2013 VOLKSWAGEN PASSAT Owners Manual

HomeLink® Universal Transmitter
Applicable only in the United States and Canada

WARNING
Improper use of the HomeLink® Universal Transmitter can cause serious or even fatal per-
sonal injury.
x Garage doors operate with enough force to cause serious personal injury.
x Never let anyone get in the way of a garage door when it is opening or closing.
x When programming the HomeLink® Universal Transmitter, you may be operating a garage
door or estate gate. Always make sure that people and objects are out of the way to help
prevent serious personal injury or property damage.
x When operating the “training” button on a garage door opener with a rolling code, you will
need to stand on a ladder or step-stool. Always take extra precautions to prevent falls and
serious injury.
x Never use the HomeLink® Universal Transmitter with any garage door opener that does
not have the safety stop-and-reverse feature, as required by federal safety standards. This
includes any garage door opener model manufactured before April 1, 1982.
x A garage door opener that cannot detect an object, signaling the door to stop and reverse,
does not meet current federal safety standards. Using a garage door opener without these
features increases the risk of serious injury or death.
x Follow the installation manual and the included safety information from the manufacturer
when using the remote-controlled garage door opener or electrical drive.
Applicable only in the United States and Canada
Programming the HomeLink® Universal Transmitter

Fig. 50 In the driver side sun visor: The remote control and buttons for the HomeLink Universal Transmitter.

Fig. 51 To program: Simultaneously press the buttons for the HomeLink Universal Transmitter and the remote
control.

Please carry out each step only in the order specified:
5.
At the garage door opener receiver (overhead unit) in the garage, locate the “learn” or
“training” button. The name and color of the button may vary by manufacturer. This button
is usually located near the hanging antenna wire attachment point on the unit. If you cannot
locate the “training” button, refer to the garage door opener’s user manual.
6. Press and release the “training” button.
Once the button is pressed, you have 30 seconds to initiate the next step.
7. Return to the vehicle. Firmly press and hold the programmed HomeLink button for 2 se-
conds and release.
8. Repeat the “press/hold/release” sequence up to 3 times to complete the programming
process for that button.

Repeat the steps to program the other buttons for the HomeLink® Universal Transmitter on the sun
visor keypad to control other devices.
Deleting programming for all buttons
Be sure to delete programming on all buttons on the sun visor keypad before selling the vehicle or
turning it over to people you do not know.
x Complete the programming preparation steps described above.
x Press and hold buttons 1 and 3 at the same time, for about 20 seconds.
x When the indicator light above button 2 begins to flash, immediately release buttons 1 and 3 .
This step deletes all old settings.
After programming
Test the garage door opener, Operating the HomeLink® Universal Transmitter.
Applicable only in the United States and Canada
Operating the HomeLink® Universal Transmitter

DANGER
20 mm button cells and other lithium batteries will cause serious personal injury and even
death within a short time if swallowed.
x Always keep hand-held remote control devices with batteries, spare batteries, as well as
dead button cell and larger 20 mm batteries out of the reach of children.
x Get medical attention immediately if you suspect that a battery has been swallowed.
WARNING
Improper use of the HomeLink® Universal Transmitter can cause serious or even fatal per-
sonal injury.
x Garage doors operate with enough force to cause serious personal injury.
x Never let anyone get in the way of a garage door when it is opening or closing.
x When programming the HomeLink® Universal Transmitter, you may be operating a garage
door or estate gate. Always make sure that people and objects are out of the way to help
prevent serious personal injury or property damage.
x When operating the “training” button on a garage door opener with a rolling code, you will
need to stand on a ladder or step-stool. Always take extra precautions to prevent falls and
serious injury.
x Never use the HomeLink® Universal Transmitter with any garage door opener that does
not have the safety stop-and-reverse feature, as required by federal safety standards. This
includes any garage door opener model manufactured before April 1, 1982.
x A garage door opener that cannot detect an object, signaling the door to stop and reverse,
does not meet current federal safety standards. Using a garage door opener without these
features increases the risk of serious injury or death.
x Follow the installation manual and the included safety information from the manufacturer
when using the remote-controlled garage door opener or electrical drive.
NOTICE
The wrong batteries can damage the hand-held remote control. Replace a dead battery with
one that has the same voltage, size, and specifications.
Please dispose of old batteries properly and in an environmentally responsible manner. Always
keep them out of the reach of children.
Certain batteries used in hand-held remote controls are classified as Perchlorate Material.
Special handling may apply – see http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Obey all legal
requirements regarding proper disposal. Authorized Volkswagen dealers and authorized Volkswagen
Service Facilities are familiar with the requirements, and we recommend that you have them perform
this service for you.

