2014 NISSAN TEANA sensor

EC-636
< ECU DIAGNOSIS INFORMATION >[VQ35DE]
ECM
HO2S02H
Heated oxygen sensor 2
(Bank 1) P0138 07H 0CH
Minimum sensor output voltage for test
cycle
P0137 08H 0CH Maximum sensor output voltage for
test cycle
P0138 80H 0CH Sensor output voltage
P0139 81H 0CH Difference in sensor output voltage
P0139 82H 11H Rear O2 sensor delay response diag-
nosis
03H Heated oxygen sensor 3
(Bank 1) P0143 07H 0CH
Minimum sensor output voltage for test
cycle
P0144 08H 0CH Maximum sensor output voltage for
test cycle
P0146 80H 0CH Sensor output voltage
P0145 81H 0CH Difference in sensor output voltage
05H Air fuel ratio (A/F) sensor 1
(Bank 2) P0151 83H 0BH
Minimum sensor output voltage for test
cycle
P0151 84H 0BH Maximum sensor output voltage for
test cycle
P0150 85H 0BH Minimum sensor output voltage for test
cycle
P0150 86H 0BH Maximum sensor output voltage for
test cycle
P0153 87H 04H Response rate: Response ratio (lean
to rich)
P0153 88H 04H Response rate: Respon
se ratio (rich to
lean)
P2A03 or P2098 89H 84H The amount of shift in air fuel ratio (too
lean)
P2A03 or P2099 8AH 84H The amount of shift in air fuel ratio (too
rich)
P0150 8BH 0BH Difference in sensor output voltage
P0153 8CH 83H Response gain at the limited frequency
P014E 8DH 04H O2 sensor slow response - Rich to
lean bank 2 sensor 1
P014E 8EH 04H O2 sensor slow response - Rich to
lean bank 2 sensor 1
P014F 8FH 84H O2 sensor slow response - Lean to rich
bank 2 sensor 1
P014F 90H 84H O2 sensor slow response - Lean to rich
bank 2 sensor 1
P015C 91H 01H O2 sensor delayed response - Rich to
lean bank 2 sensor 1
P015C 92H 01H O2 sensor delayed response - Rich to
lean bank 2 sensor 1
P015D 93H 01H O2 sensor delayed response - Lean to
rich bank 2 sensor 1
Item
OBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ECM
EC-637
< ECU DIAGNOSIS INFORMATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
HO2S 05H
Air fuel ratio (A/F) sensor 1
(Bank 2) P015D 94H 01H
O2 sensor delayed response - Lean to
rich bank 2 sensor 1
P0153 95H 04H Response rate: Response ratio (lean
to rich)
P0153 96H 84H Response rate: Response ratio (rich to
lean)
06H Heated oxygen sensor 2
(Bank 2) P0158 07H 0CH
Minimum sensor output voltage for test
cycle
P0157 08H 0CH Maximum sensor output voltage for
test cycle
P0158 80H 0CH Sensor output voltage
P0159 81H 0CH Difference in sensor output voltage
P0159 82H 11H Rear O2 sensor delay response diag-
nosis
07H Heated oxygen sensor 3
(Bank2) P0163 07H 0CH
Minimum sensor output voltage for test
cycle
P0164 08H 0CH Maximum sensor output voltage for
test cycle
P0166 80H 0CH Sensor output voltage
P0165 81H 0CH Difference in sensor output voltage
CATA-
LY S T 21H
Three way catalyst function
(Bank1) P0420 80H 01H O2 storage index
P0420 82H 01H Switching time lag engine exhaust in-
dex value
P2423 83H 0CH Difference in 3rd O2 sensor output
voltage
P2423 84H 84H O2 storage index in HC trap catalyst
22H Three way catalyst function
(Bank2) P0430 80H 01H O2 storage index
P0430 82H 01H Switching time lag engine exhaust in-
dex value
P2424 83H 0CH Difference in 3rd O2 sensor output
voltage
P2424 84H 84H O2 storage index in HC trap catalyst
EGR
SYSTEM 31H EGR function P0400 80H 96H
Low flow faults: EGR temp change rate
(short term)
P0400 81H 96H Low flow faults: EGR temp change rate
(long term)
P0400 82H 96H Low flow faults: Difference between
max EGR temp and EGR temp under
idling condition
P0400 83H 96H Low flow faults: Max EGR temp
P1402 84H 96H High Flow Faults: EGR temp increase
rate
Item
OBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-638
< ECU DIAGNOSIS INFORMATION >[VQ35DE]
ECM
VVT
SYSTEM 35H VVT Monitor (Bank1)
P0011 80H 9DH
VTC intake function diagnosis (VTC
alignment check diagnosis)
P0014 81H 9DH VTC exhaust function diagnosis (VTC
alignment check diagnosis)
P0011 82H 9DH VTC intake function diagnosis (VTC
drive failure diagnosis)
