2016 MAZDA MODEL CX-3 Owners Manual (in English)

8–39
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Examples: Based on a single occupant weight of 68 kg (150 lbs), and a value of 385 kg (849
lbs) for the “combination weight of occupants and cargo should never exceed”:
The cargo weight limit with one occupant is 385 kg (849 lbs) - 68 kg (150 lbs) = 317 kg
(699 lbs)
The cargo weight limit with two occupants is 385 kg (849 lbs) - (68 × 2) kg ( (150 × 2) lbs)
= 249 kg (549 lbs)
If the weight of the occupant increases, the cargo weight limit decreases by that much.
GAW (Gross Axle Weight) is the total weight placed on each axle (front and rear) -
including vehicle curb weight and all payload.
GAWR (Gross Axle Weight Rating) is the maximum allowable weight that can be carried
by a single axle (front or rear). These numbers are shown on the Safety Compliance
Certifi cation Label located on the driver's door frame or door pillar. The total load on
each axle must never exceed its GAWR.
GVW
GVW (Gross Vehicle Weight) is the Vehicle Curb Weight cargo passengers.
GVWR (Gross Vehicle Weight Rating) is the maximum allowable weight of the fully
loaded vehicle (including all options, equipment, passengers and cargo). The GVWR is
shown on the Safety Compliance Certifi cation Label located on the driver's door frame
or door pillar. The GVW must never exceed the GVWR.
$9@&)&"#@&EJUJPOJOEC


$9@&)&"#@&EJUJPOJOEC










8–40
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
SAMPLE
WARNING
Never Exceed Axle Weight Rating Limits:
Exceeding the Safety Certifi cation Label axle weight rating limits is dangerous and could
result in death or serious injury as a result of substandard vehicle handling, performance,
engine, transmission and/or structural damage, serious damage to the vehicle, or loss of
control.
Always keep the vehicle within the axle weight rating limits.
GCW
$9@&)&"#@&EJUJPOJOEC


$9@&)&"#@&EJUJPOJOEC










8–41
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
GCW (Gross Combination Weight) is the weight of the loaded vehicle (GVW).
GCWR (Gross Combination Weight Rating) is the maximum allowable weight of the
vehicle - including all cargo and passengers - that the vehicle can handle without risking
damage.The GCW must never exceed the GCWR.
WARNING
Never Exceed GVWR or GAWR Specifi cations:
Exceeding the GVWR or the GAWR specifi ed on the certifi cation label is dangerous.
Exceeding any vehicle rating limitation could result in a serious accident, injury, or
damage to the vehicle.
Do not use replacement tires with lower load carrying capacities than the originals
because they may lower the vehicle's GVWR and GAWR limitations. Replacement tires
with a higher limit than the originals do not increase the GVWR and GAWR limitations.
Never exceed the GVWR or the GAWR specifi ed on the certifi cation label.
$9@&)&"#@&EJUJPOJOEC


$9@&)&"#@&EJUJPOJOEC










8–42
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Steps for Determining the Correct Load Limit
Steps for Determining Correct Load Limit-
(1) Locate the statement “The combined weight of occupants and cargo should never exceed
XXX kg or XXX lbs.” on your vehicle's placard.
(2) Determine the combined weight of the driver and passengers that will be riding in your
vehicle.
(3) Subtract the combined weight of the driver and passengers from XXX kg or XXX lbs.
(4) The resulting fi gure equals the available amount of cargo and luggage load capacity. For
example, if the “XXX” amount equals 1400 lbs. and there will be fi ve 150 lb passengers
in your vehicle, the amount of available cargo and luggage load capacity is 650 lbs.
(1400 - 750 (5 × 150) = 650 lbs.)
(5) Determine the combined weight of luggage and cargo being loaded on the vehicle. That
weight may not safely exceed the available cargo and luggage load capacity calculated in
Step 4.
(6) If your vehicle will be towing a trailer, load from your trailer will be transferred to your
vehicle. Consult this manual to determine how this reduces the available cargo and
luggage load capacity of your vehicle.
$9@&)&"#@&EJUJPOJOEC


$9@&)&"#@&EJUJPOJOEC










8–43
Customer Information and Reporting Safety Defects
Declaration of Conformity
Declaration of Conformity
Keyless Entry System/Immobilizer System
$9@&)&"#@&EJUJPOJOEC


$9@&)&"#@&EJUJPOJOEC










8–44
Customer Information and Reporting Safety Defects
Declaration of Conformity
Blind Spot Monitoring (BSM) System
$9@&)&"#@&EJUJPOJOEC


$9@&)&"#@&EJUJPOJOEC










8–45
Customer Information and Reporting Safety Defects
Declaration of Conformity
Bluetooth ® Hands-Free
Type A
U.S.A. and Canada
FCC ID: CB2MBLUEC09 IC:279B-MBLUEC09
This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
WARNING
Changes or modifi cations not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
The term “IC: ” before the radio certifi cation number only signifi es that Industry Canada
technical specifi cations were met.
The antenna used for this transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter. End-users and installers must be provided with
installation instructions and transmitter operating conditions for satisfying RF exposure
compliance.
Mazda Bluetooth
® Hands-Free Customer Service



y U.S.A.
 Phone: 800-430-0153 (Toll-free)
 Web: www.MazdaUSA.com/bluetooth



y Canada
 Phone: 800-430-0153 (Toll-free)
 Web: www.mazdahandsfree.ca
$9@&)&"#@&EJUJPOJOEC


$9@&)&"#@&EJUJPOJOEC










8–46
Customer Information and Reporting Safety Defects
Declaration of Conformity
Mexico



y Brief description: Bluetooth module for Hands-free telephone and streaming audio



y Name and address of the importer: Refer to "MEXICO" (page 8-12 ) in Importer/
Distributor section.



y Brand name of the product: Johnson Controls Inc.



y Model name of the product: MAZ



y Names and addresses of where the warranty can be served: Refer to "MEXICO" (page
8-12 ) in Importer/Distributor section.



y Names and addresses of where to acquire spare parts, consumables and accessories: Refer
to "MEXICO" (page 8-12 ) in Importer/Distributor section.



y Warranty period, items covered by the warranty and its possible limitations or exceptions:
Refer to the Warranty Booklet for detailed warranty information.



y Warranty procedure:
 Center of Attention to Client (CAC)
 Phone: 01-800-01-MAZDA
 Web: www.mazdamexico.com.mx



y Electrical specifi cations:
 Voltage: 9-16V, Frequency: 2.4Ghz, Current: 270mA(Typ)
