2013 Lexus CT200h Owner's Manual (in English)

571-1. For safe use
1
CT200h_OM_OM76102E_(EE)
For safety and security
Insert the mechanical key into the
cylinder and rotate to the OFF posi-
tion.
The OFF indicator light turns on
(only when the power switch is in
ON mode).
“PASSENGER AIR BAG” indicator information
If any of the following problems occur, it is possible that there is a malfunction in
the system. Have the vehicle inspected by any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional.
Neither ON nor OFF comes on.
The indicator light does not change when the airbag manual on-off switch is
switched to ON or OFF.
Deactivating the airbags for the front passenger
WA R N I N G
When installing a child restraint system
For safety reasons, always install the child restraint system in a rear seat. In the
event that the rear seat cannot be used, the front seat can be used as long as the
airbag manual on-off system is set to OFF.
If the airbag manual on-off system is left on, the strong impact of the airbag
deployment (inflation) may cause serious injury or even death.
When a child restraint system is not installed on the front passenger seat
Ensure that the airbag manual on-off system is set to ON.
If it is left off, the airbag may not deploy in the event of an accident, which may
result in serious injury or even death.

581-1. For safe use
CT200h_OM_OM76102E_(EE)
Safety information for children
It is recommended that children sit in the rear seats to avoid accidental
contact with the shift lever, wiper switch etc.
Use the rear door child-protector lock or the window lock switch to
avoid children opening the door while driving or operating the power
window accidentally. (P. 136, 178)
Do not let small children operate equipment which may catch or pinch
body parts, such as the power window, hood, back door, seats etc.
Observe the following precautions when children are in the vehicle.
Use a child restraint system appropriate for the child, until the child
becomes large enough to properly wear the vehicle’s seat belt.
WA R N I N G
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There
is also a danger that children may injure themselves by playing with the win-
dows, the moon roof (if equipped) or other features of the vehicle. In addition,
heat build-up or extremely cold temperatures inside the vehicle can be fatal to
children.

591-1. For safe use
1
For safety and security
CT200h_OM_OM76102E_(EE)
Child restraint systems
Studies have shown that installing a child restraint system on a rear seat is
much safer than installing one to the front passenger seat.
Choose a child restraint system that suits your vehicle and is appropri-
ate to the age and size of the child.
For installation details, follow the instructions provided with the child
restraint system.
General installation instructions are provided in this manual. (P. 6 7 )
If child restraint system regulations exist in the country where you
reside, please contact any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional for the child restraint
system installation.
Lexus recommends that you use a child restraint system which con-
forms to the regulation ECE No.44.
Lexus strongly urges the use of child restraint systems.
Points to remember

601-1. For safe use
CT200h_OM_OM76102E_(EE)
Child restraint systems are classified into the following 5 groups accord-
ing to the regulation ECE No.44:
Group 0: Up to 10 kg (22 lb.) (0 - 9 months)
Group 0+: Up to 13 kg (28 lb.) (0 - 2 years)
Group I: 9 to 18 kg (20 to 39 lb.) (9 months - 4 years)
Group II: 15 to 25 kg (34 to 55 lb.) (4 years - 7 years)
Group III: 22 to 36 kg (49 to 79 lb.) (6 years - 12 years)
In this owner’s manual, the following popular 3 types of child restraint
systems that can be secured with the seat belts are explained.
Types of child restraints
Baby seatChild seat
Equal to Group 0 and 0+ of ECE
No.44Equal to Group 0+ and I of ECE
No.44
Junior seat
Equal to Group II and III of ECE
No.44

611-1. For safe use
1
CT200h_OM_OM76102E_(EE)
For safety and security
Information provided in the table shows your child restraint system suit-
ability for various seating positions.
Child restraint system suitability for various seating positions
Front passenger seat Rear seat
Airbag manual
on-off switch
OutboardCenter
ONOFF
0
Up to 10 kg (22
lb.)
(0 - 9 months)X
Never putU
*1
L2U
L2L1
L2
0+
Up to 13 kg (28
lb.)
(0 - 2 years)X
Never putU
*1
L2U
L2L1
L2
I
9 to 18 kg
(20 to 39 lb.)
(9 months - 4
years)Rear-
facing —
X
Never put
U
*1UL3
Forward-
facing —
UF
*1
II, III
15 to 36 kg
(34 to 79 lb.)
(4 - 12 years)UF
*1 *2U*1 *2U
L5L4
L5
Seating posi-
Mass groups

