2015 LEXUS NX300h Owners Manual

1693-5. Opening, closing the windows and moon roof
3
Operation of each component
NX300h_U_OM78007UMoon roof 
Opens the moon roof Press and hold the “OPEN” switch. The
moon roof tilts up and then fully opens
automatically.
*Closes the moon roof Press and hold the “CLOSE” switch. The
moon roof fully closes automatically.
*
* : Lightly press either end of the moon roof
switch to stop the moon roof partway.
Tilts the moon roof up Press and hold the “UP” switch. It auto-
matically opens until the tilt up stop posi-
tion.
* Tilts the moon roof down Press and hold the “DOWN” switch.
The moon roof full close automatically.
*
* : Lightly press either end of the moon roof
switch to stop the moon roof partway.
 : If equippedUse the overhead switches to open and close the moon roof and tilt it up and
down.
Opening and closing 1
2
Tilting up and down 1
2

170 3-5. Opening, closing the windows and moon roof
NX300h_U_OM78007U ■
The moon roof can be operated when
The power switch is in ON mode. ■
Jam protection function
If an object is detected between the moon roof and the frame while the moon roof is clos-
ing or tilting down, travel is stoppe d and the moon roof opens slightly.■
Sunshade
The sunshade can be opened and closed manually. However, the sunshade will open
automatically when the moon roof is opened. ■
Door lock linked moon roof operation ●
The moon roof can be opened and closed using the mechanical key.
* (  P. 5 9 3 )●
The moon roof can be opened us ing the wireless remote control.
* (  P. 1 2 4 )
* : These settings must be cust omized at your Lexus dealer.■
When the moon roof does not close normally
Perform the following procedure: ●
If the moon roof closes but then re-opens slightly
Stop the vehicle.
Press and hold the “CLOSE” switch.
* 1
The moon roof will close, reopen and pause for approximately 10 seconds.
* 2
Then it
will close again and tilt down. Finally it will stop.
Check to make sure that the moon roof completely stops and then release the
switch. ●
If the moon roof tilts down but then tilts back up
Stop the vehicle.
Press and hold the “DOWN” switch.
* 1
The moon roof will close, reopen and paus e for approximately 10 seconds in the tilt
up position.
* 2
Then it will close again. Finally it will stop.
Check to make sure that the moon roof has completely stopped and then release
the switch.
* 1
: If the switch is released at the incorrec t time, the procedure will have to be per-
formed again from the beginning.
* 2
: If the switch is released after the above mentioned 10 second pause, automatic
operation will be disabled. In that case , perform the moon roof initialization by
referring to “When tilt up/down or moon roof opening and closing can be done but
automatic full opening and closing can not be done” on P. 171.
If the moon roof does not fully close even after performing the above procedure cor-
rectly, have the vehicle inspected by your Lexus dealer. 1
2
3
1
2
3

1713-5. Opening, closing the windows and moon roof
3
Operation of each component
NX300h_U_OM78007U ■
When the moon roof does not move normally
When the opening and closing operation or automatic opening function of the moon
roof does not move normally, perform the following initialization procedures.
Turn the power switch to ON mode.
Operate the moon roof.
The initialization method changes depending on the contents that can be operated. ●
If only the tilt up operations can be done when the moon roof is closed
Press and hold the “DOWN” or “CLOSE” switch.
Open until the tilt up stop position. After that the moon roof opens and completely
closes.
After that tilt up once again and stop at the completely closed position.
Confirm that moon roof has complete ly stopped and release the switch.●
If the moon roof can only be closed when the moon roof is partially opened
Press and hold the “DOWN” or “CLOSE” switch.
Fully close the moon roof, tilt up and open it close to the fully open position. After
that, fully close the moon roof and tilt up on ce again, then stop the moon roof in the
fully closed position.
Confirm that moon roof has complete ly stopped and release the switch.●
When tilt up/down or moon roof opening and closing can be done but automatic full
opening and closing can not be done
Press the “OPEN” switch and fully open.
Press the “CLOSE” switch and fully close.
Press the “UP” switch and tilt up until the tilt up stop position.
Press the “DOWN” switch and tilt down.
If the switch is released before any step is completes, the procedure will have to be per-
formed again from the beginning.
If the opening and closing operations or au tomatic opening function does not move as
normal, even after performing the above mentioned operations, have the vehicle
inspected by your Lexus dealer. ■
Moon roof open warning buzzer
The buzzer sounds and a message is shown on the multi-information display in the instru-
ment cluster when the power switch is turned off and the driver’s door is opened with the
moon roof open. ■
Customization
Setting (e.g. linked door lock operation) can be changed.
(Customizable features:  P. 6 3 3 ) 1
2
3
4
3
4
3
4
5
6