P0014 83H 9DH VTC exhaust function diagnosis (VTC
drive failure diagnosis)
P100A 84H 10H VEL slow response diagnosis P1090 85H 10H VEL servo system diagnosis
P0011 86H 9DH VTC intake intermediate lock function
diagnosis (VTC intermediate position
alignment check diagnosis)
Advanced: P052A Retarded: P052B 87H 9DHVTC intake intermediate lock system
diagnosis (VTC intermediate lock posi-
tion check diagnosis)
36H VVT Monitor (Bank2) P0021 80H 9DH
VTC intake function diagnosis (VTC
alignment check diagnosis)
P0024 81H 9DH VTC exhaust function diagnosis (VTC
alignment check diagnosis)
P0021 82H 9DH VTC intake function diagnosis (VTC
drive failure diagnosis)
P0024 83H 9DH VTC exhaust function diagnosis (VTC
drive failure diagnosis)
P100B 84H 10H VEL slow response diagnosis P1093 85H 10H VEL servo system diagnosis
P0021 86H 9DH VTC intake intermediate lock function
diagnosis (VTC intermediate position
alignment check diagnosis)
Advanced: P052C Retarded: P052D 87H 9DHVTC intake intermediate lock system
diagnosis (VTC intermediate lock posi-
tion check diagnosis)
EVAP
SYSTEM 39H
EVAP control system leak
(Cap Off) P0455 80H 0CHDifference in pressure sensor output
voltage before and after pull down
3BH EVAP control system leak
(Small leak) P0442 80H 05H
Leak area index (for more than 0.04
inch)
3CH EVAP control system leak
(Very small leak) P0456 80H 05H
Leak area index (for more than 0.02
inch)
P0456 81H FDH Maximum internal pressure of EVAP
system during monitoring
P0456 82H FDH Internal pressure of EVAP system at
the end of monitoring
3DH Purge flow system P0441 83H 0CH Difference in pressure sensor output
voltage before and after vent control
valve close
Item
OBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ECM
EC-639
< ECU DIAGNOSIS INFORMATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
O2 SEN-
SOR
HEATER 41H A/F sensor 1 heater (Bank 1)
Low Input: P0031
High Input: P0032 81H 0BHConverted value of heater electric cur-
rent to voltage
42H Heated oxygen sensor 2 heat-
er (Bank 1) Low Input: P0037
High Input: P0038 80H 0CH
Converted value of heater electric cur-
rent to voltage
43H Heated oxygen sensor 3 heat-
er (Bank 1) P0043 80H 0CHConverted value of heater electric cur-
rent to voltage
45H A/F sensor 1 heater (Bank 2) Low Input: P0051
High Input: P0052 81H 0BHConverted value of heater electric cur-
rent to voltage
46H Heated oxygen sensor 2 heat-
er (Bank 2) Low Input: P0057
High Input: P0058 80H 0CH
Converted value of heater electric cur-
rent to voltage
47H Heated oxygen sensor 3 heat-
er (Bank 2) P0063 80H 0CHConverted value of heater electric cur-
rent to voltage
SEC-
OND-
ARY AIR 71H Secondary air system P0411 80H 01H
Secondary air injection system incor-
rect flow detected
Bank1: P0491
Bank2: P0492 81H 01H
Secondary air injection system insuffi-
cient flow
P2445 82H 01H Secondary air injection system pump
stuck off
P2448 83H 01H Secondary air injection system high
airflow
Bank1: P2440
Bank2: P2442 84H 01H
Secondary air injection system switch-
ing valve stuck open
P2440 85H 01H Secondary air injection system switch-
ing valve stuck open
P2444 86H 01H Secondary air injection system pump
stuck on
FUEL
SYSTEM 81H
Fuel injection system function
(Bank 1) P0171 or P0172 80H 2FH Long term fuel trim
P0171 or P0172 81H 24H The number of lambda control
clamped
P117A 82H 03H Cylinder A/F imbalance monitoring
82H Fuel injection system function
(Bank 2) P0174 or P0175 80H 2FH Long term fuel trim
P0174 or P0175 81H 24H The number of lambda control
clamped
P117B 82H 03H Cylinder A/F imbalance monitoring
Item
OBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-672
< BASIC INSPECTION >[VQ35DE]
DIAGNOSIS AND REPAIR WORKFLOW
• Perform Component Function Check if DTC CONFIR
MATION PROCEDURE is not included on Service
Manual. This simplified check procedure is an effect ive alternative though DTC cannot be detected during
this check.