621-1. For safe use
CT200h_OM_OM76102E_(EE)
Key of letters inserted in the above table:
U: Suitable for “universal” category child restraint system approved for
the use in this mass group.
UF: Suitable for forward facing “universal” category child restraint sys-
tem approved for the use in this mass group.
L1: Suitable for “LEXUS G 0+, BABY SAFE PLUS” (0 to 13 kg [0 to
28 lb.]) approved for the use in this mass group.
L2: Suitable for “LEXUS G 0+, BABY SAFE PLUS with SEAT BELT
FIXATION, BASE PLATFORM” (0 to 13 kg [0 to 28 lb.]) approved
for the use in this mass group.
L3: Suitable for “LEXUS DUO+” (without ISOFIX, 9 to 18 kg [20 to
39 lb.]) approved for the use in this mass group.
L4: Suitable for “LEXUS KID” (15 to 36 kg [34 to 79 lb.]) approved for
the use in this mass group.
L5: Suitable for “LEXUS KIDFIX” (15 to 36 kg [34 to 79 lb.]) approved
for the use in this mass group.
X: Not suitable seat position for children in this mass group.
*1: When you use a child restraint system in this position, adjust the seat back and
fix it at the most upright lock position.
*2: When you use a child restraint system in this position, remove the head
restraint.
Other child restraint system which is different from the system mentioned
in the table can be used.
But the suitability of the systems must be carefully checked with the child
restraint system manufacturer concerned and the seller of those seats.

631-1. For safe use
1
CT200h_OM_OM76102E_(EE)
For safety and security
Information provided in the table shows your child restraint system suit-
ability for various seating positions.
Child restraint system suitability for various seating positions
(with ISOFIX rigid anchors)
Mass groupsSize classFixture
Vehicle ISOFIX
Positions
Rear outside
CarrycotFISO/L1 X
GISO/L2 X
(1) X
Group 0
Up to 10 kg (22 lb.)EISO/R1 X
(1) X
Group 0+
Up to 13 kg (28 lb.)EISO/R1 X
DISO/R2 X
CISO/R3 X
(1) X
Group I
9 to 18 kg (20 to 39 lb.)DISO/R2 X
CISO/R3 X
BISO/F2 IUF
*1
B1 ISO/F2X IUF*1
AISO/F3 IUF*1
(1) X
Group II
15 to 25 kg (34 to 55 lb.)(1) X
Group III
22 to 36 kg (49 to 79 lb.)(1) X

641-1. For safe use
CT200h_OM_OM76102E_(EE)
(1) For the CRS which do not carry the ISO/XX size class identification
(A to G), for the applicable mass group, the car manufacturer shall
indicate the vehicle specific ISOFIX child restraint system(s) rec-
ommended for each position.
Key of letters inserted in the above table:
IUF: Suitable for ISOFIX forward-facing child restraints systems of uni-
versal category approved for the use in this mass group.
X: ISOFIX position not suitable for ISOFIX child restraint systems in
this mass group and/or this size class.
*1: When you use a child restraint system in this position, remove the head
restraint.
The child restraint systems mentioned in the table may not be available
outside of the EU area.
Other child restraint systems different from the systems mentioned in the
table can be used, but the suitability of the systems must be carefully
checked with the child restraint system manufacturer and retailer.
When installing the child restraint system on the front passenger seat
When you have to use a child restraint system on the front passenger seat, adjust
the following:
Selecting an appropriate child restraint system
Use a child restraint system appropriate for the child until the child becomes
large enough to properly wear the vehicle’s seat belt.
If the child is too large for a child restraint system, sit the child on a rear seat
and use the vehicle’s seat belt. (P. 40)
The seatback to the most upright position
The seat cushion to the fully rearward
position
