EC-606
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
COOLING FANHI/MID/
LOW/OFF • The control condition of the cool-
ing fan (determined by ECM ac-
cording to the input signals) is
indicated.
HI: High speed operation
MID: Middle speed operation
LOW: Low speed operation
OFF: Stop
HO2S2 HTR (B1)
On/Off Indicates [On/Off] condition of heat-
ed oxygen sensor 2 heater deter-
mined by ECM according to the
input signals.
HO2S2 HTR (B2)
ALT DUTY SIG On/Off The control condition of the power
generation voltage variable control
(determined by ECM according to
the input signals) is indicated.
• On: Power generation voltage variable control is active.
• Off: Power generation voltage
variable control is inactive.
I/P PULLY SPD rpm Indicates the engine speed comput-
ed from the input speed sensor sig-
nal.
VEHICLE SPEED km/h or
mph The vehicle speed computed from
the vehicle speed signal sent from
TCM is displayed.
IDL A/V LEARN YET/
CMPLT Displays the condition of idle air vol-
ume learning
• Yet: Idle Air Volume Learning has not been performed yet.
• Cmplt: Idle Air Volume Learning
has already been performed suc-
cessfully.
TRVL AFTER MIL km or
mile Distance traveled while MIL is acti-
vated.
ENG OIL TEMP °C or °F The engine oil temperature (deter-
mined by the signal voltage of the
engine oil temperature sensor) is
displayed.
VHCL SPEED SE km/h or
mph The vehicle speed computed from
the vehicle speed signal sent from
combination meter is displayed.
SET VHCL SPD km/h or
mph • The preset vehicle speed is dis-
played.
MAIN SW On/Off Indicates [On/Off] condition from
MAIN switch signal.
CANCEL SW On/Off Indicates [On/Off] condition from
CANCEL switch signal.
RESUME/ACC SW On/Off Indicates [On/Off] condition from
RESUME/ACCELERATE switch sig-
nal.
SET SW On/Off Indicates [On/Off] condition from
SET/COAST switch signal.
Monitored item Unit
Monitor Item Selec-
tion
Description Remarks
ECU IN-
PUT SIG- NALS MAIN-
SIG-
NALS
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DIAGNOSIS SYSTEM (ECM)EC-607
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
BRAKE SW1 On/Off
Indicates [On/Off] condition from
brake pedal position switch signal or
ASCD clutch switch.
BRAKE SW2 On/Off Indicates [On/Off] condition of stop
lamp switch signal.
VHCL SPD CUT Non/
Cut • Indicates the vehicle cruise condi-
tion.
NON: Vehicle speed is maintained
at the ASCD set speed.
CUT: Vehicle speed decreased to
excessively low compared with
the ASCD set speed, and ASCD
operation is cut off.
LO SPEED CUT Non/
Cut • Indicates the vehicle cruise condi-
tion.
NON: Vehicle speed is maintained
at the ASCD set speed.
CUT: Vehicle speed decreased to
excessively low, and ASCD oper-
ation is cut off.
AT OD MONITOR On/Off • Indicates [On/Off] condition of
CVT O/D according to the input
signal from the TCM.
AT OD CANCEL On/Off • Indicates [On/Off] condition of
CVT O/D cancel request signal.
CRUISE LAMP On/Off Indicates [On/Off] condition of
CRUISE lamp dete rmined by the
ECM according to the input signals.
SET LAMP On/Off • Indicates [On/Off] condition of
SET lamp determined by the ECM
according to the input signals.
ALT DUTY % Indicates the duty ratio of the power
generation command value. The ra-
tio is calculated by ECM based on
the battery current sensor signal.
BAT CUR SEN mV The signal voltage of battery current
sensor is displayed.
A/F ADJ-B1
— Indicates the correction of a factor
stored in ECM. The factor is calcu-
lated from the difference between
the target air-fuel ratio stored in ECM
and the air-fuel ratio calculated from
A/F sensor 1 signal.
A/F ADJ-B2
P/N POSI SW On/Off ××Indicates [On/Off] condition from the
park/neutral position (PNP) signal.
INT/A TEMP SE °C or °F ×× The intake air temperature (deter-
mined by the signal voltage of the in-
take air temperature sensor) is
indicated.
AC PRESS SEN V The signal voltage from the refriger-
ant pressure sensor is displayed.
VTC DTY EX B2
*——
Monitored item Unit
Monitor Item Selec-
tion
Description Remarks
ECU IN-
PUT SIG- NALS MAIN-
SIG-
NALS
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-608
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
EVAP LEAK DIAGYe t / C m -
plt Indicates the condition of EVAP leak
diagnosis.
• YET: EVAP leak diagnosis has not been performed yet.
• CMPLT: EVAP leak diagnosis has
been performed successfully.