Adjusting the seating position

WARNING
Always adjust seat, safety belts, and head restraints properly before driving and make sure
that all passengers are properly restrained.
x Push the passenger seat as far back as possible. Always be sure that there are at least
10 inches (25 cm) between the front passenger's breastbone and the instrument panel.
x Always adjust the driver's seat and the steering wheel so that there are at least 10 inches
(25 cm) between your breastbone and the steering wheel.
x Adjust the driver's seat so that you can easily push the pedals all the way to the floor
while keeping your knee(s) slightly bent. The distance to the instrument panel in the knee
area must be at least 4 inches (10 cm).
x If these requirements cannot be met for physical reasons, contact an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility to see whether adaptive
equipment is available.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands
at the 9 o'clock and 3 o'clock positions to help reduce the risk of personal injury if the driv-
er's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands at other places
inside the steering wheel rim or on the steering wheel hub. Holding the steering wheel the
wrong way can cause serious injuries to the hands, arms, and head if the driver's airbag in-
flates.
x Pointing the steering wheel toward your face decreases the ability of the driver's airbag to
help protect you in a collision.
x Never drive with backrests reclined or tilted back farther than necessary to drive comfort-
ably. The farther back the backrests are tilted, the greater the risk of injury caused by incor-
rect positioning of the safety belts and improper seating position.
x Never drive with the front seat passenger backrest tilted forward. If the front airbag de-
ploys, the front backrest can be forced backward and injure passengers on the rear seat.
x Sit as far back as possible from the steering wheel and the instrument panel.
x Always sit upright with your back against the backrest with the front seats properly ad-
justed. Never lean against or place any part of your body too close to the area where the air-
bags are located.
x Rear seat passengers who are not properly seated and restrained are more likely to be
seriously injured in a crash.
WARNING
Improper adjustment of the seats can cause accidents and severe injuries.
x Never adjust the seats while the vehicle is moving. Your seat may move unexpectedly and
you could lose control of the vehicle. In addition, you will not be in the correct seating posi-
tion while adjusting the seats.
x Adjust the front seat height, angle and longitudinal direction only if the seat adjustment
area is clear.
x The adjustment of the front seats must not be restricted by things in the footwell in front
or behind the seats.
Examples of improper seating positions

Not wearing or improperly fastening safety belts increases the risk of severe or fatal injuries. Safety
belts can work only when they are properly positioned on the body. An improper seating position
significantly impairs the protection provided by safety belts. This can cause severe or even fatal inju-
ries. Improper seating positions also increase the risk of serious injury or death when an airbag de-
ploys and strikes an occupant who is not in the proper seating position. The driver is responsible for all
passengers and especially children riding in the vehicle.
The following are only some examples of seating positions that will increase the risk of serious injury
or death.
Therefore, whenever the vehicle is moving:
x Never stand up in the vehicle.
x Never stand on the seats.
x Never kneel on the seats.
x Never ride with the seat backrest reclined.
x Never lean up against the instrument panel.
x Never lie down on the rear seat.
x Never sit on the edge of the seat.
x Never sit sideways.
x Never lean out the window.
x Never put your feet out the window.
x Never put feet on the instrument panel.
x Never rest your feet on the seat cushion or back of the seat.
x Never ride in the footwell.
x Never sit on the front or rear center armrest.
x Never ride without your safety belt properly fastened.
x Never ride in the luggage compartment.
WARNING
Contact with parts of the vehicle interior can cause serious personal injury in a crash.
x Always make sure that all vehicle occupants stay in a proper seating position and are
properly restrained whenever the vehicle is moving.
x Improper seating positions increase the risk of serious and fatal injury, especially when an
airbag deploys and strikes a passenger in an improper seating position.
