2015 MITSUBISHI LANCER Owners Manual

Door locks 5-36 Features and controls
5
Turn the key toward the front of the vehicle to lock the door. After checking that the door islocked, turn the key back to the center and remove it.
Move the lock knob to the lock position to lock the door.All doors should be kept locked while driv- ing. The driver’s door can be unlocked without using the lock knob by pulling on the inside door handle. 1. Move the inside lock knob to the locked position.
2. Be sure the keys are not inside the vehi- cle. Close the door.
N00549600178
Ty p e 1
To lock or unlock the front doors with the key 1- Insert or remove the key 2- Lock 3- Unlock
To lock or unlock the door from the inside 1- Lock 2- Unlock To lock the door without using the key
Key reminder system When a key was used to start the engine
BK0210300US.bo
ok 36 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Power door locks
Features and controls 5-37
5
Type 2 If the ignition switch is turned off and the driver’s door is opened with the key in the ignition switch, the key reminder buzzer willsound intermittently to remind you to remove the key. The warning display will be displayed on theinformation screen in the multi-information display.
N00517300039
When you push the lock knob forward or lockthe door with the power door lock switch in both of the following conditions, the lockknob will automatically return to the unlocked position.  The key is in the ignition switch or the ignition switch is in the “ACC” or “ON”position. Driver’s door or front passenger door is opened.
N00503800121
Type 1 Type 2 If the driver’s door is opened while the igni- tion switch is in a position other than “LOCK” (PUSH OFF), the ignition switch return reminder buzzer will sound intermit-tently to remind you to return the ignition switch to the “LOCK” (PUSH OFF) position. The warning display will be displayed on theinformation screen in the multi-information display.
N00509300564
Lock out protection
Ignition switch return reminder system When the F.A.S.T.-key was used to start the engine
Power door locks
NOTE
 When locking or unlocking with the key on the driver’s door, only the driver’s door will lock or unlock.  Repeated continuous operation between lock and unlock could activate the power door locking systems built-in protection circuitand prevent the system from operating. If this occurs, wait about 1 minute before oper- ating the inside lock knob or the key.
BK0210300US.bo
ok 37 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Power door locks 5-38 Features and controls
5
All of the doors can be locked or unlocked by pressing the power door lock switch on the driver’s or the front passenger’s door.
Turn the key in the driver’s door lock once in the unlocking direction, and the driver’s doorwill be unlocked.
N00517701131
All doors will unlock when the ignitionswitch is turned to the “LOCK” position. All doors will unlock when the selector lever (CVT) or the gearshift lever (Twin Clutch SST) is moved to the “P” (PARK) position with the ignition switch in the “ON” position.
To lock and unlock the doors Using the power door lock switch 1- Lock 2- Unlock
Using the key 1- Insert or remove the emergency key.2- Lock 3- Unlock
To unlock the doors You can select either the function to unlockthe doors using the ignition switch position or the function to unlock the doors using the selector lever {continuously variable trans-mission (CVT)} position or the gearshift lever (Twin Clutch SST) position. These functions are not activated when thevehicle is shipped from the factory. To acti- vate or deactivate these functions, please contact your authorized Mitsubishi Motorsdealer.Using the ignition switch position Using the selector lever {continu- ously variable transmission (CVT)} position or the gearshift lever (Twin Clutch SST) position
BK0210300US.bo
ok 38 ページ ２０１４年４月８日　火曜日　午前１０時４６分

“Child safety locks” for rear door
Features and controls 5-39
5
N00509400190
Child safety locks help prevent rear passen- gers, especially children, from opening the rear door using the inside door handle. A lock lever for the child safety lock is pro- vided on each rear door. When the lever is in the lock position (1), therear door cannot be
opened using the inside
door handle. To open the rear door when the child safetylock lever is in the lock position, pull the out- side door handle. When the lever is in th
e release position (2),
the child safety lock is released and the rear
door can be opened using the inside door han- dle.
N00509501198
Ve h i c l e s w i t h C V TVehicles with Twin Clutch SST
“Child safety locks” for rear door 1- To lock 2- To release
WA R N I N G Always keep the doors tightly closed and locked when driving. An unlocked door may be accidentally opened by a passen-ger, especially by a child who could fall out. Also, if the doors are not locked, there is a greater risk of someone being thrownfrom the vehicle in an accident.
Trunk lid
WA R N I N G It is dangerous to drive with the trunk lid open since carbon monoxide (CO) gas canenter the cabin. CO is an invisible, odor- less gas that can cause unconsciousness and even death. Do not allow children to have access to the trunk, either by climbing into the trunkfrom outside or through the inside of the vehicle. Always clos
e the trunk lid when
your vehicle is unattended. If trapped in the trunk, it is possible to escape from the trunk by using the inside emergency trunkrelease lever. (See “Inside emergency trunk lid release” on page 5-41.)
BK0210300US.bo
ok 39 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Trunk lid 5-40 Features and controls
5
Insert the key and turn it clockwise. The trunk lid will pop up
slightly. Lift it to
open the trunk.
Press the trunk button (Vehicles with keyless entry system or F.A.S.T.-key) or OPENswitch (Vehicles with F.A.S.T.-key). (See “Keyless entry system” on page 5-7, 5-30 or “Free-hand Advanced Security Transmitter(F.A.S.T.-key)” on page 5-12.) The trunk lid will pop up to slightly. Lift it to open the trunk. Pull the trunk lid release lever, located to the left of the driver’s seat, up to open the trunk.
Pull the trunk lid downward as illustrated. Gently slam the trunk lid from the outside so
CAUTION Do not stand behind the exhaust pipe when loading and unloading luggage. Heat from the exhaust could lead to burns.