EVAP DIAG READY On/Off Indicates the ready condition of
EVAP leak diagnosis.
• On: Diagnosis has been ready
condition.
• Off: Diagnosis has not been ready condition.
BAT TEMP SEN V The signal voltage from the battery
temperature sensor is displayed.
THRTL STK CNT B1
*——
HO2 S2 DIAG1(B2) INCMP/
CMPLT Indicates DTC P0139 self-diagnosis
(delayed responce) condition.
• INCMP: Self-diagnosis is incom- plete.
• CMPLT: Self-diagnosis is com-
plete.
A/F SEN1 DIAG1(B2) INCMP/
CMPLT Indicates DTC P015C or P015D
self-diagnosis condition.
• INCMP: Self-diagnosis is incom-
plete.
• CMPLT: Self-diagnosis is com- plete.
A/F SEN1 DIAG1(B1) INCMP/
CMPLT Indicates DTC P015A or P015B self-
diagnosis condition.
• INCMP: Self-diagnosis is incom- plete.
• CMPLT: Self-diagnosis is com- plete.
A/F SEN1 DIAG2(B2) INCMP/
CMPLT Indicates DTC P014E or P014F self-
diagnosis condition.
• INCMP: Self-diagnosis is incom-
plete.
• CMPLT: Self-diagnosis is com- plete.
A/F SEN1 DIAG2(B1) INCMP/
CMPLT Indicates DTC P014C or P014D
self-diagnosis condition.
• INCMP: Self-diagnosis is incom- plete.
• CMPLT: Self-diagnosis is com- plete.
A/F SEN1 DIAG3(B2) ABSNT/
PRSNT Indicates DTC P014C, P014D,
P015A or P015B se lf-diagnosis con-
dition.
• ABSNT: The vehicle condition is not within the diagnosis range.
• PRSNT: The vehicle condition is within the diagnosis range.
Monitored item Unit
Monitor Item Selec-
tion
Description Remarks
ECU IN-
PUT SIG- NALS MAIN-
SIG-
NALS
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DIAGNOSIS SYSTEM (ECM)EC-609
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*: The item is indicated, but not used.
NOTE:
Any monitored item that does not match the vehicle being diagnosed is deleted from the display automatically.
WORK SUPPORT MODE
Work Item
A/F SEN1 DIAG3(B1)ABSNT/
PRSNT Indicates DTC P014C, P014D,
P015A or P015B self-diagnosis con-
dition.
• ABSNT: The vehicle condition is not within the diagnosis range.
• PRSNT: The vehicle condition is within the diagnosis range.
HO2 S2 DIAG2(B2) INCMP/
CMPLT Indicates DTC P0139 self-diagnosis
(slow responce ) condition.
• INCMP: Self-diagnosis is incom- plete.
• CMPLT: Self-diagnosis is com-
plete.
HO2 S2 DIAG2(B1) INCMP/
CMPLT Indicates DTC P0139 self-diagnosis
(slow responce ) condition.
• INCMP: Self-diagnosis is incom-
plete.
• CMPLT: Self-diagnosis is com- plete.
EOP SENSOR mV The signal voltage of EOP sensor is
displayed.
HO2 S2 DIAG1(B1) INCMP/
CMPLT Indicates DTC P0139 self-diagnosis
(delayed responce) condition.
• INCMP: Self-diagnosis is incom-
plete.
• CMPLT: Self-diagnosis is com- plete.
A/F-S ATMSPHRC
CRCT B1 — Displays a determined value of at-
mospheric correction factor neces-
sary for correcting an A/F sensor
signal input to ECM. The signal used
for the correction is an A/F sensor
signal transmitted while driving un-
der atmospheric pressure.
A/F-S ATMSPHRC
CRCT B2 — Displays a determined value of at-
mospheric correction factor neces-
sary for correcting an A/F sensor
signal input to ECM. The signal used
for the correction is an A/F sensor
signal transmitted while driving un-
der atmospheric pressure.
A/F-S ATMSPHRC
CRCT UP B1 count Displays the number of updates of
the A/F sensor atmospheric correc-
tion factor.
A/F-S ATMSPHRC
CRCT UP B2 count Displays the number of updates of
the A/F sensor atmospheric correc-
tion factor.
Monitored item Unit
Monitor Item Selec-
tion
Description Remarks
ECU IN-
PUT SIG- NALS MAIN-
SIG-
NALS
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-610
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
*: This function is not necessary in the usual service procedure.
ACTIVE TEST MODE
Test Item
WORK ITEM CONDITION USAGE
IDLE AIR VOL LEARN The idle air volume that keeps the engine within the specified range is memorized in ecm. When learning the idle air volume
EVAP SYSTEM CLOSE Close the EVAP canister vent control valve in order to make
EVAP system close under the following conditions.
