2012 VOLKSWAGEN TOUAREG Owners Manual

The Electronic Stabilization Program (ESC) cannot be deactivated when the Adaptive Cruise Control is switched on. If the ESc has been deactivated and you then switch on the Adaptive Cruise Control, the ESC function will also be activated automatically.
The currently set distance and the last settings are stored automatically and assigned to the used remote control vehicle key.
When to temporarily deactivate Adaptive Cruise Control (ACC)

Fig. 275 In the instrument cluster display. Alert: Distance to vehicle ahead is too small.

brake pedal has to be hit hard and suddenly. However, this support only works as long as the brake pedal is depressed.
Front Assist cannot react when approaching standing objects ahead of you, like when driving up to a line of stopped vehicles in heavy traffic.
Operating Front Assist
Front Assist can be turned off or on in the infotainment system:
x Switch on the ignition.
x Push the infotainment button CAR.
x Tap on the Assistants button in the display.
x Select Front Assist.
x Tap on the Active button in order to switch Front Assist on or off.
If the box next to the Active button is checked =, then Front Assist is active and ready.
If Front Assist is switched off, then the message Front Assist deactivated appears in the display of the instrument cluster.
With Front Assist switched off, the advance alert and the distance alert are also deactivated.
Switching the advance alert and distance alert on and off
The advance alert and distance alert can be activated or deactivated together in the infotainment system:
x Switch on the ignition.
x Push the infotainment button CAR.
x Tap on the Assistants button in the display.
x Select Front Assist.
x Tap on the Alert button in order to switch advance alert and distance alert on or off.
If the box next to the Active button is checked =, then advance alert and distance alert are active and ready.
Volkswagen recommends to always leave the advance alert and distance alert activated.
Special driving situations
Front Assist is subject to physical and system-specified limits when driving. Under certain conditions, the reactions of the Adaptive Cruise Control may be unexpected or delayed from the driver's viewpoint

WARNING
The Forward Collision Warning system (Front Assist) technology cannot overcome the laws of physics and system-related limits. The driver is always responsible for braking in time. If the Forward Collision Warning system issues a warning, immediately apply the brake to slow the vehicle down or avoid the obstacle, depending on the traffic situation.
x Always adjust your speed and driving style to road, traffic, weather, and visibility condi-tions.
x The Forward Collision Warning system cannot prevent accidents and serious injuries on its own.
x The Forward Collision Warning system can issue unnecessary warnings in certain com-plex driving situations, for example, at traffic islands.
x The Forward Collision Warning system can issue unnecessary warnings when its function is impaired, for example, if the radar sensor is dirty or if the position of the radar sensor has been changed.
x The Forward Collision Warning system does not react to people, animals, or vehicles crossing or approaching in the same lane.
x Always be prepared to take full control of the vehicle at all times.
NOTICE
If you notice that the Forward Collision Warning system (Front Assist) doesn't work properly or the sensors are damaged, switch off the Forward Collision Warning system (Front Assist) immediately.
x Go see an authorized Volkswagen dealer or Volkswagen Service Facility for assistance and have the Forward Collision Warning system (Front Assist) checked.
If the Forward Collision Warning system (Front Assist) initiates a braking maneuver, the hydraulic braking system is under pressure. In this case the braking pedal will feel “harder” and the brake pedal travel will be shorter.
Automatic braking maneuvers can be interrupted by depressing the gas pedal or moving the steering wheel.
Deactivate the Forward Collision Warning system if it does not work as described in this chapter, for example, if multiple unwanted warnings occur. Have the system checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Temporarily switch off the Forward Collision Warning system (Front
Assist) in the following situations

x If the radar sensor malfunctions.
x If external force has affected the radar sensor, for example, after a rear-end collision.
x If the radar sensor is covered (even temporarily) by any accessories or other equipment, for exam-ple, auxiliary headlights.
x If the vehicle is being loaded onto a truck, ferry, or train.
WARNING
Failure to switch off the Forward Collision Warning system in the situations mentioned can cause accidents and serious personal injury.
Forward Collision Warning system (Front Assist) system limits

Autonomous Emergency Braking

Fig. 276 In the instrument cluster display. Warning: Distance to vehicle ahead becoming too small.

The Autonomous Emergency Braking function should be deactivated by switching off the Forward Collision Warning system (Front Assist) in following situations:
x When the vehicle is being towed.
x When the vehicle is on a roller test stand.
x When the vehicle is off road, like on construction sites or on race tracks.
x When one of the sensors is defect.
x When the sensors have been damaged, like after a frontal collision accident.
x After several false alarms in a row.
x If the sensors are covered by additional parts, like auxiliary headlights.
x If the vehicle is driving on steep terrain or on or across slopes.
WARNING
Always remember that the Autonomous Emergency Braking function has limits – it will not release you from the responsibility to control and slow down your vehicle.
x The Autonomous Emergency Braking function alone cannot avoid accidents and fatal injuries.
x Under certain circumstances and complex traffic situations the Autonomous Emergency Braking function can perform unwanted braking maneuvers, like in construction sites.
x Soiled or misaligned radar sensors can lead to unwanted braking maneuvers
x The Autonomous Emergency Braking function does not react to people, animals, crossing traffic or vehicles that are approaching you on the same lane.
x Always adjust your speed and the distance you keep between you and the vehicles ahead of you to the road, traffic, weather, and visibility conditions.
x Never follow a vehicle so closely that you cannot stop your vehicle safely, under certain circumstances the automatic braking function cannot bring the vehicle to a stop in time.
x Never allow the closing speed between you and other vehicles to be so high that the Au-tonomous Emergency Braking function may not be able to slow your vehicle safely. If closing speed is too high, you must apply the brakes yourself to reduce the risk of a rear-end crash.
x Always be prepared to takeover the control of the brake and the gas pedal in every situa-tion.
NOTICE
If you notice that the Autonomous Emergency Braking function doesn't work properly or the sensors are damaged, switch off the Forward Collision Warning system (Front Assist) and therefore the Autonomous Emergency Braking function immediately.
x Go see an authorized Volkswagen dealer or Volkswagen Service Facility for assistance and have the system checked.
If the Autonomous Emergency Braking function initiates a braking maneuver, the hydraulic brak-ing system is under pressure. In this case the braking pedal will feel “harder” and the brake pedal travel will be shorter.
Automatic braking maneuvers can be interrupted by depressing the gas pedal or moving the steering wheel.
The Autonomous Emergency Braking function can slow your vehicle down to a standstill, but not hold your vehicle permanently. When necessary, apply the vehicle brakes!

Should the Autonomous Emergency Braking function not work properly as described here and initiate several false alarms unwanted braking maneuvers in a row, temporarily deactivate the Forward Collision Warning system (Front Assist) and therefore the Autonomous Emergency Braking function. Have the system checked by an authorized Volkswagen dealer or Volkswagen Service Facility.
Special driving situations

Fig. 277