If the result of Component Function Check is NG, it is the same as the detection of DTC by DTC CONFIR-
MATION PROCEDURE.
Is DTC detected?
YES >> GO TO 10.
NO >> Check according to GI-43, "Intermittent Incident"
.
6.PERFORM BASIC INSPECTION
Perform EC-675, "Work Procedure"
.
Do you have CONSULT?
YES >> GO TO 7.
NO >> GO TO 9.
7.PERFORM SPEC IN DATA MONITOR MODE
With CONSULT
Make sure that “MAS A/F SE-B1” , “MAS A/F SE-B2”, “B/FUEL SCHDL”, “A/F ALPHA-B1” and “A/F ALPHA-
B2” are within the SP value using CONSULT “SPEC” in “DATA MONITOR” mode of “ENGINE”. Refer to EC-
701, "Component Function Check".
Is the measurement value within the SP value?
YES >> GO TO 9.
NO >> GO TO 8.
8.DETECT MALFUNCTIONING PART BY TROUBL E DIAGNOSIS - SPECIFICATION VALUE
Detect malfunctioning part according to EC-702, "Diagnosis Procedure"
.
Is a malfunctioning part detected?
YES >> GO TO 11.
NO >> GO TO 9.
9.DETECT MALFUNCTIONING SYST EM BY SYMPTOM TABLE
Detect malfunctioning system according to EC-987, "Symptom Table"
based on the confirmed symptom in
step 4, and determine the trouble diagnosis order based on possible causes and symptoms.
>> GO TO 10.
10.DETECT MALFUNCTIONING PA RT BY DIAGNOSIS PROCEDURE
Inspect according to Diagnos is Procedure of the system.
NOTE:
The Diagnosis Procedure in EC section described based on open circuit inspection. A short circuit inspection
is also required for the circuit check in the Diagnosis Procedure. For details, refer to GI-46, "Circuit Inspec-
tion".
Is a malfunctioning part detected?
YES >> GO TO 11.
NO >> Monitor input data from related sensors or check voltage of related ECM terminals using CON-
SULT. Refer to EC-613, "Reference Value"
.
11 .REPAIR OR REPLACE THE MALFUNCTIONING PART
1. Repair or replace the malfunctioning part.
2. Reconnect parts or connectors disconnected during Diagnosis Procedure again after repair and replace-
ment.
3. Check DTC. If DTC is displayed, erase it.
With CONSULT: Refer to “How to Erase DTC and 1st Trip DTC” in EC-601, "CONSULT Function"
.
Without CONSULT: Refer to “How to Erase Self-diagnostic Results” in EC-598, "On Board Diagnosis
Function".
>> GO TO 12.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-676
< BASIC INSPECTION >[VQ35DE]
BASIC INSPECTION
2. Rev engine (2,000 to 3,000 rpm) 2 or 3 times under no load,
then run engine at idle speed for approximately 1 minute.
3. Check idle speed.
For procedure, refer to EC-992, "Work Procedure"
.
For specification, refer to EC-998, "Idle Speed"
.
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 4.
4.PERFORM ACCELERATOR PEDAL RE LEASED POSITION LEARNING
1. Stop engine.
2. Perform EC-681, "Work Procedure"
.
>> GO TO 5.
5.PERFORM THROTTLE VALVE CL OSED POSITION LEARNING
Perform EC-682, "Work Procedure"
.
>> GO TO 6.
6.PERFORM IDLE AIR VOLUME LEARNING
Perform EC-683, "Work Procedure"
.
Is Idle Air Volume Learning carried out successfully?
YES >> GO TO 7.
NO >> Follow the instruction of Idle Air Volume Learning. Then GO TO 4.