To open Operation from outside the vehicle Using the key (Vehicles with key cylin- der)
Using the remote control transmitter (Vehicles with keyless entry system or F. A . S . T. - k e y )
CAUTION Do not use the trunk lid release lever while the vehicle is moving. If the trunk lid is opened, objects in the trunk could fall onto the road and cause an accident.NOTE
 The trunk area light comes on when the trunk lid is opened, and goes out when it is closed.  The trunk area light remains illuminated for a certain period and then goes off automati- cally. Refer to “Interior light auto-cutoutfunction (dome light and other lights)” on page 5-187.
To close
BK0210300US.bo
ok 40 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Inside emergency trunk lid release
Features and controls 5-41
5
that it is completely closed. Always ensure the trunk lid is securely closed.
N00509800165
The emergency trunk lid release is designed to provide a way to open the trunk lid from inside the trunk. It was developed to help pre-vent death and serious injuries to children who might become locked inside a vehicle trunk. The emergency trunk lid release lever (see illustration) is mounted on the trunk lid. The lever glows in the dark after exposure to sunlight.
You and your family should familiarize your- selves with the location and operation of theemergency trunk lid release lever. Children should be taught not to play in or around vehicles.
CAUTION Be careful to prevent catching anyone’s fin- gers when closing the trunk lid. Before starting the vehicle, be sure to con- firm that the trunk lid is closed. If the trunklid opens while driving the vehicle, objects stored in the trunk could fall out onto the road.NOTE
 Gas struts (A) are installed in the locations illustrated to support the trunk lid. Please observe the following in order to preventdamage or faulty operation. • Do not touch, push or pull the gas struts when closing the trunk lid. • Do not attach any plastic material, tape, etc., to the gas struts.
• Do not tie string, etc., around the gas struts. • Do not hang any object on the gas struts.
Inside emergency trunk lid release
NOTE
WA R N I N G Children should never be left unsuper- vised in or around vehicles. Unsupervised children could lock them- selves in an open vehicle or trunk. People trapped inside a vehicle or trunk, even if only for a short period of time, canquickly die from suffocation or heat stroke, especially on hot days. Interior temperatures in vehicles can rise in min-utes. Keep your vehicle doors locked and the trunk lid closed when not in use. Keep your vehicle keys away from children.
BK0210300US.bo
ok 41 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Theft-alarm system 5-42 Features and controls
5
To open the trunk from the inside, move the lever (A) in the direction of the arrow on the lever. Push up on the trunk lid to open the trunk and climb out.
N00510200185
The theft-alarm system is designed to provideprotection from unauthorized entry into thevehicle. This system is operated in three stages: the first is the “armed” stage, the sec- ond is the “alarm” stage, and third is the “dis-armed” stage. If triggered, the system
provides both audible and visual alarm sig- nals.
N00510301183
Park the vehicle and stop the engine. Arm thesystem as described below. 1. Turn the ignition switch to the “LOCK” position. Also, if a key was used to start the engine,remove the key from the ignition switch. 2. Make sure that the trunk lid and engine hood are closed.3. Lock all doors by either the remote con- trol transmitter or the F.A.S.T.-key.
At this time, the theft-alarm indicator (A) on the audio panel flashes for confirma- tion. 4. The system has entered the armed stage after about 20 seconds, when the theft-alarm indicator (A) flashing becomes slower. The theft-alarm indicator (A) continues toflash while the system is in the armedstage.
CAUTION When loading the trunk, place your things so that they will not touch the emergency trunk lid release lever when you close the trunk. Otherwise you could damage the lever andmake it unusable.
Theft-alarm system
CAUTION Do not modify or add parts to the theft-alarm system. Doing so could cause the theft-alarm to malfunction.
Armed stage Arm the system and leave
NOTE
 If the engine hood or the trunk lid is open, the theft-alarm indicator (A) illuminates and the system cannot enter the armed stage. Thesystem enters the armed stage about 20 sec- onds after the engine hood or the trunk lid is closed.  The system will be disarmed if, while the theft-alarm indicator (A) is illuminated, alldoors are unlocked by remote control trans- mitter or the F.A.S.T.-key.
BK0210300US.bo
ok 42 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Theft-alarm system
Features and controls 5-43
5
N00510401197
The alarm will be activated if any of the fol- lowing occur while the vehicle is parked andthe system is armed.  One of the doors is opened without using the remote control transmitter or the F. A . S . T. - k e y. The engine hood or the trunk lid is opened.
When the alarm is activated: 1. The headlights blink on and off for 3 min- utes. After 3 minutes the headlights automati-cally shut off. 2. The horn will sound intermittently for 3 minutes.
Type 1
Type 2 The alarm can be deactivated in the following ways.  By using the remote control transmitter or the F.A.S.T.-key to lock or unlock the door. Turn the ignition switch to the “ON” posi- tion.
N00510501169
The system will be disarmed if the followingoperation is performed.  The ignition switch is turned to the “ON” position. All doors are unlocked by the remote con- trol transmitter or the F.A.S.T.-key.
 The system will be disarmed if, while the theft-alarm indicator is illuminated, the igni- tion switch is turned to the “ON” position.  The system will not be
armed if a door or the
trunk lid or the engine hood is not com- pletely closed. If this happens, rearm the sys- tem as described above.
Alarm stage Type of alarm
NOTE
NOTE
 The alarm will continue to operate for 3 min- utes. At the end of that period, the alarm will automatically shut off to save battery power. The system will then
be rearmed until the
proper disarming step is taken.  The alarm will resume if unauthorized actions are taken again, even if the alarm has stopped.  While the alarm is operating, a warning is displayed on the information screen in the multi-information display.
Horn sounds!Headlights blink on and off!
Alarm deactivation Disarmed stage
BK0210300US.bo
ok 43 ページ ２０１４年４月８日　火曜日　午前１０時４６分