• Ignition switch ON
• Engine not running
• Ambient temperature is above 0 °C (32 °F).
• No vacuum and no high pressure in EVAP system
• Fuel tank temperature is more than 0 °C (32 °F).
• Within 10 minutes after starting “EVAP SYSTEM CLOSE”
• When trying to execute “EVAP SYSTEM CLOSE” under
the condition except above, CONSULT will discontinue it
and display appropriate instruction.
NOTE:
When starting engine, CONSULT may display “BAT-
TERY VOLTAGE IS LOW. CHARGE BATTERY”, even in
using charged battery. When detecting EVAP vapor leak-
age in the EVAP system
FUEL PRESSURE RELEASE Fuel pu mp will stop by touching “START” during idling.
crank a few times after engine stalls. When releasing fuel pressure from
fuel line
SELF-LEARNING CONT The coefficient of self-learning control mixture ratio returns to the original coefficient. When clearing mixture ratio self-
learning value
TARGET IGN TIM ADJ* Idle condition When adjusting target ignition tim- ing
TARGET IDLE RPM ADJ* Idle condition When setting target idle speed
VIN REGISTRATION In this mode, VIN is registered in ECM When registering VIN in ECM
CLSD THL POS LEARN Ignition on and engine stopped. When learning the throttle valve
closed position
SAVING DATA FOR REPLC CPU In this mode, save data that is in ECM. When ECM replaced.
WRITING DATA FOR REPLC CPU In this mode, write data stored by “SAVING DATA FOR RE-
PLC CPU” in work support mode to ECM. When ECM replaced.
TEST ITEM CONDITION JUDGMENT CHECK ITEM (REMEDY)
FUEL INJEC-
TION • Engine: Return to the original
non-standard condition
• Change the amount of fuel injec- tion using CONSULT. If malfunctioning symptom disap-
pears, see CHECK ITEM. • Harness and connectors
• Fuel injector
• Air fuel ratio (A/F) sensor 1
ENG COOLANT
TEMP • Engine: Return to the original
non-standard condition
• Change the engine coolant tem- perature using CONSULT. If malfunctioning symptom disap-
pears, see CHECK ITEM. • Harness and connectors
• Engine coolant temperature sen-
sor
• Fuel injector
PURG VOL
CONT/V • Engine: After warming up, run en-
gine at 1,500 rpm.
• Change the EVAP canister purge volume control solenoid valve
opening percent using CON-
SULT. Engine speed changes according to
the opening percent. • Harness and connectors
• Solenoid valve
FUEL/T TEMP
SEN • Change the fuel tank temperature using CONSULT.
ALTERNATOR
DUTY •Engine: Idle
• Change duty ratio using CON-
SULT. Battery voltage changes.
• Harness and connectors
• IPDM E/R
•Alternator
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ECM
EC-613
< ECU DIAGNOSIS INFORMATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
ECU DIAGNOSIS INFORMATION
ECM
Reference ValueINFOID:0000000009462542
VALUES ON THE DIAGNOSIS TOOL
NOTE:
• The following table includes information (items) inapplicable to this vehicle. For information (items) applica- ble to this vehicle, refer to CONSULT display items.
• Numerical values in the following table are reference values.
• These values are input/output values that ECM receiv es/transmits and may differ from actual operations.
Example: The ignition timing shown by the timing light may differ from the ignition timing displayed on the
data monitor.
This occurs because the timing light shows a value calculated by ECM according to signals received from
the camshaft position sensor and other sensors related to ignition timing.
• For outlines of following items, refer to EC-601, "CONSULT Function"
.
Monitor Item Condition Values/Status
ENG SPEED Run engine and compare CONSULT value with the tachometer indication.Almost the same speed as
the tachometer indication.
MAS A/F SE-B1 See EC-701, "Description"
.
B/FUEL SCHDL See EC-701, "Description"
.
A/F ALPHA-B1 See EC-701, "Description"
.
A/F ALPHA-B2 See EC-701, "Description"
.
COOLAN TEMP/S Engine: After warming up More than 70 °C (158 °F)
A/F SEN1 (B1) Engine: After warming up Maintaining engine speed at 2,000 rpm Fluctuates around 2.2 V
A/F SEN1 (B2) Engine: After warming up Maintaining engine speed at 2,000 rpm Fluctuates around 2.2 V
HO2S2 (B1) Revving engine from idle to 3,000 rpm quickly after the following conditions are
met.
• Engine: After warming up
• After keeping engine speed between 3,500 and 4,000 rpm for 1 minute and at idle for 1 minute under no load 0 - 0.3 V
←→ Approx. 0.6 -
1.0 V
HO2S2 (B2) Revving engine from idle to 3,000 rpm quickly after the following conditions are
met.
