
1. Select the
icon to display the
channel list.
2. Select
to display the category
list.
3. Select a desired category.

Parental lock
If a channel is locked, the channel is
muted.
To use the parental lock function, the PIN
code must be initialized ¿ rst.
By using the session lock, the parental
lock can be enabled or disabled during the
current drive cycle (from when the ignition
is switched on to switched off). When
the session lock is on, the parental lock is
available. When the session lock is off, the
parental lock is temporarily cancelled.
When canceling the parental lock or
session lock, or when changing the PIN
code, PIN code input is required.
PIN code reset
If the registered code has been forgotten,
reset the code to the default [0000] code.

1. Select the icon.
2. If the selected channel is locked, input
the PIN code to cancel the parental lock
temporarily.
3. Select
.
4. Input the default code [0000] using the
number buttons.
5. Select
.
6. Input the new PIN code using the
number buttons.
7. Select
.
$9@'%&"#@&EJUJPOJOEC


$9@'%&"#@&EJUJPOJOEC










5–34
Interior Features
Audio Set
How to use AUX mode
Playback
1. Select the icon on the home screen to display the Entertainment screen.
2. Select
to switch to the AUX mode. The following icons are displayed in the lower
part of the center display.

Icon Function

Displays the Entertainment menu. Use to switch to a different audio source.

Displays sound settings to adjust audio quality level.
Refer to Volume/Display/Sound Controls on page 5-24 .

N O T E



y If a device is not connected to the auxiliary jack, the mode does not switch to the AUX
mode.



y Adjust the audio volume using the portable audio device, commander switch, or audio
control switch.



y Audio adjustments can also be made using the portable audio device's volume setting.



y If the connection plug is pulled out from the auxiliary jack while in AUX mode, noise may
occur.

$9@'%&"#@&EJUJPOJOEC


$9@'%&"#@&EJUJPOJOEC
