2013 Lexus CT200h Owner's Manual (in English)

651-1. For safe use
1
CT200h_OM_OM76102E_(EE)
For safety and security
WA R N I N G
Using a child restraint system
The use of a child restraint system not suitable for the vehicle may not properly
secure the infant or child. It may result in death or serious injury (in the event
of sudden braking, sudden swerving or an accident).
Child restraint precautions
For effective protection in automobile accidents and sudden stops, a child
must be properly restrained, using a seat belt or child restraint system depend-
ing on the age and size of the child. Holding a child in your arms is not a sub-
stitute for a child restraint system. In an accident, the child can be crushed
against the windshield, or between you and the vehicle’s interior.
Lexus strongly urges the use of a proper child restraint system that conforms
to the size of the child, installed on the rear seat. According to accident statis-
tics, the child is safer when properly restrained in the rear seat than in the
front seat.
Never install a rear-facing child restraint system on the front passenger seat
when the airbag manual on-off switch is on. (P. 5 6 )
In the event of an accident, the force of the rapid inflation of the front passen-
ger airbag can cause death or serious injury to the child.
A forward-facing child restraint system may be installed on the front passen-
ger seat only when it is unavoidable. A child restraint system that requires a
top strap should not be used in the front passenger seat since there is no top
strap anchor for the front passenger seat. Adjust the seatback as upright as
possible and always move the seat as far back as possible because the front
passenger airbag could inflate with considerable speed and force. Otherwise,
the child may be killed or seriously injured.
Do not allow the child to lean his/her head or any part of his/her body against
the door or the area of the seat, front and rear pillars or roof side rails from
which the SRS side airbags or SRS curtain shield airbags deploy even if the
child is seated in the child restraint system. It is dangerous if the SRS side and
curtain shield airbags inflate, and the impact could cause death or serious
injury to the child.
Make sure you have complied with all installation instructions provided by
the child restraint manufacturer and that the system is properly secured. If it is
not secured properly, it may cause death or serious injury to the child in the
event of a sudden stop, sudden swerve or accident.

661-1. For safe use
CT200h_OM_OM76102E_(EE)
WA R N I N G
When children are in the vehicle
Do not allow children to play with the seat belt. If the seat belt becomes twisted
around a child’s neck, it may lead to choking or other serious injuries that could
result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used to
cut the belt.
When the child restraint system is not in use
Keep the child restraint system properly secured on the seat even if it is not in
use. Do not store the child restraint system unsecured in the passenger com-
partment.
If it is necessary to detach the child restraint system, remove it from the vehi-
cle or store it securely in the luggage compartment. This will prevent it from
injuring passengers in the event of a sudden stop, sudden swerve or accident.

671-1. For safe use
1
For safety and security
CT200h_OM_OM76102E_(EE)
Installing child restraints
Seat belts (An ELR belt requires a
locking clip.)
ISOFIX rigid anchors (ISOFIX
child restraint system)
Lower anchors are provided for the
outboard rear seats. (Buttons dis-
playing the location of the anchors
are attached to the seats.)
Anchor brackets (for top strap)
An anchor bracket is provided for
outboard rear seats.
Follow the child restraint system manufacturer’s instructions. Firmly
secure child restraints to the seats using a seat belt or ISOFIX rigid
anchors. Attach the top strap when installing a child restraint.

681-1. For safe use
CT200h_OM_OM76102E_(EE)
Rear facing Baby seat/child seat
Place the child restraint system
on the rear seat facing the rear
of the vehicle.
Run the seat belt through the
child restraint system and
insert the plate into the buckle.
Make sure that the belt is not
twisted. Keep the lap portion
of the belt tight.
Install a locking clip near the
tab of the lap and shoulder belt
by inserting the lap and shoul-
der webbing through the
recesses of locking clip.
Installing child restraints using a seat belt
1
2
3

691-1. For safe use
1
CT200h_OM_OM76102E_(EE)
For safety and security
Forward-facing Child seat
Adjust the head restraint to the
upmost position.
Place the child restraint system
on the seat facing the front of
the vehicle.
Run the seat belt through the
child restraint system and
insert the plate into the buckle.
Make sure that the belt is not
twisted. Keep the lap portion
of the belt tight.
Install a locking clip near the
tab of the lap and shoulder belt
by inserting the lap and shoul-
der webbing through the
recesses of locking clip.
1
2
3
4

701-1. For safe use
CT200h_OM_OM76102E_(EE)
Junior seat
Place the child restraint system
on the seat facing the front of
the vehicle.
Sit the child in the child
restraint system. Fit the seat
belt to the child restraint sys-
tem according to the manufac-
turer’s instructions and insert
the plate into the buckle. Make
sure that the belt is not twisted.
Check that the shoulder belt is
correctly positioned over the
child’s shoulder and that the lap
belt is as low as possible. (P.
40)
Press the buckle release button and
fully retract the seat belt.
1
2
Removing a child restraint installed with a seat belt

711-1. For safe use
1
CT200h_OM_OM76102E_(EE)
For safety and security
Open the fasteners on the lower
part of the seatback.
Adjust the head restraint to the
upmost position.
Check the positions of the exclu-
sive fixing bars, and install the
child restraint system to the seat.
The bars are installed in the clear-
ance between the seat cushion and
seatback.
If the child restraint has a top strap,
the top strap should be latched onto
the anchors.
Installation with ISOFIX rigid anchor (ISOFIX child restraint sys-
tem)
1
2
3

721-1. For safe use
CT200h_OM_OM76102E_(EE)
Adjust the head restraint to the
upmost position.
Secure the child restraint system
using the seat belt or ISOFIX
rigid anchors.
Open the anchor bracket cover,
latch the hook onto the anchor
bracket and tighten the top strap.
Make sure the top strap is securely
latched.
When installing a child restraint system
You need a locking clip to install the child restraint system. Follow the instruc-
tions provided by the manufacturer of the system. If your child restraint system
does not provide a locking clip, you can purchase the following item from any
authorized Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional: Locking clip for child restraint system
(Part No. 73119-22010)
Child restraint systems with a top strap
1
2
3
