2011 Peugeot 508 Owner's Manual

5
143
!i
Visibility

Do not cover the rain sensor, linked with
the sunshine sensor and located in the
centre of the windscreen behind the
rear view mirror.
Switch off the automatic rain sensitive
wipers when using an automatic car wash.
In winter, it is advisable to wait until
the windscreen is completely clear of
ice before activating the automatic rain
sensitive wipers.



Operating fault

If a fault occurs with the automatic rain
sensitive wipers, the wipers will operate in
intermittent mode.
Have it checked by PEUGEOT dealer or a
qualified workshop.










Special position of the
windscreen wipers
This position permits release of the windscreen
wiper blades.
It is used for cleaning or replacement of the
blades. It can also be useful, in winter, to
detach the blades from the windscreen.
In the moment following switching the ignition
off, any action on the stalk positions the wipers
ver tically on the windscreen.
To park the wipers after this has been done,
switch on the ignition and operate the stalk. To maintain the effectiveness of the "flat-
blade" wiper blades, it is advisable to:


- handle them with care,

- clean them regularly using soapy
water,

- avoid using them to retain
cardboard on the windscreen,

- replace them at the first signs of
wear.

144
i!
Visibility


1.
Front cour tesy lamp


2.
Front map reading lamp s

3.
Rear map reading lamp s

4.
Interior mood LEDs














Courtesy lamps

In this position, the cour tesy lamp
comes on gradually:

Front courtesy lamps


Take care to avoid leaving anything in
contact with the courtesy lamps.

With the "permanent lighting" mode,
the lighting time varies according to the
circumstances:


- with the ignition off, approximately
ten minutes,

- in energy economy mode,
approximately thirty seconds,

- with the engine running, unlimited.


- when the vehicle is unlocked,

- when the key is removed from the ignition,

- when opening a door,

- when the remote control locking button is
activated, in order to locate your vehicle.
It switches off gradually:


- when the vehicle is locked,

- when the ignition is switched on,

- 30 seconds after the last door is closed.
Permanently off.
Permanent lighting.


Front and rear map reading
lamps


)
With the ignition on, press the
corresponding switch.
When the front courtesy lamp is on "permanent
lighting", the rear map reading lamp comes on
as well, unless it is "permanently off ".
From the front, you can deactivate the rear map
reading lamps so as to not disturb sleeping
rear passengers, for example. However, the
rear passengers can force the illumination of
a lamp.

5
145
Visibility








Interior mood lighting
The dimmed passenger compar tment lighting improves visibility in the vehicle when the light is
poor.

Switching on

At night, interior mood light emitting diodes - LEDs
(cour tesy lamp, doors) come on automatically
when the sidelamps are switched on.


Switching off

The interior mood lighting switches off
automatically when the sidelamps are switched off.
It can be switched off manually by adjusting the
instrument panel lighting dimmer button to the
lowest setting.

146
i
Child safety











General points relating to child seats

For maximum safety, please obser ve the
following recommendations:


- in accordance with European regulations,
all children under the age of 12 or less
than one and a half metres tall must
travel in approved child seats suited to
their weight
, on seats fitted with a seat
belt or ISOFIX mountings * ,

- statistically, the safest seats in your
vehicle for carr ying children are the
rear seats,


- a child weighing less than 9 kg must
travel in the "rearwards-facing" position
both in the front and in the rear.


PEUGEOT recommends
that children
should travel in the rear seats
of your
vehicle:


-
"rearwards-facing"
up to the age of 2,

- "forwards-facing"
over the age of 2. Although one of PEUGEOT's main criteria when designing your vehicle, the safety of your children
also depends on you.

*
The rules for carrying children are specific to
each country. Refer to the current legislation
in your country.

6
147
Child safety
Child seat in the front


"Rearwards-facing"

When a "rear wards-facing" child seat is
installed on the front passenger seat
, it
is essential that the passenger airbag is
deactivated. Otherwise, the child would
risk being seriously injured or killed if the
airbag were to inflate
.


"Forwards-facing"

When a "for wards-facing" child seat is installed
on the front passenger seat
, adjust the
vehicle's seat to the intermediate longitudinal
position with the seat back upright and leave
the passenger airbag activated.


Intermediate longitudinal
position

148
i
Child safety


Passenger airbag OFF


For more information on deactivating
the airbag, refer to the "Safety" section
then "Airbags".






Child seats recommended by PEUGEOT
PEUGEOT offers a complete range of recommended child seats which are secured using a three
point seat belt
:


Group 0+: from bir th to 13 kg



Group 1: from 9 to 18 kg









L1

"RÖMER/BRITAX Baby-
Safe Plus".
Installed in the rear wards-
facing position.







L2

"RÖMER Duo Plus
ISOFIX".


Groups 2 and 3: from 15 to 36 kg









L4

"RECARO Star t''.







L5

"KLIPPAN Optima".
From the age of 6 years
(approximately 22 kg), the
booster is used on its own.

Refer to the advice given on the label present on both sides of the sun visor(s):


CAUTION


RISK OF DEATH OR SERIOUS INJURY.

DO NOT install a child seat facing rear wards on the front seat, which is fitted with an airbag.

6
149./..
Child safety














Installing child seats attached using the seat belt
In accordance with European regulations, this table indicates the options for installing child seats secured using a seat belt and universally approved (a)
in accordance with the weight of the child and the seat in the vehicle.


Weight of the child and indicative age




Seat



Under 13 kg


(groups 0 ( b
) and 0+)
Up to approx 1 year

From 9 to 18 kg


(group 1)
1 to 3 years approx

From 15 to 25 kg


(group 2)
3 to 6 years approx

From 22 to 36 kg


(group 3)
6 to 10 years approx
Front passenger seat ( c )
with height adjuster


U (R)



U (R)



U (R)



U (R)


Front passenger seat (c)

without height adjuster

U



U



U



U



Saloon


Outer rear seats

U



U



U



U


Centre rear seat

X



X



X



X




SW


Outer rear seats

U



U



U



U


Centre rear seat

X



X



X



X

150
Child safety


a:
universal child seat, child seat that can be installed in all vehicles using a seat belt.

b:
group 0, from bir th to 10 kg. Shells seats and baby carriers cannot be installed in the front passenger seat.

c:
consult the legislation in force in your country before installing your child on this seat.

U:
seat suitable for the installation of a child seat secured using a seat belt and universally approved, "rear wards-facing" and/or "forwards-facing".

U (R):
idem U
, with the vehicle's seat adjusted to the highest position and as far back as possible.

X:
seat position not suitable for installation of a child seat for the weight class indicated.
