Park Distance Control (PDC)

NOTICE
x Things like trailer draw bars, thin rods, fences, trees, and narrow painted vertical poles or posts may not be detected by the Park Distance Control and Optical Parking System sensors and could damage the vehicle.
x If you continue driving closer to an object that the Park Distance Control and Optical Park-ing Systems have already detected and reported, the object may disappear from the sensor range and may no longer be detected. This is especially true for low or high objects. The sys-tem will no longer sound warnings about these objects. Ignoring signals from the Park Dis-tance Control system could result in serious damage to the vehicle.
x The sensors in the bumper can be damaged or become misaligned in low speed impacts and parking maneuvers. Damaged or misaligned sensors cannot accurately detect or report objects that might be within range of the PDC system
x To help make sure that the system works properly, always keep the sensors in the bumpers clean, free of snow and ice; do not cover the sensors with stickers or other objects.
x When cleaning the sensors with power washers or steam cleaners, only spray the sensors directly for a very short time, and always keep the washer nozzle at least 4 inches (10 cm) from the sensors.
x Noise from rough roads, cobblestones, other vehicles and the surrounding area, for exam-ple, can prevent the Park Distance Control system from accurately detecting and reporting people and objects that may be within range of the system sensors.
x Aftermarket components such as bicycle racks can impair the function of the Park Distance Control system.
Volkswagen recommends practicing with the Park Distance Control and the Optical Parking System in a location or parking space with no traffic in order to become familiar with the system and how it works.
Park Distance Control

Fig. 297 On the front and rear bumper: Park Distance Control system sensors.

Fig. 298 In the upper front center console: Different versions of the button for switching Park Distance Control on and off.

In order to Operation
OR: If the vehicle rolls backwards.
Automatically
deactivate
the PDC:
Drive forward faster than about 5 – 10 mph (10 – 15 km/h).
OR: Shift into Reverse R.
Switch to full-
screen view:
Vehicle rolls backwards slowly.
OR: Press the lit-up button  or ∗.
OR: Tap the /03 function key ⇒ fig. 299.

The indicator light in the button  ⇒ fig. 298 comes on and stays on as long as the feature is active.
A chime sounds to tell you that the system is on. If the chime does not sound, PDC is not working. Have the system inspected by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Special considerations when using Park Distance Control
x In some cases, the Park Distance Control system interprets water and ice on the sensors as an obstacle. To prevent automatic PDC activation in these cases, you can turn Park Distance Control off
permanently in the Infotainment System ⇒  Automatic activation in the Infotainment System.
x If the distance remains the same, the warning tone volume decreases after a few seconds. If a continuous tone sounds, its volume remains the same.
x If the vehicle moves away from the obstacle, the beeping sound stops automatically. The beep turns on once more automatically if the vehicle approaches the obstacle again.
x There is no beeping when the transmission is in Park (P) or the electronic parking brake is en-gaged.
x The volume of the audible signals can be adjusted by an authorized Volkswagen dealership or an authorized Volkswagen Service Facility.
WARNING
Never rely completely on the PDC for information about people and objects that might be in the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The PDC sensors have blind spots where they cannot detect people or objects.
x Always watch for people, especially small children and animals, because the sensors may not always be able to detect them.
If you hear a long beep lasting about 3 seconds when you first turn PDC on or the indicator light in the button starts blinking, this means there is a malfunction in the Park Distance Control system. Switch off the Park Distance Control system with the button and have it immediately checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.

Optical Parking System (OPS)

Fig. 299 OPS screen display: Small-screen display.

Fig. 300 OPS screen display: Full-screen display.

Function Proper response
Automatically activate
the OPS small-screen
display:
By approaching to within about 38 inches
(95 cm) of an obstacle at a speed of less than
about 5 - 10 mph (10 - 15 km/h).
Manually deactivate the
OPS small-screen dis-
play:
Tap the O function key ⇒ fig. 299.
Switch to full-screen
view:
Vehicle rolls backwards slowly.
OR: Press the lit-up button  or ∗.
OR: Tap the OPS function key ⇒ fig. 299.
Automatically switch on
the display:
By putting the vehicle in Reverse.
OR: Vehicle rolls backwards.
Manually switch on the
display:
Press the  or ∗ button.
Manually deactivate the
display:
Press the  or ∗ button again.
Automatically deacti-
vate the display:
Drive forward faster than about 5 - 10 mph (10 -
15 km/h).

