2012 VOLKSWAGEN TOUAREG Owners Manual

Inserting or removing memory cards
If a memory card cannot be inserted, check the insert position and memory card.
x Insert a compatible memory card into one of the memory card slots (2) with the cutoff corner first and facing right until the card clicks into place.
x To remove, briefly press the inserted memory card. The memory card “pops” into the eject position and can be removed.
No files can be copied onto the memory card in the unit.
Data media or files cannot be read
A message will be shown if a data medium cannot be read. The data medium needs to be removed manually.
Only supported files can be displayed and played via the Audio menu. Other files are ignored.
When you browse a media source, folders containing non-supported files are also displayed, but they appear empty once opened.
Navigation data (VCards etc.) can only be read via the Directory menu
WARNING
Inserting data media when the vehicle is moving can distract you from the road and lead to accidents. Always keep the storage compartment closed when the vehicle is moving.
NOTICE
The memory card slot's locking mechanism and the memory card can be damaged by incorrect insertion of a memory card or by inserting a incompatible memory card!
x When inserting a card, make sure it is correctly positioned.
x Excessive pressure can destroy the locking mechanism in the memory card slot.
x Only use suitable memory cards
If you insert a number of different CDs and DVDs and receive the message Drive error every time, contact a qualified workshop.
Open MEDIA main menu

Fig. 151 MEDIA main menu: Audio menu.

Fig. 152 MEDIA main menu: Video DVD menu.

Response Effect
Briefly press the button M
once.
Switch tracks or chapters at the start of
the current track or chapter.
Briefly press the button M
twice.
Switch tracks or chapters at the start of
the previous track or chapter.
Briefly press the button L
once.
Switch to next track or chapter.
Press M and hold. Fast search backward.
Press L and hold. Fast search forward.
Briefly press the button N once. Playback stops. The button N changes
to b.
OR: Briefly press the button b
once.
Playback is resumed. The button b
changes to N.

Media mode (audio):

Files B on data media are often organized by means of folders  and play lists t to determine a certain playing order.
Files, folders and playlists on a data medium are sorted by name in alphanumerical order.
The illustration shows a typical audio data CD that contains tracks B, folders A and sub folders
⇒ fig. 154.
The tracks are played back as follows:
1. Tracks (1) and (2) in the CD's root directory
2. Track (3) and (4) in the first directory F1 in the root directory of the CD
3. Track (5) in the first subdirectory F1.1 of the directory F1
4. Track (6) in the first subdirectory F1.1.1 of the subdirectory F1.1
5. Track (7) in the second subdirectory F1.2 of the directory F1
6. Track (8) and (9) in the second directory F2
Play lists t are treated like directories in the playback sequence.
WARNING
Driving on today’s roads demands the full attention of the driver at all times. Driver distrac-tion causes accidents, collisions and serious personal injury!
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System, when using your mobile phone, or when operating the mobile phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your mobile phone, and the mobile phone controls only if road, traffic, and weather conditions permit and you will not be distracted from your driving.
x If you cannot use the Infotainment System, your mobile phone, or the mobile phone con-trols safely while driving, wait until later or find a safe spot where you can pull off the road and park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other warning sounds outside the vehicle.
Compressed video files (Podcasts, AVI) on a data medium are treated like audio files when played back.
Play lists are not automatically played, they must be specifically selected via the menu for track selection.
Playback of video files in the Audio menu

Track display in Audio menu

Fig. 155 MEDIA main menu: Audio menu.

Browsing audio and media sources

Fig. 156 Track list of a playing audio CD.

Fig. 157 Track list of a playing audio data CD.