7.CHECK IDLE SPEED AGAIN
1. Start engine and warm it up to normal operating temperature.
2. Check idle speed.
For procedure, refer to EC-992, "Work Procedure"
.
For specification, refer to EC-998, "Idle Speed"
.
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 8.
8.DETECT MALFUNCTIONING PART
Check the Following.
• Check camshaft position sensor (PHASE) and circuit. Refer to EC-820, "Diagnosis Procedure"
.
• Check crankshaft position sensor (POS) and circuit. Refer to EC-817, "Diagnosis Procedure"
.
Is the inspection result normal?
YES >> GO TO 9.
NO >> Repair or replace malfunctioning part. Then GO TO 4.
9.CHECK ECM FUNCTION
1. Substitute with a non-malfunctioning ECM to check EC M function. (ECM may be the cause of the incident,
although this is rare.)
2. Perform initialization of NVIS (NAT S) system and registration of all NVIS (NATS) ignition key IDs. Refer to
SEC-66, "ECM : Work Procedure"
.
>> GO TO 4.
10.CHECK IGNITION TIMING
1. Run engine at idle.
2. Check ignition timing with a timing light.
For procedure, refer to EC-993, "Work Procedure"
.
PBIA8513J
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BASIC INSPECTIONEC-677
< BASIC INSPECTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
For specification, refer to
EC-998, "Ignition Timing".
Is the inspection result normal?
YES >> GO TO 19.
NO >> GO TO 11.
11 .PERFORM ACCELERATOR PEDAL RELEASED POSITION LEARNING
1. Stop engine.
2. Perform EC-681, "Work Procedure"
.
>> GO TO 12.
12.PERFORM THROTTLE VALVE CLOSED POSITION LEARNING
Perform EC-682, "Work Procedure"
.
>> GO TO 13.
13.PERFORM IDLE AIR VOLUME LEARNING
Perform EC-683, "Work Procedure"
.
Is Idle Air Volume Learning carried out successfully?
YES >> GO TO 14.
NO >> Follow the instruction of Idle Air Volume Learning. Then GO TO 4.
14.CHECK IDLE SPEED AGAIN
1. Start engine and warm it up to normal operating temperature.
2. Check idle speed.
For procedure, refer to EC-992, "Work Procedure"
.
For specification, refer to EC-998, "Idle Speed"
.
Is the inspection result normal?
YES >> GO TO 15.
NO >> GO TO 17.
15.CHECK IGNITION TIMING AGAIN
1. Run engine at idle.
2. Check ignition timing with a timing light. For procedure, refer to EC-993, "Work Procedure"
.
For specification, refer to EC-998, "Ignition Timing"
.
Is the inspection result normal?
YES >> GO TO 19.
NO >> GO TO 16.
16.CHECK TIMING CHAIN INSTALLATION
Check timing chain installation. Refer to EM-182, "Exploded View"
.
Is the inspection result normal?
YES >> GO TO 17.
NO >> Repair the timing chain installation. Then GO TO 4.
17.DETECT MALFUNCTIONING PART
Check the following.
• Check camshaft position sensor (PHASE) and circuit. Refer to EC-820, "Diagnosis Procedure"
.
• Check crankshaft position sensor (POS) and circuit. Refer to EC-817, "Diagnosis Procedure"
.
Is the inspection result normal?
YES >> GO TO 18.
NO >> Repair or replace malfunctioning part. Then GO TO 4.
18.CHECK ECM FUNCTION
1. Substitute with a non-malfunctioning ECM to check EC M function. (ECM may be the cause of the incident,
although this is rare.)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

ACCELERATOR PEDAL RELEASED POSITION LEARNINGEC-681
< BASIC INSPECTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
ACCELERATOR PEDAL RELEAS
ED POSITION LEARNING
DescriptionINFOID:0000000009462553
Accelerator Pedal Released Position Learning is a function of ECM to learn the fully released position of the
accelerator pedal by monitoring the accelerator pedal pos ition sensor output signal. It must be performed each
time the harness connector of the accelerator pedal position sensor or ECM is disconnected.
Work ProcedureINFOID:0000000009462554
1.START
1. Check that accelerator pedal is fully released.
2. Turn ignition switch ON and wait at least 2 seconds.
3. Turn ignition switch OFF and wait at least 10 seconds.
4. Turn ignition switch ON and wait at least 2 seconds.
5. Turn ignition switch OFF and wait at least 10 seconds.
>> END
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
