P0128 THERMOSTAT FUNCTIONEC-751
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Drive the vehicle under the conditions instructed bel
ow until the difference between “COOLAN TEMP/S” and
“FUEL T/TMP SE” becomes at least 24 °C (43 °F).
*: Example
- STEP 2
Drive the vehicle at 50 km/h (32 MPH) or more with the difference between “COOLAN TEMP/S” and “FUEL
T/TMP SE” maintained at 24 °C (43 °F) or more.
NOTE:
Keep the accelerator pedal as steady as possible during cruising.
- STEP 3
Drive the vehicle at 50 km/h (32 MPH) or more until “COOLAN TEMP/S” increases by 6 °C (11 °F).
NOTE:
Keep the accelerator pedal as steady as possible during cruising.
Is the condition satisfied?
YES >> GO TO 4.
NO >> GO TO 1.
4.PERFORM DTC CONFIRMATION PROCEDURE-II
With CONSULT
1. Drive the vehicle until the following condition is satisfied.
CAUTION:
Always drive vehicle at safe speed.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-751, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462622
1.CHECK ENGINE COOLANT TEMPERATURE SENSOR
Check engine coolant temperature sensor. Refer to EC-751, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace engine coolant temperature sensor.
2.CHECK THERMOSTAT
Check thermostat. Refer to CO-49, "Removal and Installation"
.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace thermostat. Refer to CO-49, "Removal and Installation"
.
Component InspectionINFOID:0000000009462623
1.CHECK ENGINE COOLANT TEMPERATURE SENSOR
COOLAN TEMP/S 65 °C (149 °F) or less
FUEL T/TMP SE Less than the value calculated by sub- tracting 24°C (43 °F) from “COOLAN
TEMP/S”.*
COOLAN TEMP/S FUEL T/TMP SE
70°C (158 °F) 46 °C (115 °F) or less
65 °C (149 °F) 41 °C (106 °F) or less
60 °C (140 °F) 36 °C (97 °F) or less
COOLAN TEMP/S 65 °C (149 °F) or more
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-752
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0128 THERMOSTAT FUNCTION
1. Turn ignition switch OFF.
2. Disconnect engine coolant temperature sensor harness connector.
3. Remove engine coolant temperature sensor. Refer to CO-51, "Removal and Installation"
.
4. Check resistance between engine coolant temperature sensor
terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace engine coolant temperature sensor. Refer to CO-51, "Removal and Installation"
.
ECT sensor
ConditionResistance
(kΩ)
+
−
Te r m i n a l
1 2 Temperature [ °C ( °F)] 20 (68) 2.37 - 2.63
50 (122) 0.68 - 1.00
90 (194) 0.236 - 0.260
JMBIA0080ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0130, P0150 A/F SENSOR 1EC-753
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0130, P0150 A/F SENSOR 1
DTC LogicINFOID:0000000009462624
DTC DETECTION LOGIC
To judge malfunctions, the diagnosis c
hecks that the A/F signal computed by ECM from the A/F sensor 1 sig-
nal fluctuates according to fuel feedback control.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 11 V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE FOR MALFUNCTION A
1. Start engine and warm it up to normal operating temperature.
2. Let engine idle for 2 minutes.
3. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-755, "Diagnosis Procedure".
NO-1 >> With CONSULT: GO TO 3.
NO-2 >> With GST: GO TO 7.
3.CHECK AIR FUEL RATIO (A/F) SENSOR 1 FUNCTION
1. Start engine and warm it up to normal operating temperature.
2. Select “A/F SEN1 (B1)” or “A/F SEN1 (B 2)” in “DATA MONITOR” mode with CONSULT.
3. Check “A/F SEN1 (B1)” or “A/F SEN1 (B2)” indication.
Does the indication fluctuate around 2.2 V?
YES >> GO TO 4.
NO >> Proceed to EC-755, "Diagnosis Procedure"
.
4.PERFORM DTC CONFIRMATION PR OCEDURE FOR MALFUNCTION B-I
1. Select “A/F SEN1 (B1) P1276” (for DTC P0130) or “A/F SEN1 (B2) P1286” (for DTC P0150) of “A/F
SEN1” in “DTC WORK SUPPORT” mode with CONSULT.
