2013 Lexus GS300h Owner's Manual

4875-2. Using the air conditioning system and defogger
5
Interior features
GS450h_300h_OM_OM30D53E_(EE)
Using the automatic mode
Select .
Select .
The air conditioning system will
operate, and air outlets and
speed will be set automatically.
When the rear seat heaters are
set to “AUTO” mode, the sys-
tem is operated automatically
according to the set tempera-
ture, outside temperature, etc.
Select to increase the temperature and to decrease the tem-
perature.
Adjusting the temperature setting
Select .
Select (increase) or
(decrease) on the operation
screen.
The air conditioning system
switches between individual and
simultaneous modes each time
is selected.
Changing the rear seat settings (with rear air conditioning
system)
1
2
3
1
2

4885-2. Using the air conditioning system and defogger
GS450h_300h_OM_OM30D53E_(EE)
Disabling the switches on the rear armrest.
Select .
Rear seat heater switches (P.
704) are also locked.
Operates pollen removal mode
on/off.
Outside air mode switches to
(recirculated air) mode. Pol-
len is removed from the air and the
air flows to the upper part of the
body.
Usually the system will turn off
automatically after approximately
1 to 3 minutes.
Operates S-FLOW mode on/off.
When the S-FLOW mode button is
pressed, the airflow changes as fol-
lows.
Without rear air conditioning sys-
tem: Air flows to the front seats
only.
With rear air conditioning system:
Air flows to the front seats only,
and if the passenger seat is unoccu-
pied, the set temperature, outside
humidity and temperature inside
Pollen removal mode button
S-FLOW mode button

4895-2. Using the air conditioning system and defogger
5
Interior features
GS450h_300h_OM_OM30D53E_(EE)the cabin are assessed, and air
flows to the driver seat only.

4905-2. Using the air conditioning system and defogger
GS450h_300h_OM_OM30D53E_(EE)
Front center outlets and front side outlets
Direct air flow to the left or
right, up or down.
Turn the knob to open or
close the vent.
Rear seat outlets
Direct air flow to the left or
right, up or down.
Turn the knob to open or
close the vent.
Adjusting the position of and opening and closing the air out-
lets
1
2
1
2

4915-2. Using the air conditioning system and defogger
5
Interior features
GS450h_300h_OM_OM30D53E_(EE)
Registering air conditioning settings to electronic keys
Unlocking the vehicle using an electronic key and turning the power switch
to ON mode will recall that key’s registered air conditioning settings.
When the power switch is turned off, the current air conditioning settings
will automatically be registered to the electronic key that was used to
unlock the vehicle.
The system may not operate correctly if more than one electronic key is in
the vicinity or if the smart entry & start system is used to unlock a passenger
door.
Settings for the electronic key and the corresponding door can be changed.
Contact any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional.
Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after is pressed.
Humidity sensor
Fogging up of the windows
The windows will easily fog up when the humidity in the vehicle is high.
Selecting on will dehumidify the air from the outlets and defog the
windshield effectively.
If you turn off, the windows may fog up more easily. A sensor, which detects humidity inside
the vehicle and the temperature of the
windshield, is provided to detect fog on
the front windscreen. Due to the sensor,
when automatic mode is set the air condi-
tioning may make the following controls:
Changing the amount of air flow
Changing the amount of air introduced
from outside when in outside air mode
with the air vents in the position
Changing the settings of the air vents to
when the is set

4925-2. Using the air conditioning system and defogger
GS450h_300h_OM_OM30D53E_(EE)
The windows may fog up if the recirculated air mode is used.
Outside/recirculated air mode
When driving on dusty roads such as tunnels or in heavy traffic, set the out-
side/recirculated air mode button to the recirculated air mode. This is effec-
tive in preventing outside air from entering the vehicle interior. During
cooling operation, setting the recirculated air mode will also cool the vehi-
cle interior effectively.
Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.
Automatic mode for air intake control
In automatic mode, the system detects exhaust gas and other pollutants and
automatically switches between outside air and recirculated air modes.
When the dehumidification function is off, and the fan is operating, turning
automatic mode on will activate the dehumidification function.
Pollen removal mode
In order to prevent the windshield from fogging up when the outside air is
cold, the following may occur:
• Outside air mode does not switch to (recirculated air) mode.
• The dehumidification function operates.
• The operation cancels after approximately 1 minute.
In rainy weather, the windows may fog up. Press .
In extremely humid weather, the windows may fog up.
The pollens are filtered out even if the pollen removal mode is turned off.
Operation of the air conditioning system in Eco drive mode
In the Eco drive mode, the air conditioning system is controlled as follows to
prioritize fuel efficiency:
Engine speed and compressor operation controlled to restrict heating/cool-
ing capacity
Fan speed restricted when automatic mode is selected
To improve air conditioning performance, perform the following opera-
tions:
Adjust the fan speed
Turn off Eco drive mode
When the S-FLOW mode operates
If air flows to the driver’s seat only, the temperature setting for the front pas-
senger’s seat is not displayed.
When the outside temperature falls to nearly 0C (32F)

4935-2. Using the air conditioning system and defogger
5
Interior features
GS450h_300h_OM_OM30D53E_(EE)The dehumidification function may not operate even when is selected.

4945-2. Using the air conditioning system and defogger
GS450h_300h_OM_OM30D53E_(EE)
Air conditioning odors
During use, various odors from inside and outside the vehicle may enter
into and accumulate in the air conditioning system. This may then cause
odor to be emitted from the vents.
To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time
immediately after the air conditioning system is started in automatic
mode.
nanoe *1 system (if equipped)
The air conditioning system adopts nanoe generator. This helps to provide
clean air and moisture by emitting electrically charged ions coated with
water particles through the front center vent on driver’s side
*2.
When the fan is turned on and is selected, the nanoe system is acti-
vated.
When the fan is operated in the following conditions, system performance
will be maximized. If the following conditions are not met, performance
will be limited.
• The , or air outlets are being used.
• The front center vent on driver’s side is open.
When nanoe is generated, a small amount of ozone is emitted and may be
faintly smelled in some situations. However, this is approximately the same
as the amount that already exists in nature, such as in forests, and it has no
affect on the human body.
A slight noise may be heard during operation. This is not a malfunction.
*1:nanoe and the nanoe mark are trademarks of Panasonic Corporation.
*2: According to temperature and humidity conditions, fan speed and direc-
tion of the air flow, the nanoe system may not operate at full capacity.
Air conditioning filter
P. 7 7 5
Customization
Settings (e.g. exhaust gas sensor sensitivity) can be changed.
(Customizable features: P. 942)
