2013 Lexus GS300h Owner's Manual

1683-2. Opening, closing and locking the doors and trunk
GS450h_300h_OM_OM30D53E_(EE)
Wireless remote control
The wireless remote control can be used to lock and unlock the
vehicle.
Locks all the doors
Closes the windows and moon
roof (press and hold)
*
Unlocks all the doors
Opens the windows and moon
roof (press and hold)
*
Opens the trunk
(press and hold)
If the vehicle is equipped with a
power trunk lid, the trunk lid auto-
matically opens fully.
*: These settings must be customized
at any authorized Lexus dealer or
repairer, or another duly qualified
and equipped professional.
Operation signals
Doors:
The emergency flashers flash to indicate that the doors have been locked/
unlocked. (Locked: once; Unlocked: twice)
Windows and moon roof:
A buzzer sounds to indicate that the windows and moon roof are operating.
Welcome light illumination control
P. 1 4 3
Function summary
1
2
3
4
5

1693-2. Opening, closing and locking the doors and trunk
3
Operation of each component
GS450h_300h_OM_OM30D53E_(EE)
Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a
buzzer sounds continuously for 5 seconds. Fully close the door to stop the
buzzer, and lock the vehicle once more.
Security feature
P. 1 4 3
Alarm (if equipped)
Using the wireless remote control to lock the doors will set the alarm system.
(P. 97)
Conditions affecting operation
P. 1 5 0
If the wireless remote control does not operate properly
Locking and unlocking the doors and opening the trunk: Use the mechanical
key.
(P. 908)
Electronic key battery depletion
P. 1 5 4
When the electronic key battery is fully depleted
P. 7 7 7
Confirmation of the registered key number
The number of keys already registered to the vehicle can be confirmed. Ask
any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional for details.
Customization
Settings (e.g. wireless remote control system) can be changed.
(Customizable features: P. 942)

1703-2. Opening, closing and locking the doors and trunk
GS450h_300h_OM_OM30D53E_(EE)
Certification for wireless remote control
The DECLARATION of CONFORMITY (DoC) is available at the following
address:
http://www.tokai-rika.co.jp/pc/

1713-2. Opening, closing and locking the doors and trunk
3
Operation of each component
GS450h_300h_OM_OM30D53E_(EE)

1723-2. Opening, closing and locking the doors and trunk
GS450h_300h_OM_OM30D53E_(EE)The DECLARATION of CONFORMITY (DoC) is available at the following
address:

1733-2. Opening, closing and locking the doors and trunk
3
Operation of each component
GS450h_300h_OM_OM30D53E_(EE)http://www.tokai-rika.co.jp/pc/

1743-2. Opening, closing and locking the doors and trunk
GS450h_300h_OM_OM30D53E_(EE)

1753-2. Opening, closing and locking the doors and trunk
3
Operation of each component
GS450h_300h_OM_OM30D53E_(EE)The DECLARATION of CONFORMITY (DoC) is available at the following
address:
