2015 LEXUS NX300h Owners Manual

1453-2. Opening, closing and locking the doors
3
Operation of each component
NX300h_U_OM78007U ■
Certification for the smart access system with push-button start 
For vehicles sold in the U.S.A.
FCC ID: HYQ23AAB
FCC ID: HYQ14FBA
FCC ID: HYQ14CBB
FCC ID: NI4TMLF12-3
NOTE:
This device complies with part 15 of the FC C Rules. Operation is subject to the following
two conditions: (1) This device may not caus e harmful interference, and (2) this device
must accept any interference received, incl uding interference that may cause undesired
operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment. 
For vehicles sold in Canada
NOTE:
This device complies with Industry Canada licence-exempt RSS st andard(s). Operation
is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
WA R N I N G ■
Caution regarding interference with electronic devices ●
People with implantable cardiac pacemakers, cardiac resynchronization therapy-
pacemakers or implantable cardioverter de fibrillators should keep away from the
smart access system with pu sh-button start antennas. (  P. 1 4 0 )
The radio waves may affect the operation of such devices. If necessary, the entry
function can be disabled. Ask your Lexus dealer for details, such as the frequency of
radio waves and timing of the emitted radio waves. Then, consult your doctor to see if
you should disable the entry function. ●
Users of any electrical medical device other than implantable cardiac pacemakers,
cardiac resynchronization therapy-pacemakers or implantable cardioverter defibril-
lators should consult the ma nufacturer of the device for information about its opera-
tion under the influence of radio waves.
Radio waves could have unexpected effe cts on the operation of such medical
devices.
Ask your Lexus dealer for details on disabling the entry function.

146 3-3. Adjusting the seats
NX300h_U_OM78007UFront seats Seat position adjustment switch
Seat cushion (front) angle adjust-
ment switch
Vertical height adjustment switch
Seatback angle adjustment switch
Lumbar support adjustment switch
(for driver’s side) ■
Power easy access system
The driver’s seat and steering wheel move in accordance with power switch mode and
the driver’s seat belt condition. (  P. 1 5 4 )Adjustment procedure 1
2
3
4
5
WA R N I N G ■
When adjusting the seat position ●
Take care when adjusting the seat position to ensure that other passengers are not
injured by the moving seat. ●
Do not put your hands under the seat or near the moving parts to avoid injury.
Fingers or hands may become jammed in the se at mechanism.■
Seat adjustment
To reduce the risk of sliding under the lap belt during a co llision, do not recline the seat
more than necessary.
If the seat is too rec lined, the lap belt may slide past the hips and apply restraint forces
directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk
of death or serious injury in the event of an accident.
Adjustments should not be ma de while driving as the seat may unexpectedly move and
cause the driver to lose control of the vehicle.

1473-3. Adjusting the seats
3
Operation of each component
NX300h_U_OM78007URear seats 
Manual seat
Reclining adjustment 
Po w e r s e a t
Reclining adjustment (only rear seat switch)Adjustment procedure
1
1

148 3-3. Adjusting the seats
NX300h_U_OM78007U ■
Before folding down the rear seatbacks
Stow the rear center seat be lt and seat belt buckles. (  P. 3 4 )
Lower the head restraint of the rear seat. (  P. 1 5 8 )■
Folding down rear seatbacks (manual seat)
Pull the seatback angle adjustment
lever and fold down the seatback.
■
Folding down rear seatbacks (power seat)
Press and hold the switch to fold down the seatback.The buzzer sounds and operations start. Th e buzzer sounds again when the operation
is complete.
To stop the operation of a se at partway, press either seat operation switch for that
seat, once more. Switches for that seat in other locations can be used to stop the
operations. (buzzer sounds depending on stopping position of the seatback)Folding down the rear seatbacks 1
2

Instrument panel switch 
Rear seat switch
When the seatback is collapsed to the
rear, put the seatback in the most
upright position and press the switch
once again.