2. Touch “START”.
3. When the following conditions are met, “TESTING” will be displayed on the CONSULT screen.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0130 Air fuel ratio (A/F) sensor 1
(bank 1) circuit A)
The A/F signal computed by ECM from the A/F
sensor 1 signal is constantly in a range other
than approx. 2.2 V. • Harness or connectors
(The A/F sensor 1 circuit is open
or shorted.)
• A/F sensor 1
B) The A/F signal computed by ECM from the A/F
sensor 1 signal is constantly approx. 2.2 V.
P0150 Air fuel ratio (A/F) sensor 1
(bank 2) circuit A)
The A/F signal computed by ECM from the A/F
sensor 1 signal is constantly in a range other
than approx. 2.2 V. • Harness or connectors
(The A/F sensor 1 circuit is open
or shorted.)
• A/F sensor 1
B) The A/F signal computed by ECM from the A/F
sensor 1 signal is constantly approx. 2.2 V.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-754
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0130, P0150 A/F SENSOR 1
If “TESTING” is not displayed after 20 seconds, retry from step 2.
CAUTION:
Always drive vehicle at a safe speed.
Is
“TESTING” displayed on CONSULT screen?
YES >> GO TO 5.
NO >> Check A/F sensor 1 function again. GO TO 3.
5.PERFORM DTC CONFIRMATION PROCEDURE FOR MALFUNCTION B-II
Release accelerator pedal fully.
NOTE:
Never apply brake when releasing the accelerator pedal.
Which does
“TESTING” change to?
COMPLETED>>GO TO 6.
OUT OF CONDITION>>Retry DTC CONF IRMATION PROCEDURE. GO TO 4.
6.PERFORM DTC CONFIRMATION PROCEDURE FOR MALFUNCTION B-III
Touch “SELF-DIAG RESULT”.
Which is displayed on CONSULT screen?
OK >> INSPECTION END
NG >> Proceed to EC-755, "Diagnosis Procedure"
.
7.PERFORM COMPONENT FUNCTION CHECK FOR MALFUNCTION B
Perform component function check. Refer to EC-754, "Component Function Check"
.
NOTE:
Use component function check to check t he overall function of the A/F sensor 1 circuit. During this check, a
1st trip DTC might not be confirmed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-755, "Diagnosis Procedure"
.
Component Function CheckINFOID:0000000009462625
1.PERFORM COMPONENT FUNCTION CHECK
With GST
1. Start engine and warm it up to normal operating temperature.
2. Drive the vehicle at a speed of 80 km/h (50 MPH) for a few minutes in the suitable gear position.
3. Shift the selector lever to the D position, then re lease the accelerator pedal fully until the vehicle speed
decreases to 50 km/h (31 MPH).
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
Never apply brake when releasing the accelerator pedal.
4. Repeat steps 2 and 3 for 5 times.
5. Stop the vehicle and turn ignition switch OFF.
6. Wait at least 10 seconds and restart engine.
7. Repeat steps 2 and 3 for 5 times.
8. Stop the vehicle.
9. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-755, "Diagnosis Procedure".
NO >> INSPECTION END
ENG SPEED 1,000 - 3,200 rpm
VHCL SPEED SE More th an 64 km/h (40 mph)
B/FUEL SCHDL 1.0 - 10.0 msec
Selector lever D position
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0130, P0150 A/F SENSOR 1EC-755
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Diagnosis ProcedureINFOID:0000000009462626
1.CHECK AIR FUEL RATIO (A/F) SENSOR 1 POWER SUPPLY
1. Disconnect A/F sensor 1 harness connector.
2. Turn ignition switch ON.
3. Check the voltage between A/F sensor 1 harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK AIR FUEL RATIO (A/F) SENSOR 1 POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R harness connector.
3. Check the continuity between A/F sensor 1 harness connector and IPDM E/R harness connector.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
3.CHECK A/F SENSOR 1 IN PUT SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between A/F sensor 1 harness connector and ECM harness connector.
4. Check the continuity between A/F sensor 1 harness connector and ground, or ECM harness connector
and ground.
