2015 LEXUS NX300h Owners Manual

6419-2. Customization
9
Vehicle specifications
NX300h_U_OM78007U ■
Power back door
* 1
(  P. 1 2 9 )
* 1
: If equipped
* 2
: Configured by operating the switch of the lower back door. (  P. 1 3 2 
* 3
: While carrying the electronic key on your person, press the back door opener switch. ■
Vehicle customization ●
When the speed linked door locking functi on and shift position linked door locking
function are both on, the door lock operates as follows.
• When shifting the shift lever to any position other than P, all th e doors will be locked.
• If the vehicle is started with all the door s locked, the speed linked door locking func-
tion would not operate.
• If the vehicle is started with any door un locked, the speed linked door locking func-
tion will operate. ●
When the smart access system with push-but ton start is off, smart door unlocking can-
not be customized. ●
When the doors remain closed after unloc king the doors and the automatic door lock
function is activated, the signals will be generated in accordance with the Operation
signal (buzzer) and the Operation signal (emergency flashers) settings. ■
In the following situations, customize mo de in which the settings can be changed
through the multi-in formation display will automatically be turned off.●
A warning message appears after the cu stomize mode screen is displayed.●
The power switch is turned off. ●
The vehicle begins to move while the customize mode screen is displayed.Function Default
setting Customized
setting
Set at the desired Position
(height)
* 2
Back Door Automatic
Open and Stop Position Initial settings
Po s i t i o n Stop at the
desired position
(height) – – – O
5 step configuration
Back Door Automatic
Open and Stop Position 5 1 to 5 O – O –
Back door opener switch
operations When the back
door is locked
* 3
When the back
door is unlocked – – O –
Power back door operations On Off – O – – 1 2 3 4

642 9-2. Customization
NX300h_U_OM78007U WA R N I N G ■
Cautions during customization
As the hybrid system needs to be operating during customization, ensure that the vehi-
cle is parked in a place with adequate vent ilation. In a closed area such as a garage,
exhaust gases including harmful carbon mo noxide (CO) may collect and enter the
vehicle. This may lead to death or a serious health hazard.
NOTICE ■
During customization
To prevent 12-volt battery discharge, ensure that the hybrid syst em is operating while
customizing features.

6439-2. Customization
9
Vehicle specifications
NX300h_U_OM78007U

6439-3. Initialization
9
Vehicle specifications
NX300h_U_OM78007UItems to initialize
* : If equippedThe following items must be initialized for normal system operation after such
cases as the 12-volt battery being re connected, or maintenance being per-
formed on the vehicle. Item When to initialize Reference
Message indicating mainte-
nance is required (U.S.A. only) • After the maintenance is per-
formed P. 4 9 2
Tire pressure warning system • When rotating the tires on vehi-
cles with differing front and rear
tire inflation pressures
• When changing the tire inflation
pressure by changing traveling
speed or load weight, etc.
• When changing the tire size P. 5 1 8
Oil maintenance • After the maintenance is per-
formed P. 5 0 6
Power back door
* • After reconnecting or changing
the 12-volt battery
• After changing a fuse P. 1 3 4
Po w e r w i n d o w
• When functioning abnormally
normally P. 1 6 7
Moon roof
* P. 1 7 0

644 9-3. Initialization
NX300h_U_OM78007U

645
10 For owners
NX300h_U_OM78007U Reporting safety defects for
U.S. owners ............................................ 646
Seat belt instructions for
Canadian owners (in French) ........ 647
SRS airbag instructions for
Canadian owners (in French) ........ 649

646
NX300h_U_OM78007UReporting safety defects for U.S. owners If you believe that your vehicle has a defect which could cause a crash or could
cause injury or death, you should i mmediately inform the National Highway
Traffic Safety Administration (NHTSA) in addition to notifying the Lexus
Division of Toyota Motor Sales, U.S. A., Inc. (Toll-free: 1-800-25-LEXUS).
If NHTSA receives similar complaints, it may open an investigation, and if it
finds that a safety defect exists in a gr oup of vehicles, it may order a recall and
remedy campaign. However, NHTSA cannot become involved in individual
problems between you, your dealer, or Lexus Division of Toyota Motor Sales,
U.S.A., Inc.
To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at
1-888-327-4236 (TTY: 1-800-424-9153); go to
http://www.safercar.gov ; or
write to: Administrator, NHTSA, 1200 New Jersey Ave, S.E., Washington, DC
20590. You can also obtain other information about motor vehicle safety from
http://www.safercar.gov .

647
10
For owners
NX300h_U_OM78007USeat belt instructions for Canadian owners (in French)●
Déroulez la sangle diagonale de
telle sorte qu’elle passe bien sur
l’épaule, sans pour autant être en
contact avec le cou ou glisser de
l’épaule. ●
Placez la sangle abdominale le plus
bas possible sur les hanches. ●
Réglez la position du dossier de
siège. Asseyez-vous le dos le plus
droit possible et calez-vous bien
dans le siège. ●
Ne pas vriller la ceinture de sécurité. ■
Ceintures de sécurité
Nettoyez avec un chiffon ou une épon ge humectée d’eau savonneuse tiède.
Par ailleurs, vérifiez régulièrement que les ceintures ne sont pas effilochées,
entaillées, ou ne paraissent pas exagérément usées.The following is a French explanation of seat belt instructions extracted from
the seat belt section in this manual.
See the seat belt section for more deta iled seat belt instructions in English.
Utilisation correcte des ceintures de sécurité
Entretien et soin
