2013 VOLKSWAGEN PASSAT Owners Manual

Applicable only in the United States and Canada
Remote control vehicle keys

Fig. 20 Remote control vehicle key without remote start feature.

Fig. 21 Remote control vehicle key with remote start feature.

Replacement vehicle keys
The vehicle identification number is required to get a replacement key or an additional remote control
vehicle key.
Up to 8 vehicle keys, each of which must be properly cut, coded, programmed, and synchronized, can
be used with your vehicle.
Each new vehicle key contains a microchip and must be coded with the data from the vehicle's elec-
tronic immobilizer. A vehicle key will not work if it does not contain a microchip or contains a chip that
is not coded, even if the key bit was cut correctly.
You can obtain additional or duplicate remote control vehicle keys from authorized Volkswagen deal-
ers, authorized Volkswagen Service Facilities, and from certain independent repair facilities and lock-
smiths which are qualified to make remote control vehicle keys.
Each vehicle key must be programmed by an authorized Volkswagen dealer, an authorized
Volkswagen Service Facility in order for it to work with your vehicle.
To find the nearest qualified independent repair facility, locksmith, or Volkswagen dealer which can cut
and code replacement vehicle keys, call the VW Customer Care Hotline at 1-800-822-8987 or visit
http://www.vw.com and search for “replacement keys.”
Canadian customers can contact an authorized Volkswagen dealer or Volkswagen Service Facility or
call the Volkswagen Canada Customer CARE Center at (1-800-822-8987).
NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage,
moisture and rough handling.
Do not press the buttons on the remote control vehicle key unless you actually want to use the
function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle
key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you
are out of range.
Remote control vehicle key functions can be temporarily disrupted by interference from transmit-
ters near the vehicle that use the same frequency range (such as radio equipment or cellular phones).
Things between the remote control vehicle key and vehicle, bad weather, as well as a weak
battery can reduce the operating range.
If the remote control vehicle key buttons or the power locking buttons are pushed repeatedly in
quick succession, the power locking system is switched off for a brief period to help keep it from being
overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the luggage com-
partment lid is opened in this span of time, the vehicle is automatically locked afterwards.

Applicable only in the AGCC and South Korea
Remote control vehicle keys

Fig. 22 Remote control vehicle key.

Do not press the buttons on the remote control vehicle key unless you actually want to use the
function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle
key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you
are out of range.
Remote control vehicle key functions can be temporarily disrupted by interference from transmit-
ters near the vehicle that use the same frequency range (such as radio equipment or cellular phones).
Things between the remote control vehicle key and vehicle, bad weather, as well as a weak
battery can reduce the operating range.
If the remote control vehicle key buttons or the power locking are pushed repeatedly in quick
succession, the power locking system is switched off for a brief period to help keep it from being
overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the luggage com-
partment lid is opened in this span of time, the vehicle is automatically locked afterwards.
Applicable only in Mexico
Remote control vehicle keys

Fig. 23 Remote control vehicle key with panic button.

Panic button
Press the panic button (2) only in emergencies! After pushing the panic button, the horn will sound and
the turn signals will flash. Press the panic button again to switch off the panic feature.
Replacement vehicle keys
The vehicle identification number is required to get a replacement key or an additional remote control
vehicle key.
Up to 8 vehicle keys, each of which must be properly cut, coded, programmed, and synchronized, can
be used with your vehicle.
Each new vehicle key contains a microchip and must be coded with the data from the vehicle's elec-
tronic immobilizer. A vehicle key will not work if it does not contain a microchip or contains a chip that
is not coded, even if the key bit was cut correctly.
You can obtain additional or duplicate remote control vehicle keys from authorized Volkswagen deal-
ers and authorized Volkswagen Service Facilities.
Each vehicle key must be programmed by an authorized Volkswagen dealer or authorized
Volkswagen Service Facility in order for it to work with your vehicle.
NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage,
moisture and rough handling.
Do not press the buttons on the remote control vehicle key unless you actually want to use the
function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle
key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you
are out of range.
Remote control vehicle key functions can be temporarily disrupted by interference from transmit-
ters near the vehicle that use the same frequency range (such as radio equipment or cellular phones).
Things between the remote control vehicle key and vehicle, bad weather, as well as a weak
battery can reduce the operating range.
If the remote control vehicle key buttons or the power locking buttons are pushed repeatedly in
quick succession, the power locking system is switched off for a brief period to help keep it from being
overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the luggage com-
partment lid is opened in this span of time, the vehicle is automatically locked afterwards.

Applicable only in the United States, Canada, Mexico, and the AGCC
Valet parking key

Fig. 24 Valet parking key.

Fig. 26 Indicator light in the remote control vehicle key (version 2).

Replacing the remote control vehicle key battery

Fig. 28 Remote control vehicle key: Open battery compartment cover.

Fig. 29 Remote control vehicle key: Remove old battery.