172 3-5. Opening, closing the windows and moon roof
NX300h_U_OM78007U WA R N I N G
Observe the following precautions.
Failing to do so may caus e death or serious injury.■
Opening the moon roof ●
Do not allow any passengers to put their hands or heads outside the vehicle while it is
moving. ●
Do not sit on top of the moon roof. ■
Closing the moon roof ●
The driver is responsible for moon roof opening and closing operations.
In order to prevent accidental operation, espe cially by a child, do not let a child oper-
ate the moon roof. It is possible for children and other passengers to have body parts
caught in the moon roof. ●
Check to make sure that all passengers do not have any part of their body in a posi-
tion where it could be caught when the moon roof is being operated. ●
When using the mechanical key and operat ing the moon roof, op erate the moon roof
after checking to make sure that there is no possibility of any passenger having any of
their body parts caught in the moon roof. Also, do not let a child operate moon roof
by the mechanical key. It is possible for ch ildren and other passengers to get caught in
the moon roof. ●
When exiting the vehicle, turn the power swit ch off, carry the key and exit the vehicle
along with the child. There may be accidental operation, due to mischief, etc., that
may possibly lead to an accident. ■
Jam protection function ●
Never use any part of your body to intentio nally activate the jam protection function.●
The jam protection function may not work if something gets caught just before the
moon roof fully closes.

173
4 Driving
NX300h_U_OM78007U 4-1. Before driving
Driving the vehicle ....................... 174
Cargo and luggage .................... 182
Vehicle load limits ....................... 186
Trailer towing (vehicles with
towing package) ....................... 187
Trailer towing (vehicles
without towing package) ...... 199
Dinghy towing............................. 200
4-2. Driving procedures
Power (ignition) switch.............. 201
EV drive mode ........................... 206
Hybrid transmission ................. 208
Turn signal lever ........................... 212
Parking brake ................................ 213
Brake hold ...................................... 216
ASC
(Active Sound Control) ......... 218
4-3. Operating the lights
and wipers
Headlight switch .......................... 219
Automatic High Beam .............223
Fog light switch............................ 227
Windshield wipers and
washer..........................................228
Rear window wiper and
washer..........................................234 4-4. Refueling
Opening the fuel tank cap ..... 236
4-5. Using the driving support
systems
Dynamic radar cruise
control ......................................... 240
Dynamic radar cruise
control with full-speed
range ............................................ 253
Cruise control ..............................267
LDA (Lane Departure Alert
with steering control) ............ 270
Intuitive parking assist .............. 279
Lexus parking assist
monitor ........................................ 287
Driving mode select
switch ...........................................303
Driving assist systems...............305
PCS
(Pre-Collision System)........... 310
BSM (Blind Spot Monitor) ...... 316
4-6. Driving tips
Hybrid vehicle driving
tips ................................................. 324
Winter driving tips ..................... 326
Utility vehicle precautions ......330

174 4-1. Before driving
NX300h_U_OM78007UDriving the vehicle  P. 2 0 1
With the brake pedal depressed, shift the shift lever to D. (  P. 2 0 8 )
Release the parking brake. (  P. 2 1 4 )If the parking brake is in automatic mode, the parking brake is released automatically
when shifting the shift lever to any position other than P. (  P. 2 1 3 )
Gradually release the brake pedal and gently depress the accelerator pedal
to accelerate the vehicle.
With the shift lever in D, depress the brake pedal.
If necessary, set the parking brake. (  P. 2 1 4 )If the vehicle is to be stopped for an extended period of time, shift the shift lever to P.
(  P. 2 0 8 )
With the shift lever in D, depress the brake pedal.
Shift the shift lever to P. (  P. 2 0 8 )
Set the parking brake. (  P. 2 1 4 )If the parking brake is in automatic mode, the parking brake is set automatically when
shifting the shift lever to P. (  P. 2 1 3 )
Press the power switch to stop the hybrid system.
Lock the door, making sure that you have the electronic key on your person. If parking on a hill, bloc k the wheels as needed.The following procedures should be observed to ensure safe driving:
Starting the hybrid system
Driving
Stopping
Parking the vehicle 1
2
3
1
2
1
2
3
4
5