1493-3. Adjusting the seats
3
Operation of each component
NX300h_U_OM78007U ■
Returning the rear seatbacks (manual seat)
Raise the rear seatback until it
locks.
Check that the plate for the seat
belt is on the front side of the seat. 
Luggage room switch
1
2

150 3-3. Adjusting the seats
NX300h_U_OM78007U ■
Returning the rear seatbacks (power seat)
Press and hold the switch to return the seatback. The buzzer sounds and operations start. The buzzer sounds again when the oper-
ation is complete.
To stop the operation of a seat partway, press either seat operation switch for that
seat, once more. Switches for that seat in other locations can be used to stop the
operations. (buzzer sounds depending on stopping position of the seatback)
Check that the plate for the seat
belt is on the front side of the seat. 1
Instrument panel switch 
Rear seat switch
Luggage room switch
2

1513-3. Adjusting the seats
3
Operation of each component
NX300h_U_OM78007U ■
Operating conditions for reclining adjustment (power seat)
When the following conditions are me t, switch operations are possible.
■
Operating conditions for folding down the seatback (power seat)
When the following conditions are me t, switch operations are possible.
●
When operating the luggage compartment switch: When the back door is open. ●
When the operating switches for the seat to be operate are not being pressed.
When the power switch is in ON mode, in addition to the above, the power seat operates
for any of the following conditions:
• Parking brake is engaged
• The brake pedal is depressed
• The shift lever is in P ■
Operating conditions for return ing the seatback (power seat)
When the following conditions are me t, switch operations are possible.
●
When the operating switches for the seat to be operate are not being pressed.
When the power switch is in ON mode, in addition to the above, the power seat operates
for any of the following conditions:
• Parking brake is engaged
• The brake pedal is depressed
• The shift lever is in P ●
When the seatback position is within the range
of illustration A. ●
When the operating switches for the seat to be
operate are not being pressed. ●
When operating the rear seat switch: The
seatback position is with in the range of illustra-
tion A. ●
When operating the in strument panel switch
or luggage compartment switch: The seatback
position is within the range of illustration B. ●
When operating the rear seat switch: When
the rear door for the seat to be operated is
open.
●
When operating the rear seat switch: When
the seatback position is within the range of
illustration A. ●
When operating the rear seat switch: When
the rear door for the seat to be operated is
open. ●
When operating the luggage compartment
switch: When the back door is open. Most
upright
position
Most upright
position
Most
upright
position

152 3-3. Adjusting the seats
NX300h_U_OM78007U ■
Reclining adjustment (power seat)
■
Power seat operations (if equipped)
If the seat has a cover or seat cushion, it may not operate properly. Also, when folding
down the seat, check that there is nothing on the rear seat that would interfere with the
operation. ■
Seatback jam protection function (power seat)
When folding down the seatback, if a foreig n object is perceived between the seatback
and seat cushion, the seatback will revers e operations and then stops operations.
The buzzer sounds intermitte ntly during reverse operatio ns and sounds continuously
when operations are stopped.Stop the seatback partwa y. To set the seatback
to the rearmost position, press the button again.
WA R N I N G ■
When folding the rear seatbacks down and after folded
Observe the following precautions.
Failure to do so may result in death or serious injury.●
Do not fold the seatbacks down while driving. ●
Stop the vehicle on level ground, set the parking brake and shift the shift lever to P. ●
Do not allow anyone to sit on a folded se atback or in the luggage compartment while
driving. ●
Do not allow children to enter the luggage compartment. ■
When operating the seatback
Observe the following precautions.
Failure to do so may cause death or serious injury. ●
Keep other passengers from being hit with the seatback. ●
Do not bring your hands close to the moving parts or between the seats, as well as do
not let any part of your body get caught. ●
Vehicles with a power seat: Do not let children operate the seatback as other passen-
gers may get caught in seat. ●
Vehicles with a power seat: Check that there are no passengers sitting in the seat
before folding that seat forward. Also, do le t other passengers sit in the seat while the
seat is forward folding.