• Engine: After warming up
• After keeping engine speed between 3,500 and 4,000 rpm for 1 minute and at
idle for 1 minute under no load 0 - 0.3 V
←→ Approx. 0.6 -
1.0 V
HO2S2 MNTR(B1) Revving engine from idle to 3,000 rpm quickly after the following conditions are
met.
• Engine: After warming up
• After keeping engine speed between 3,500 and 4,000 rpm for 1 minute and at idle for 1 minute under no load LEAN
←→ RICH
HO2S2 MNTR(B2) Revving engine from idle to 3,000 rpm quickly after the following conditions are
met.
• Engine: After warming up
• After keeping engine speed between 3,500 and 4,000 rpm for 1 minute and at idle for 1 minute under no load LEAN
←→ RICH
VHCL SPEED SE Turn drive wheels and compare CONSULT value with the speedometer indica-
tion. Almost the same speed as
speedometer indication
BATTERY VOLT Ignition switch: ON (Engine stopped) 11 - 14 V
ACCEL SEN 1 Ignition switch: ON
(Engine stopped) Accelerator pedal: Fully released 0.5 - 1.0 V
Accelerator pedal: Fully depressed 4.2 - 4.8 V
ACCEL SEN 2*
1Ignition switch: ON
(Engine stopped) Accelerator pedal: Fully released 0.5 - 1.0 V
Accelerator pedal: Fully depressed 4.2 - 4.8 V
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

E C -618
< ECU DIAGNOSIS INFORMATION >[VQ35DE]
ECM
*1: Accelerator pedal position sensor 2 signal and throttle
position sensor 2 signal are converted by ECM inter-
nally. Thus, they differ from ECM terminals voltage signal.
*2: Before measuring the terminal voltage, confir m that the battery is fully charged. Refer to PG-4, "How to
Handle Battery".
*3: The item is indicated, but not used.
TERMINAL LAYOUT
PHYSICAL VALUES
NOTE:
• ECM is located in the engine room left side near battery.
• Specification data are reference values.
• Pulse signal is measured by CONSULT.
EOP SENSOR • Engine: After warming up
• Selector lever: P or N
• Air conditioner switch: OFF
•No load Idle Approx. 1,450 mV
2,000 rpm Approx. 2,850 mV
HO2 S2 DIAG1(B1) DTC P0139 self-diagnosis (delayed response) has not been performed yet. INCMP
DTC P0139 self-diagnosis (delayed response) has already been performed suc-
cessfully. CMPLT
A/F-S ATMSPHRC
CRCT B1 Engine: After warming up, idle the engine Varies depending on vehicle
environment.
A/F-S ATMSPHRC
CRCT B2 Engine: After warming up, idle the engine
Varies depending on vehicle
environment.
A/F-S ATMSPHRC
CRCT UP B1 Engine: Running Varies depending on the
number of updates.
A/F-S ATMSPHRC
CRCT UP B2 Engine: Running Varies depending on the
number of updates.
Monitor Item Condition Values/Status
JSBIA0505ZZ
Terminal No. Description
ConditionVa l u e
(Approx.)
+ -– Signal name Input/
Output
1
(R) 128
(GR) Throttle contro
l motor power
supply Input [Ignition switch: ON] BATTERY VOLTAGE
(11 - 14 V)
2
(BG) 128
(GR) Throttle control mo
tor (Close) Output [Ignition switch: ON]
• Engine stopped
• Selector lever: D position
• Accelerator pedal: Fully re-
leased 0 - 14 V
JMBIA1125GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ECM
EC-619
< ECU DIAGNOSIS INFORMATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
3
(SB) 128
(GR) A/F sensor 1 heater (bank 2) Output [Engine is running]
• Warm-up condition
• Idle speed (More than 140 seconds after
starting engine) 2.9 - 8.8 V
4
(LG) 107
(P) Engine oil pressure sensor Input [Engine is running]
• Warm-up condition
• Idle speed 1.3 V
[Engine is running]
• Warm-up condition
• Engine speed is 2,000 rpm 2.7 V
5
(P) 128
(GR) Throttle control motor (Open) Output [Ignition switch: ON]
• Engine stopped
• Selector lever: D position
• Accelerator pedal: Fully de-
pressed 0 - 14 V
[Ignition switch: ON]
• Engine stopped
• Selector lever: D position
• Accelerator pedal: Fully re- leased 0 - 14 V
6
(BR) 128
(GR) A/F sensor 1 heater
(bank 1) Output[Engine is running]
• Warm-up condition
• Idle speed
(More than 140 seconds after
starting engine) 2.9 - 8.8 V
Terminal No. Description
ConditionVa l u e
(Approx.)
+ -– Signal name Input/
Output
JMBIA0030GB
JPBIA3359ZZ
JPBIA3360ZZ
JMBIA0031GB
JMBIA0032GB
JMBIA0902GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
