2013 VOLKSWAGEN PASSAT Owners Manual


Low beams off. Parking lights and DRL
stay on. The length of time they stay on
depends on the vehicle battery charge.
Low beams switched on.
Fog lights switched off. The DRL may
stay on for some time. Headlights and fog lights switched on.

Fog lights:
The indicator light shows that the front fog lights are switched on.
x To switch on the fog lights : first turn the light switch to position  or , and then pull the light
switch out to the first detent.
x To switch off the fog lights, push the switch back in from the first detent. To then turn off the head-
lights, turn the switch to position /.
Acoustic warning when lights are not switched off
In the following situations, a warning chime will sound if you take the key out of the ignition and open
the driver door. This is to remind you that lights are still on.
x Light switch in position  if the vehicle has no orientation lighting.
x Light switch in position .
WARNING
Daytime running lights and parking lights are not bright enough to let you see ahead or be
seen by others when it is dark.
x Always switch on the low-beam headlights at dusk or when it is dark and whenever the
weather is bad or visibility is poor.
x Never use the daytime running lights to see where you are going. They are not bright
enough and will not let you see far enough ahead for safety, especially at dusk or when it is
dark. Always switch on the low-beam headlights at dusk or when it is dark.
x The taillights do not come on with the daytime running lights. Unless the taillights are on,
a vehicle cannot be seen by others in bad weather, at dusk, or when it is dark.
x Even if automatic headlight control (!54/) is switched on, the low-beam headlights may still
not come on by themselves in fog or heavy rain. You have to switch on the low-beam head-
lights manually.
In cool or humid weather, the insides of the headlights, the taillights, and turn signals can tempo-
rarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in the United States
Lights and vision features

The daytime running lights are switched on whenever the ignition is switched on and the light switch is
in position / or !54/. The indicator light  or $2, in the instrument cluster indicates that the feature is
active.
If the light switch is in position !54/, a low-light sensor switches the instrument and switch lighting on
and off automatically.
Daytime running lights (DRL) parking feature
Some models are equipped with a daytime running lights (DRL) parking feature that switches the
daytime running lights off when the vehicle is parked and the ignition is switched on.

Function Action
Switching the DRL off: – Switch the ignition on.
– Turn the light switch to the O position.
– Set the parking brake.
Switching the DRL on: – Release the parking brake.

Static cornering lights
Your vehicle may have fog lights under the front bumper that are also static cornering lights. On some
models the static cornering lights may also be integrated in the headlights. At speeds below about
25 mph (40 km/h), the light on one side of the vehicle will come on automatically when you turn a
corner. If you turn to the right, the right fog light comes on; turn left and the left fog light comes on. The
light dims and goes out when the steering wheel is straightened out again.
When you move the selector lever to Reverse (R), the static cornering lights on both sides of the
vehicle may come on so that you can see the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. If you are using automatic headlight
control (headlight switch in the !54/ position ⇒ fig. 96), they work only when the headlights have been
automatically switched on. The static cornering lights do not come on when the headlight switch is in
the O position or when the fog lights themselves have been switched on.
Automatic headlight control (!54/)
Automatic headlight control is a convenience feature only and cannot always recognize all lighting and
driving situations.
If the light switch is in the !54/ position, both vehicle lighting and instrument and switch lighting are
automatically switched on and off in the following situations ⇒ :

Automatic activation: Automatic deactivation:
If the low-light sensor registers darkness, for
example when driving through a tunnel.
If sufficient brightness is registered.

WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-
beam headlights at dusk or when it is dark.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
x If automatic headlight control (!54/) is switched on, the low-beam headlights still may not
be switched on in fog or heavy rain. You have to switch on the low-beam headlights yourself.
In cool or humid weather, the insides of the headlights, rear lights, and turn signals can tempo-
rarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in Canada
Lights and vision features

Automatic activation: Automatic deactivation:
If the low-light sensor registers darkness, for
example when driving through a tunnel.
If sufficient brightness is registered.

WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-
beam headlights at dusk or when it is dark.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
x If automatic headlight control (!54/) is switched on, the low-beam headlights still may not
be switched on in fog or heavy rain. You have to switch on the low-beam headlights yourself.
In cool or humid weather, the insides of the headlights, rear lights, and turn signals can tempo-
rarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in Mexico, the AGCC, and South Korea
Lights and vision features

If the light switch is in the AUT O position, both vehicle lighting and instrument and switch lighting are
automatically switched on and off in the following situations ⇒ :

Automatic activation: Automatic deactivation:
If the low-light sensor registers darkness, for
example when driving through a tunnel.
If sufficient brightness is registered.
Vehicles without daytime running lights (DRL): if
you drive faster than 140 km/h (85 mph) for a few
seconds.
Vehicles without daytime running lights (DRL: if
you drive slower than 65 km/h (40 mph) for a few
minutes.

WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-
beam headlights at dusk or when it is dark.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
x If automatic headlight control (!54/) is switched on, the low-beam headlights still may not
be switched on in fog or heavy rain. You have to switch on the low-beam headlights yourself.
In cool or humid weather, the insides of the headlights, rear lights, and turn signals can tempo-
rarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
“Coming home” and “Leaving home” feature (orientation lighting)

“Leaving home” Action
Switch off: – Automatically after preset delay period is over.
– Lock the vehicle.
– Turn the light switch to the / position.
– Switch the ignition on.

The delay period can be adjusted and the function can be switched on and off in the Lights &
Vision menu ⇒ page 17.
If the “Coming home” feature is switched on and the driver door is opened, no warning chime will
sound to alert you that the lights are still on.
Instrument panel lighting

Fig. 98 To the left of the steering wheel: Control for instrument panel lighting.

Interior and reading lights

Sun protection
