2012 VOLKSWAGEN TOUAREG Owners Manual

Display: meaning
Unsubscribed: The station is not included in your current subscrip-
tion package or your subscription has expired.
Subscription Change: In the pop-up window, press the OK function
key to start the station update following a subscription package change.
Linking: Satellite radio reception is currently not available, such as under
trees or in an underground parking garage.
Antenna: Aerial fault. Please contact a Volkswagen dealership.

Changing station and selecting a category

Fig. 149 Station list for station selection.

The station list closes automatically after a period of inactivity.
Selecting a different station by changing the category
The currently selected category is displayed in the function key at the top right of the station list.
The order of the satellite stations and which categories are displayed can be preselected in the Ra-
dio settings
x Press the function key with the display of the current categories.
x Press a category to select it in the pop-up window.
The station list view “jumps” to the display of the selected category and plays the first station in this category.
SCAN
x Press the SIRIUS

Radio settings

Function key: Effect
Category/channel no. : In the category view arranged according to
channel number.
Delete preset list : When Delete all is pressed, all stations and channels
stored to station buttons are deleted.

Media mode: Introduction

NOTICE
x When inserting and removing CDs and DVDs, always hold them at right angles to the front of the unit. Inserting or removing them at an angle to the DVD drive may lead to scratching.
x Inserting a second CD or DVD while a CD or DVD is inserted or is being ejected can destroy the DVD drive. Always wait until the data media is completely ejected.
NOTICE
Any foreign objects attached to a data medium and non-round data media can damage the DVD drive.
x Only clean 12-cm standard CDs or DVDs should be used!
– Do not attach stickers or other items to the data medium. Stickers may peel off and damage the drive.
– Do not insert 8-cm single CDs or non-round CDs (shaped CDs) or DVDs.
– Do not insert DVD-Plus, Dual Discs and Flip Discs, as these are thicker than standard CDs.
CDs can also be played in a DVD drive if they meet the requirements
Uneven road surfaces and strong vibrations may cause CDs and DVDs being played in the DVD drive to jump.
If the temperature inside a DVD drive is too high, loading and playback of CDs and DVDs is disabled.
Data media and file requirements

Data media Conditions for playback
Audio files Video files
I Audio CDs (up to
80 min).
I Standard video DVD
and DVD-compatible DVD
audio.
I CD-ROM-, CD-R-, CD-
RW audio data CD up to
max. 700 MB (Megabyte)
in the data system ISO
9660 Level 1 and 2, Joliet
or UDF 1.02, 1.5, 2.01,
2.5.
I DVD+/-R/RW up to 4.7
GB and dual layer DVDs
up to 8.5 GB in the Joliet
file system (single-session
only); UDF.

The data medium configuration or the devices or programs used for recording can cause individual tracks or data medium to be unreadable. Information can be found on the Internet on the best ways to create audio files, video files and data media (compression rate, ID3 tag etc.).
Due to the larger quantity of data, it takes longer to read a data medium containing compressed audio files (such as MP3, WMA) than a “normal” audio CD. Complex directory structures can also the delay the reading process. If possible, only use data media with readable audio and video files.
Play lists only define a certain playback sequence. Play lists do not save any files. Play lists cannot be played if the files on the data medium are not saved in the location to which the play list is referring (relative data path). Play lists cannot be copied to the media center (HDD).
NOTICE
Do not use memory card adapters.
No liability can be accepted for damaged or lost files on the data media.
Inserting or removing data media

Fig. 150 Data media slots in glove compartment.