Scanned areas
In front of the vehicle, the area in which obstacles are detected extends about 48 inches (120 cm) straight ahead and up to 24 inches (60 cm) to either side. Behind the vehicle, the area scanned area extends about 5 ft. 4 inches (160 cm) to the rear and about 2 ft. (60 cm) to either side (C) and
⇒ fig. 300 (C).
When the system is activated automatically, the acoustic signal sounds only if an object is detected in the area about 20 inches (50 cm) to the front or rear of the vehicle.
Screen display
The display shows the scanned area in several segments. The closer the vehicle gets to the obstacle,
the closer the segment advances to the displayed vehicle ⇒ fig. 299 (B) and ⇒ fig. 300 (B).
When the next-to-last segment is displayed, you have reached the collision zone. Stop the vehicle!

Distance between vehicle
and obstacle
Audible sig-
nal
Screen: Segment color
if obstacle detected
Front: about 12 – 48 inches
(31 – 120 cm) Beep tone if
manually
activated.
Yellow
Rear: about 12 – 64 inches
(31 – 160 cm)
Front: about 12 – 20 inches
(31 – 50 cm) Beep tone if
automatically
activated.
Yellow
Rear: about 12 – 20 inches (
31 – 50 cm)
About 0 – 12 inches (0 –
30 cm) front or rear
Continuous
tone. Red

The distance at which the continuous tone sounds is somewhat greater for vehicles with a factory-installed trailer hitch.
Infotainment System settings for OPS
A number of settings can be selected in the Infotainment System.
x Switch on the ignition.
x Press the CAR Infotainment button.
x Tap the Assist systems function key on the screen.
x Select Parking Distance Warning System from the list.

Function key: Actions
Front volume/tone level : Different volume and pitches can be separately
selected for front by tapping the - or + function keys or by moving the
slider.
Rear volume/tone level : Different volume and pitches can be separately
selected for rear by tapping the - or + function keys or by moving the slid-
er.
Reduced audio volume : Different volume and pitches can be separately
selected for front and rear by tapping the - or + function keys or by mov-
ing the slider.

Function key: Actions
Automatic activation of mini-OPS : If the check box in the function key is
checked =, the small screen OPS display is automatically switched on
when you slowly approach an obstacle. To switch off this feature, tap Au-
tomatic activation of mini-OPS . After deactivation, there will not be any
warning when you approach an obstacle.
Reset settings : Resets all settings to the factory settings.

When towing a trailer
On vehicles with a factory-installed trailer hitch and an electrically connected trailer, a corresponding graphic is displayed on the screen. Distance values behind the vehicles will not be displayed.
Muting the Park Distance Control volume
You can mute the PDC beeping signals by tapping the  function key on the Radio or Navigation system screen. Tap the function key again to reactivate the acoustic signals.
Muting is cancelled by switching Park Distance Control back on after it was switched off. The warning messages cannot be switched off.
If the display has been switched off manually and PDC remains active, the mute setting is also can-celled.
Switching Park Distance Control back on after it was switched off reactivates the volume. System malfunction warning signals cannot be switched off.
WARNING
Never rely completely on the OPS for information about people and objects that might be in the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The OPS sensors have blind spots where they cannot detect persons or objects.
x Never pay so much attention to the OPS and the graphics shown on the screen that you fail to notice what is going on around you.
x Always watch for people, especially small children and animals, because the sensors may not always be able to detect them.
NOTICE
Automatic activation of OPS when approaching an obstacle works only when your speed falls below a threshold of about 5 - 10 mph (10 - 15 km/h). If you then close the display, you must either switch the ignition off and back on or exceed the speed threshold and then reduce speed to under the threshold a second time in order for it to activate automatically again.
Volkswagen recommends practice parking with Park Distance Control and the Optical Parking System on a parking lot or other place where there is little traffic to get used to how the system works.