DTC A/F sensor 1
Ground Voltage
Bank Connector Terminal
P0130 1 F12 4 Ground Battery voltage
P0150 2 F61 4
DTC A/F sensor 1 IPDM E/R
Continuity
Bank Connector Terminal Connector Terminal
P0130 1 F12 4 F8352
Existed
P0150 2 F61 4 53
DTC A/F sensor 1 ECM
Continuity
Bank Connector Terminal Connector Terminal
P0130 1 F12 1
F79 69
Existed
273
P0150 2 F61 177
281
DTC A/F sensor 1
Ground Continuity
Bank Connector Terminal
P0130 1 F12 1
Ground Not existed
2
P0150 2 F61 1
2
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-756
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0130, P0150 A/F SENSOR 1
5. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK INTERMITTENT INCIDENT
Check intermittent incident. Refer to GI-43, "Intermittent Incident"
.
Is the inspection result normal?
YES >> Replace malfunctioning air fuel ratio (A/F) sensor 1. Refer to EM-152, "Removal and Installation
(LH)" or EM-153, "Removal and Installation (RH)".
NO >> Repair or replace error-detected parts.
DTC ECM
Ground Continuity
Connector Terminal
P0130 F79 69
Ground Not existed
73
P0150 77
81
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0131, P0151 A/F SENSOR 1EC-757
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0131, P0151 A/F SENSOR 1
DTC LogicINFOID:0000000009462627
DTC DETECTION LOGIC
To judge the malfunction, the diagnosis checks that the
A/F signal computed by ECM from the A/F sensor 1
signal is not inordinately low.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10.5 V at idle.
>> GO TO 2.
2.CHECK A/F SENSOR 1 FUNCTION
With CONSULT
1. Start engine and warm it up to normal operating temperature.
2. Select “A/F SEN1 (B1)” or “A/F SEN1 (B 2)” in “DATA MONITOR” mode with CONSULT.
3. Check “A/F SEN1 (B1)” or “A/F SEN1 (B2)” indication.
With GST
Follow the procedure “With CONSULT” above.
Is the indication constantly approx. 0 V?
YES >> Proceed to EC-758, "Diagnosis Procedure".
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Turn ignition switch OFF, wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF, wait at least 10 seconds and then restart engine.
4. Drive and accelerate vehicle to more than 40 km/h (25 MPH) within 20 seconds after restarting engine.
CAUTION:
Always drive vehicle at a safe speed.
5. Maintain the following conditions for approximately 20 consecutive seconds.
NOTE:
• Keep the accelerator pedal as steady as possible during cruising.
• If this procedure is not completed within 1 minute after restarting engine at step 1, return to step
1.
6. Check 1st trip DTC.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0131 Air fuel ratio (A/F) sensor 1
(bank 1) circuit low voltage • The A/F signal computed by ECM from the A/
F sensor 1 signal is constantly approx. 0 V. • Harness or connectors
(The A/F sensor 1 circuit is open or
shorted.)
• A/F sensor 1
P0151 Air fuel ratio (A/F) sensor 1
(bank 2) circuit low voltage
ENG SPEED 1,000 - 3,200 rpm
VHCL SPEED SE More than 40 km/h (25 mph)
B/FUEL SCHDL 1.5 - 9.0 msec
Selector lever Suitable position
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-758
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0131, P0151 A/F SENSOR 1
With GST
Follow the procedure “With CONSULT” above.
Is 1st trip DTC detected?
YES >> Proceed to EC-758, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462628
1.CHECK AIR FUEL RATIO (A/F) SENSOR 1 POWER SUPPLY
1. Disconnect A/F sensor 1 harness connector.
2. Turn ignition switch ON.
3. Check the voltage between A/F sensor 1 harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK AIR FUEL RATIO (A/F) SENSOR 1 POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R harness connector.
3. Check the continuity between A/F sensor 1 harness connector and IPDM E/R harness connector.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
3.CHECK A/F SENSOR 1 INPUT SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between A/F sensor 1 harness connector and ECM harness connector.
4. Check the continuity between A/F sensor 1 harness connector and ground, or ECM harness connector
and ground.
DTC A/F sensor 1
Ground Voltage
Bank Connector Terminal
P0131 1 F12 4 Ground Battery voltage
P0151 2 F61 4
DTC A/F sensor 1 IPDM E/R
Continuity
Bank Connector Terminal Connector Terminal
P0131 1 F12 4 F8352
Existed
P0151 2 F61 4 53
DTC A/F sensor 1 ECM
Continuity
Bank Connector Terminal Connector Terminal
P0131 1 F12 1
F79 69
Existed
273
P0151 2 F61 177
281
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
