2012 VOLKSWAGEN TOUAREG Owners Manual

Heating and air conditioning

WARNING
Poor visibility increases the risk of collisions and other accidents that cause serious person-al injuries.
x Always make sure all windows are clear of ice, snow and condensation for good visibility to the front, sides, and rear.
x Maximum heating output and fast defrosting will only be possible after the engine has reached operating temperature. Wait until you have good visibility before driving off.
x Always make sure you know how to properly use the heating and ventilation systems as well as the rear window defroster that you will need for good visibility.
x Never use air recirculation for long periods of time. When the air conditioner is off and recirculation mode is on, condensation can quickly form on the windows and greatly reduce visibility.
x Always switch off recirculation mode when it is not needed.
WARNING
Stale air causes driver fatigue and reduces driver alertness, which can cause accidents, colli-sions and serious personal injury.
x Never switch off the fan for a long period of time and never use air recirculation a long period of time because no fresh air will come into the passenger compartment.
NOTICE
x If you think the air conditioner is not working properly or may be damaged, switch it off to help prevent more damage. Have the air conditioner checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Air conditioner repair requires specialized knowledge and special tools. Volkswagen rec-ommends that you see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
x Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation sys-tem can leave residue on the evaporator and on the dust and pollen active carbon filter, result-ing in permanent odors whenever the air conditioner is switched on.
If the air conditioner is switched off, the fresh outside air will not be dehumidified. To help keep the windows from fogging over, Volkswagen recommends leaving the air conditioner (compressor) switched on. Press the !

Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle battery has been replaced may change or delete system settings (including time, date, personal con-venience settings and programming). Check the settings and correct as necessary once the vehicle battery has built up a sufficient charge.
Climatronic controls

Fig. 301 In the front center console: Climatronic controls.

Button/Knob More information. Front Climatronic controls ⇒ fig. 301.

Defog / defrost button: The incoming outside air is directed
to the windshield, and air recirculation is automatically dis-
abled. At temperatures above +38 °F (+3 °C), the air is
dehumidified and the fan is set a to high speed so as to
defog/defrost the windshield as quickly as possible.
39.# Apply the driver settings to all climate zones ⇒ page 526.
3 Air recirculation
=
Rear window defroster: works only when the engine is run-
ning or, on hybrid vehicles, when the vehicle is ready to
drive; switches itself off after 10 minutes at the latest.
!

Operation via the Infotainment System

Fig. 302 Infotainment System: Front climate control settings.

Function
key More information. Front Climatronic controls ⇒ fig. 302.

x Press the Units feature key.
x Select the desired unit.
Automatic window fog detection
Automatic window fog detection checks whether the windows are fogged up and if necessary automat-ically adjusts the air flow to the windshield and side windows or switches on the windshield heating. If the fan or the air conditioner !

Air vents

Fig. 303 Air vents in the instrument panel.
