2013 VOLKSWAGEN PASSAT Owners Manual

Applicable only in Mexico and the AGCC

WARNING
Even if empty, portable fuel containers can leak and cause a fire and serious personal
injuries, especially in a crash.
x For your safety, we strongly recommend that you do not travel with a portable fuel
container in your vehicle.
x If, under exceptional circumstances, you must transport a portable fuel container, please
observe the following:
– Never fill a portable fuel container while it is anywhere in or on the vehicle (for
example, in the luggage compartment or on top of the luggage compartment lid). Static
electricity can build up while filling and can ignite fuel vapors, causing a fire.
– Always place a portable fuel container on the ground before filling. Never spill fuel
inside the vehicle or luggage compartment. Fuel vapors are highly flammable.
– Always keep the filler nozzle completely inside the portable container before and
during filling.
– If filling a portable container made of metal, the filler nozzle must always be in contact
with the container. This will help prevent static electricity from discharging and causing a
fire.
– Always observe local and state or provincial laws about the use, storage, and
transportation of portable fuel containers.
– Make certain that the portable fuel container meets industry standards, such as ANSI /
ASTM F852-86.
NOTICE
x Remove fuel spills from the vehicle immediately to help prevent damage to the paint, tires,
and wheel housings.
x Refueling with gasoline when your vehicle has a diesel engine or refueling with diesel fuel
when your vehicle has a gasoline engine can cause very serious and expensive engine and
fuel system damage that is not covered by any Volkswagen Limited Warranty.
x If you put any amount of incorrect fuel in the fuel tank, do not start the engine under any
circumstances. Immediately contact the nearest authorized Volkswagen dealer or authorized
Volkswagen Service Facility for assistance. These fuels contain substances that can severely
damage the fuel system and the engine if the engine is started.
Fuels can pollute the environment. Spilled fuel must be collected and disposed of properly,
following all applicable environmental regulations.
There is no emergency release for the fuel filler flap. Contact an authorized Volkswagen dealer or
an authorized Volkswagen Service Facility for assistance.

Indicator lights and fuel gauge

Fig. 160 In the instrument cluster: Fuel gauge.

WARNING
Driving with a fuel tank that is almost empty can lead to stalling in traffic, a collision, and
serious personal injuries.
x When the fuel tank is almost empty, fuel supply to the engine can be interrupted,
especially when driving over bumps, across slopes, and up and down hills.
x Steering and braking assistance as well as ESC and related systems will not work if the
engine “sputters” or stalls due to lack of fuel.
x Always refuel when the tank is 1/4 full to reduce the risk of running out of fuel and stalling
in traffic.
NOTICE
x Failure to heed warning lights or text WARNINGS can result in vehicle damage.
x Never drive until the fuel tank is completely empty. The irregular fuel supply can cause the
engine to misfire. This allows unburned fuel to get into the exhaust system and damage the
catalytic converter or the diesel particulate filter.
The small arrow next to the gas pump symbol in the fuel gauge shows the side of the vehicle with
the fuel filler flap.
Misfueling guard for diesel vehicles

Fig. 163 With open fuel cap: Misfueling guard in the fuel filler neck.

slightly with light pressure to open the misfueling guard. If the misfueling guard cannot be opened this
way, see the nearest authorized Volkswagen dealer or authorized Volkswagen Service Facility and
have the fuel system checked.
WARNING
Spilled fuel can cause fires, explosions, burns, and other severe injuries.
x Do not refuel from devices other than correct, undamaged standard diesel fuel pump
nozzles.
x Always stop refueling once the pump nozzle switches off so that the tank does not
overflow.
NOTICE
x It is your responsibility to put the right fuel in your vehicle and any damage that results is
not covered under the Emissions warranties or any other Volkswagen Limited Warranty.
x If you put any amount of the incorrect fuel in the fuel tank, do not start the engine under any
circumstances. Immediately contact the nearest authorized Volkswagen dealer or authorized
Volkswagen Service Facility for assistance.
x If diesel fuel should get on any rubber hose, it must be wiped off immediately. The same
applies if diesel fuel gets onto other parts of the vehicle, especially paint, tires, or a plastic
part. Wash the contaminated vehicle parts right away with soap and warm water to help
prevent leaks and serious damage.
x Never force a fuel nozzle in the misfueling guard. If you have problems inserting a fuel
nozzle, first check to make sure you are using the correct diesel fuel. If you are, go to a pump
with the standard diesel nozzle. Forcing a fuel nozzle in the misfueling guard can damage it so
that it can no longer help prevent misfueling.
Applicable only in Mexico and the AGCC
Fuel capacities

Refueling checklist

Fuel

Fuel grades Alternative designations Further information
RON7 91 Regular unleaded gasoline
RON7 95 Premium unleaded gasoline 95
RON7 98 Super plus unleaded gasoline 98

Applicable only in Mexico, the AGCC, and South Korea
Gasoline additives
