2012 VOLKSWAGEN TOUAREG Owners Manual

For your own safety and to reduce injuries in the event of sudden braking maneuvers or accidents, Volkswagen recommends the following seating positions:
Applies to all vehicle occupants:
x Adjust head restraints so that the upper edge of the head restraint is at least at eye level or higher.
Position the back of your head as close as possible to the head restraint ⇒ fig. 39 and ⇒ fig. 40.
x Push the head restraint completely down for short people, even if the top of the head is then below the upper edge of the head restraint.
x Tall people should pull the head restraint all the way up.
x Adjust the seat backrest angle to an upright position so that your back is in full contact with it when the vehicle is moving.
x Always keep both feet on the floor and in the footwell whenever the vehicle is moving.
x Always adjust and fasten safety belts properly ⇒  Safety belts.
Driver - seat and steering wheel adjustment:
x Adjust the steering wheel so that there are at least 10 inches (25 cm) between the steering wheel
and your breast bone ⇒ fig. 39. When adjusting the proper distance to the steering wheel, grasp the top of the steering wheel with your elbows slightly bent.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands at the 9 o'clock and 3 o'clock positions to help reduce the risk of personal injury if the driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands at other places inside the steering wheel rim or on the steering wheel hub. Holding the steering wheel the wrong way can cause serious injuries to the hands, arms, and head if the driver's airbag inflates.
x Adjust the steering wheel so that the steering wheel cover points at your chest and not at your face. Pointing the steering wheel toward your face decreases the ability of the driver's airbag to help protect you in a collision.
x Adjust the driver's seat so that you can easily push the pedals all the way to the floor while keeping your knee(s) slightly bent.
x Adjust the seat height so that the top point of the steering wheel can be reached.
x Always keep both feet in the footwell so that you are in control of the vehicle at all times.
Passenger - front seat adjustment:
x Push the passenger seat as far back as possible in order to ensure optimum protection if the airbag is deployed.

Electrical controls on the driver and passenger seats

Fig. 41 Driver seat: controls to adjust lumbar support A, seat cushion B, and seat back rest angle C.

WARNING
Improper use of electrical seat controls can cause serious personal injuries.
x The front seats in your vehicle can be electrically adjusted even when the vehicle key has been removed from the ignition or, on a vehicle with Keyless Access, even if there is no key in the vehicle.
x Never leave children and persons who need help in the vehicle alone because the unsu-pervised use of the electric seat adjustments can result in serious personal injury.
x Always make sure that no one is in the way while the front seats are being adjusted, or while calling up the stored memory settings for the front seats. In an emergency, stop auto-matic seat adjustment by pressing a seat adjustment switch.
NOTICE
To help prevent damage to electrical parts in the seats, do not kneel on the front seats or apply concentrated pressure to a small area of the seat or backrest.
If the vehicle battery is too weak, the electrical seat adjustment controls may not work.
When entering and exiting the vehicle, be careful not to come into contact with any switches that could change the seat adjustment.
Starting the engine stops seat adjustment.
Adjusting the front seats in the Volkswagen Information System

Fig. 42 Infotainment system: Menu seat settings for the driver and passenger seat with memory feature.

Menu seat settings for the driver and front passenger seat with memory feature

Function key: supplementary information
Driver seat remote control key : When the check box on the display screen
is activated =, the remote control vehicle key that is in use is activated for
the memory feature.
Adjust front passenger seat : After tapping the function key, the front pas-
senger seat can be adjusted using the driver seat controls.
Front passenger seat aligned to driver seat : After tapping the function key,
driver seat adjustment can be applied to the front passenger seat. To do
this, press and hold the Adjust front passenger seat function key.

WARNING
Improper use of electrical seat controls can cause serious personal injuries.
x The front seats in your vehicle can be electrically adjusted even when the vehicle key has been removed from the ignition or, on a vehicle with Keyless Access, even if there is no key in the vehicle.
x Never leave children and persons who need help in the vehicle alone because the unsu-pervised use of the electric seat adjustments can result in serious personal injury.
x Always make sure that no one is in the way while the front seats are being adjusted, or while calling up the stored memory settings for the front seats. In an emergency, stop auto-matic seat adjustment by pressing a seat adjustment switch.
NOTICE
To help prevent damage to electrical and pneumatic parts in the seats, do not kneel on the front seats or apply concentrated pressure to a small area of the seat or backrest.
If the vehicle battery is too weak, the electrical seat adjustment controls may not work.
Starting the engine stops seat adjustment.
When entering and exiting the vehicle, be careful not to come into contact with any switches that could change the seat adjustment.

Adjusting the rear seat

Fig. 43 Moving the left rear seat forwards and backwards.

Fig. 44 Adjusting angle of left rear seat backrest.

WARNING
Improper adjustment of the rear seats can cause severe personal injury.
x Adjust the rear seat only when the vehicle is stopped, since the seat could otherwise move unexpectedly when the vehicle is moving.
x Adjust the rear seat only if no one is in the way.
x Always guide the backrest down by hand and never let it fall into place on its own.
NOTICE
x Items in the luggage compartment could be damaged or cause damage when the rear seat is adjusted in the fore and aft direction.
x If the rear seat is in a forward position, items can get into the area between the seat and the luggage compartment floor. When you slide the rear seat back again, make sure that the area behind the seat is clear of objects.
Adjusting front and rear head restraints

Fig. 45 Adjusting the front head restraints.

Fig. 46 Adjusting the rear head restraints.

Removing and reinstalling head restraints

Fig. 47 Removing the front head restraints.

Fig. 48 Removing the rear head restraints.
