2013 VOLKSWAGEN PASSAT Owners Manual

Applicable only in the United States and Canada
Proper seating position

Fig. 52 The driver should never sit closer than 10 inches (25 cm) of the steering wheel.

Fig. 53 Proper safety belt positioning and head restraint adjustment.

x Tall people should pull the head restraint all the way up.
x Adjust the seat backrest angle to an upright position so that your back is in full contact with it when
the vehicle is moving.
x Always keep both feet on the floor and in the footwell whenever the vehicle is moving.
x Always adjust and fasten safety belts properly.
Driver - Seat and steering wheel adjustment:
x Adjust the steering wheel so that there are at least 10 inches (25 cm) between the steering wheel
and your breast bone ⇒ fig. 52. When adjusting the proper distance to the steering wheel, grasp the
top of the steering wheel with your elbows slightly bent.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands at the
9 o'clock and 3 o'clock positions to help reduce the risk of personal injury if the driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands at other places inside
the steering wheel rim or on the steering wheel hub. Holding the steering wheel the wrong way can
cause serious injuries to the hands, arms, and head if the driver's airbag inflates.
x Adjust the steering wheel so that the steering wheel cover points at your chest and not at your
face. Pointing the steering wheel toward your face decreases the ability of the driver's airbag to help
protect you in a collision.
x Adjust the driver's seat so that you can easily push the pedals all the way to the floor while keeping
your knee(s) slightly bent.
x Adjust the seat height so that the top point of the steering wheel can be reached.
x Always keep both feet in the footwell so that you are in control of the vehicle at all times.
Passenger - front seat adjustment:
x Push the passenger seat as far back as possible in order to ensure optimum protection if the
airbag is deployed.
Applicable only in Mexico, the AGCC, and South Korea
Proper seating position

Fig. 54 The driver should never sit closer than 10 inches (25 cm) of the steering wheel.

Fig. 55 Proper safety belt positioning and head restraint adjustment.

Passenger - front seat adjustment:
x Push the passenger seat as far back as possible in order to ensure optimum protection if the
airbag is deployed.
Manual controls on the driver and passenger seat

Fig. 56 Controls on the left front seat.

Electrical controls on the driver and front passenger seats

Fig. 57 Driver seat: controls to adjust lumbar support 1, seat cushion 2, and seat backrest angle 3.

Starting the engine stops seat adjustment.
When entering and exiting the vehicle, be careful not to come into contact with any switches that
could change the seat adjustment.
Adjusting front and rear head restraints

Fig. 58 Adjusting the front head restraints.

Fig. 59 Adjusting the rear head restraints.

x The head restraint must lock securely in the position selected.
Proper head restraint adjustment
Adjust head restraints so that the upper edge of the head restraint is at least at eye level or higher.
Position the back of the head as close as possible to the head restraint.
Adjusting the head restraint for short people
Push the head restraint down as far as it will go, even if this means the person's head is still below the
top edge of the head restraint. A small gap may remain between the head restraint and the backrest
when the head restraint is all the way down.
Adjusting the head restraint for tall people
Pull the head restraint up as far as it will go.
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk
of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the
risk of neck injury in crash.
x Every person in the vehicle must have a properly adjusted head restraint to minimize the
risk of neck injury in a crash. Each head restraint must be adjusted according to the occu-
pants' size so that the upper edge is even with the top of the person's head, but no lower than
eye level. Always sit so that the back of your head is as close as possible to the head re-
straint.
x Never adjust head restraint while driving.
Removing and reinstalling head restraints

Fig. 60 Removing the front head restraints.

Fig. 61 Removing the rear head restraints.
