2015 LEXUS NX300h Owners Manual

4175-11. Bluetooth ®
5
Lexus Display Audio system
NX300h_U_OM78007U WA R N I N G ■
While driving
Do not operate the portable audio player, cellular phone or connect a device to the
Bluetooth ®
system.■
Caution regarding interference with electronic devices ●
Your audio unit is fitted with Bluetooth ®
antennas. People with implantable cardiac
pacemakers, cardiac resynchronization ther apy-pacemakers or implantable cardio-
verter defibrillators should maintain a re asonable distance between themselves and
the Bluetooth ®
antennas. The radio waves may affect the operation of such devices.●
Before using Bluetooth ®
devices, users of any electrical medical device other than
implantable cardiac pacemakers, cardiac resynchronization therapy-pacemakers or
implantable cardioverter defibrillators shou ld consult the manufacturer of the device
for information about its operation under th e influence of radio waves. Radio waves
could have unexpected effects on th e operation of such medical devices.
NOTICE ■
When leaving the vehicle
Do not leave your portable audio player or cellular phone in the vehicle. The inside of
the vehicle may become hot, causing damage to the portable audio player or cellular
phone.

418 5-12. Other function
NX300h_U_OM78007U“Information” screen Go to “Information”: “MENU” button  “Info”
Display the fuel consumption.
(  P. 1 1 4 )
Display the “USB Photo” screen.
(  P. 4 2 0 )
Display the weather information.
(  P. 422)
Display the Traffic Map picture. Available when in a traffic supported
HD Radio coverage area
Go to “Traffic Map”: “MENU” button  “Info”  “Traffic Incidents”
Current position of your car
Traffic information line
The line color means the following:
Red: Heavy congestion
Yellow: Moderate traffic
Green: Free flowing trafficDisplay “Information” screen 1
2
3
4
Traffic information map 1
2

4195-12. Other function
5
Lexus Display Audio system
NX300h_U_OM78007U ■
Disclaimers

420 5-12. Other function
NX300h_U_OM78007UUSB photo Go to “USB Photo”: “MENU” button  “Info”  “USB1 Photo” or “USB2
Photo”
 P. 3 4 5
Move the controller to the left to display the menu screen.
Change the full screen mode.
Select to set the slide show display
on/off. Start the slide show at a selected folder.
Change the play speed.
Change the play mode.
Move the controller to the right and select “Browse”.
Select the desired folder, and then select a desired file to begin using the
selected folder.Connecting a USB memory device enables you to enjoy photo on the Lexus
Display Audio display.
USB photo screen
Connecting a USB memory device
Menu screen 1
2
3
4
Selecting a folder and a file 1
2

4215-12. Other function
5
Lexus Display Audio system
NX300h_U_OM78007U ■
USB memory functions
 P. 3 7 8 ■
USB memory ●
Compatible devices
USB memory device that can be used for JPEG display. ●
Compatible device formats
The following device format can be used:
• USB communication format: USB2.0 FS (480 Mbps)
• File system format: FAT16/32 (Windows)
• Correspondence class: Mass storage class ●
JPEG file compatibility
• Compatible image size: Maximum 10MB
• Compatible pixel size: Maximum 10,000,000 pixels
NOTICE ■
To prevent damage to the USB memory device or its terminals
 P. 3 8 0

422 5-12. Other function
NX300h_U_OM78007UWeather information Go to “Weather”: “MENU” button  “Info”  “Weather”
Select the desired city/location.
Current location of your car
Select of the recently checked loca-
tion list Select the desired location on the
recently checked location list.
Select of the National City list. Select the region on the region list and
then select the city on the National City
list.
Select of the local location list Select the location on th e local location list.
Select the time
Display the current weather infor-
mation.
Display the 3 days weather informa-
tion. You can display detail of a week, move
the controller right and then select the
desired week.
Display the 6/12 hour weather information.Weather information for the selected city is displayed.
Available when in weather supported HD Radio coverage area
How to check the weather information 1
2
1
2
3
4
3
1
2
3

4235-12. Other function
5
Lexus Display Audio system
NX300h_U_OM78007UVoice command system Press the talk switch. To cancel the voice command system,
press and hold the talk switch.
After a beep sounds, say the desired
command. On the list screen, you can select the
desired command.
■
Menu screen
To display the menu screen, move
the controller to the left.
Offer examples of commands
and operation methods
Adjust the settings for voice guid-
ance volume and voice recogni-
tion prompts. (“Hints” screen)
(  P. 3 5 1 )
Start over voice recognition (except “Hints” screen)
Cancel voice recognition ■
Microphone
 P. 3 9 3 ■
When using the microphone ●
It is unnecessary to speak directly into the microphone when giving a command.●
Wait for the confirmation beep before speaking a command.The voice command system enables the audio and hands-free systems to be
operated using voice commands.
Operations of the voice command system can be performed by selecting the
menu corresponding to each function on the right part of the screen. Even if
any menu is selected, commands displayed on all menus can be operated.
Using the voice command system 1
2
1
2
3
4

424 5-12. Other function
NX300h_U_OM78007U ●
Voice commands may not be recognized if:
• Spoken too quickly.
• Spoken at a low or high volume.
• The roof or windows are open.
• Passengers are talking while voice commands are spoken.
• The air conditioning speed is set high.
• The air conditioning vents are turned towards the microphone. ●
In the following conditions, the system ma y not recognize the command properly and
using voice commands may not be possible:
• The command is incorrect or unclear. No te that certain words, accents or speech
patterns may be difficult for the system to recognize.
• There is excessive background noise, such as wind noise. ■
When searching for a track ●
A USB memory or iPod must be connected to enable track searching and playback.
(  P. 3 4 5 ) ●
When a USB memory or iPod is connected, recognition data is created so tracks can
be searched using voice commands. ●
Recognition data is updated un der the following conditions:
• When the USB memory or iPod data has changed.
• When the voice recognition language is changed. (  P. 3 4 8 )●
While the recognition data is being created or being updated, a track search cannot be
performed using a voice command. ■
The Gracenote ®
media database
 P. 3 7 1
Due to natural language speech recognitio n technology, this system enables rec-
ognition of a command when spoken naturally. However, the system cannot rec-
ognize every variation of each command.
In some situations, it is possible to omit the command for the procedure and
directly state the desired operation.
This function is available in English, Spanish and French.Casual speech recognition