1754-1. Before driving
4
Driving
NX300h_U_OM78007U With the brake pedal depressed, shift the shift lever to D. (  P. 2 0 8 )
Pull the parking brake switch and parking brake is set manually. (  P. 2 1 4 )
Release the brake pedal and gently depress the accelerator pedal to acceler-
ate the vehicle.
Press the parking brake switch and parking brake is released manually.
(  P. 2 1 4 ) ■
When starting off on a uphill
The hill-start assist co ntrol will activate. (  P. 3 0 5 )■
For fuel-efficient driving
Keep in mind that hybrid vehicles are similar to conventional vehicles, and it is necessary
to refrain from activities such as sudden acceleration. (  P. 3 2 4 )■
Driving in the rain ●
Drive carefully when it is raining, because visibility will be reduced, the windows may
become fogged-up, and th e road will be slippery.●
Drive carefully when it starts to rain, becau se the road surface will be especially slip-
pery. ●
Refrain from high speeds when driving on an expressway in the rain, because there may
be a layer of water between the tires and the road surface, preventing the steering and
brakes from operating properly. ■
Restraining the hybrid system output (Brake Override System) ●
When the accelerator and brake pedals are de pressed at the same time, the hybrid sys-
tem output may be restrained. ●
A warning message is displayed on the multi-information display while the system is
operating. If a warning message is shown on the multi-information display, read the
message and follow the instructions.■
Restraining sudden start (Drive-Start Control) ●
When the following unusual op eration is performed, the hybrid system output may be
restrained.
• When the shift lever is shifted from R to D, D to R, N to R, P to D, or P to R (D
includes S) with the accelerator pedal depressed, a warning message appears on
the multi-information display. If a warnin g message is shown on the multi-informa-
tion display, read the message and follow the instructions.
• When the accelerator pedal is depresse d too while the vehicle is in reverse.●
While Drive-Start Control is being activate d, your vehicle may have trouble escaping
from the mud or fresh snow. In such case, deactivate TRAC (  P. 307) to cancel Drive-
Start Control so that the vehicle may become able to escape from the mud or fresh
snow.Starting off on a uphill 1
2
3
4

176 4-1. Before driving
NX300h_U_OM78007U ■
Breaking in your new Lexus
To extend the life of the ve hicle, observing the followin g precautions is recommended:●
For the first 200 miles (300 km):
Avoid sudden stops. ●
For the first 1000 miles (1600 km):
• Do not drive at extremely high speeds.
• Avoid sudden acceleration.
• Do not drive continuously in low gears.
• Do not drive at a constant speed for extended periods. 
Vehicles with towing package ●
For the first 500miles (800 km):
Do not tow a trailer. ■
Operating your vehicle in a foreign country
Comply with the relevant vehi cle registration laws and confirm the availability of the cor-
rect fuel. (  P. 6 1 8 )■
Eco-friendly driving
 P. 1 0 0
WA R N I N G
Observe the following precautions.
Failure to do so may result in death or serious injury. ■
When starting the vehicle
Always keep your foot on the brake pedal while stopped with the “READY” indicator is
illuminated. This prevents the vehicle from creeping. ■
When driving the vehicle ●
Do not drive if you are unfamiliar with the location of the brake and accelerator ped-
als to avoid depressing the wrong pedal.
• Accidentally depressing th e accelerator pedal instead of the brake pedal will
result in sudden acceleration that may lead to an accident.
• When backing up, you may twist your body around, leading to difficulty in operat-
ing the pedals. Make sure to operate the pedals properly.
• Make sure to keep a correct driving posture even when moving the vehicle only
slightly. This allows you to depress th e brake and accelerator pedals properly.
• Depress the brake pedal using your righ t foot. Depressing the brake pedal using
your left foot may delay response in an emergency, resulting in an accident. ●
The driver should pay extra attention to pedestrians when the vehicle is powered only
by the electric motor (traction motor). As there is no engine noise, the pedestrians
may misjudge the vehicle’s movement. ●
Do not drive the vehicle over or stop the vehicle near flammable materials.
The exhaust system and exhaust gases can be extremely hot. These hot parts may
cause a fire if there is any flammable material nearby.
