Refill capacities 11-6 Specifications
11
AYC fluid
For differential mech- anism
.58 qt (0.55 L) Mitsubishi Motors Genuine LSD gear oil
For torque transfer mechanism
.63 qt (0.6 L) MITSUBISHI
MOTORS Genuine ATF SP III
Brake/Clutch (if so equipped) As required Conforming to Brake fluid DOT3 or DOT4 Hood lock release mechanism and safety catch As required Multipurpose type grease NLGI Grade 2 Engine coolant
7.9 qt (7.5 L) {Includes .63 qt (0.65 L) in reserve tank}
Mitsubishi Motors Genuine Super Long Life Coolant Premium or equivalent
*
Washer fluid 4.3 qt (4.0 L) — Refrigerant (air conditioning)
Refer to the air conditioning label
on page 11-2.
HFC-134a
* : similar high quality ethylene glycol based non-silicate, non-a
mine, non-nitrate and non-borate coolant with long life hybrid o
rganic acid
technology
AYC: Active yaw control system LSD: Limited slip differential
