Checks
Avoid prolonged contact of used oil or
fluids with the skin.
Most of these fluids are harmful to
health or indeed very corrosive.
Do not discard used oil or fluids into
sewers or onto the ground.
Take used oil to a PEUGEOT dealer or
a qualified workshop (France) or to an
authorised waste disposal site.










Used products


Topping up

This additive must be topped up by a
PEUGEOT dealer or a qualified workshop
without delay.











Diesel additive level
(Diesel engine with particle
emission filter)
A low additive level is indicated by illumination
of the ser vice warning lamp, accompanied
by an audible warning and a message in the
instrument panel screen.

216
i
Checks





























Checks
Unless other wise indicated, check these components in accordance with the Maintenance and Warranty Guide and according to your engine.
Other wise, have them checked by a PEUGEOT dealer or a qualified workshop.


Battery

The battery does not require any
maintenance.
However, check that the terminals
are clean and correctly tightened,
particularly in summer and winter.
When carrying out work on the battery, refer to the "Practical
information" section for details of the precautions to be taken
before disconnecting the battery and following its reconnection.

Refer to the Maintenance and
Warranty Guide for details of the
replacement inter vals for these
components.
Depending on the environment (e.g. dusty
atmosphere) and the use of the vehicle
(e.g. city driving), replace them twice as often
if necessary
(refer to the "Engines" section).
A clogged passenger compar tment filter may
have an adverse effect on the per formance
of the air conditioning system and generate
undesirable odours.

Air filter and passenger compartment filter

Replace the oil filter each time the
engine oil is changed.

Refer to the Maintenance and
Warranty Guide for details of
the replacement inter val for this
component.


Oil filter






The presence of this label, in particular with
the Stop & Star t system, indicates the use of
a specific 12 V lead-acid battery with special
technology and specification, for which the
involvement of a PEUGEOT dealer or a
qualified workshop is required when replacing
or disconnecting the battery.
Failure to obser ve this recommendation may
shor ten the life of the battery.










Particle emission filter (Diesel)

Display of this warning lamp or a specific
message, together with the ser vice warning lamp,
indicates the star t of saturation of the par ticle
filter or low level in the Diesel additive reser voir.
As soon as the traffic conditions permit,
regenerate the filter by driving at a
speed of at least 40 mph (60 km/h) until
the ser vice warning lamp goes off.
If the ser vice warning lamp stays on,
this indicates a low additive level. Have
the additive reser voir topped up and
the par ticle emission filter ser viced
by a PEUGEOT dealer or a qualified
workshop.
Following prolonged operation of the
vehicle at very low speed or at idle,
you may, in exceptional circumstances,
notice the emission of water vapour at
the exhaust on acceleration. This does
not affect the behaviour of the vehicle or
the environment.

9
217
!
Checks






Manual gearbox

The gearbox does not require any
maintenance (no oil change).
Refer to the Maintenance and Warranty
Guide for the details of the level
checking interval for this component.







6-speed electronic gearbox
system
The gearbox does not require any
maintenance (no oil change).
Refer to the Maintenance and
Warranty Guide for details of the
checking interval for this component.







Automatic gearbox

The gearbox does not require any
maintenance (no oil change).

Refer to the Maintenance and
Warranty Guide for details of the
level checking inter val for this
component. Brake wear depends on the style
of driving, par ticularly in the case
of vehicles used in town, over shor t
distances. It may be necessary to
have the condition of the brakes checked, even
between vehicle services.
Unless there is a leak in the system, a drop in
the brake fluid level indicates that the brake
pads are worn.
















Brake pads

For information on checking brake
disc wear, contact a PEUGEOT
dealer or a qualified workshop.


Brake disc wear

Manual parking brake

If a loss of effectiveness of this
system is noticed, the parking brake
must be checked, even between
two ser vices.
Checking this system must be done by a
PEUGEOT dealer or a qualified workshop.






















Electric parking brake

This system does not require any
routine servicing. However, in the
event of a problem, have the system
checked by a PEUGEOT dealer or a
qualified workshop.
For more information, see "Driving - Electric
parking brake - § Operating faults".
















Only use products recommended by
PEUGEOT or products of equivalent
quality and specification.
In order to optimise the operation
of units as impor tant as the braking
system, PEUGEOT selects and offers
very specific products.
To avoid damaging the electrical units,
the use of a high pressure washer
in the engine compar tment is strictly
prohibited
.

218
Technical data


ENGINES AND GEARBOXES



Petrol engines


1.6 litre VTi

120 hp



1.6 litre THP

15 6 hp



Gearboxes

Electronic gear control
(6 -speed)
Manual
(6 -speed)
Automatic
(6 -speed)

Model codes

8D5FH8/P - 8E5FH8/P
8D5FS8/P - 8E5FS8/P
8D5FV8 - 8E5FV8
8D5FNA - 8E5FNA
8 D5 F VA - 8 E5 F VA
Cubic capacity (cc)
1 598
1 598
Bore x stroke (mm)
77 x 85.8
77 x 85.8
Max power: EU standard (kW)
85
88
11 0
115
Max power engine speed (rpm)
6 000
6 000
Max torque: EU standard (Nm)
160
240
Max torque engine speed (rpm)
4 250
1 400
Fuel
Unleaded
Unleaded
Catalytic conver ter
yes
yes

OIL CAPACITIES (in litres)



Engine (with filter replacement)
4.25
4.25

10
219
Technical data


WEIGHTS AND TOWED LOADS (in kg)



Petrol engines


1.6 litre VTi

1
20 hp



1.6 litre THP

15 6 hp



Gearbox
es

Electronic gear control
(6 -speed)
Manual
(6 -speed)
Automatic
(6 -speed)

Model codes

8D5FH8/P - 8E5FH8/P
8D5FS8/P - 8E5FS8/P
8D5FV8 - 8E5FV8
8D5FNA - 8E5FNA
8D5FVA - 8E5FVA

Outline

Saloon
SW
Saloon
SW
Saloon
SW


- Unladen weight
1 390
1 410
1 400
1 420
1 410
1 430


- Kerb weight *

1 465
1 485
1 475
1 495
1 485
1 505


- Gross vehicle weight (GV W)
1 945
2 055
1 995
2 080
2 015
2 080


- Gross train weight (GTW)
on a 12 % gradient
3 245
3 355
3 495
3 580
3 515
3 580


- Braked trailer (within GTW limit)
on a 10 % or 12 % gradient
1 400
1 300
1 600
1 500
1 600
1 500


- Braked trailer ** (with load transfer within the
GTW limit)
1 575
1 600
1 775
1 800
1 775
1 800


- Unbraked trailer
730
74 0
735
74 5
74 0
750


- Recommended nose weight
75
75

*
The kerb weight is equal to the unladen weight + driver (75 kg).

**
The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

220
Technical data

* The kerb weight is equal to the unladen weight + driver (75 kg).

** The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

WEIGHTS AND TOWED LOADS (In kg)



Petrol engine


1.6 litre THP
160 hp



Gearbox

Manual
(6 -speed)

Model code


-

Outine

Saloon
SW


- Unladen weight
-
-


- Kerb weight *

-
-


- Gross vehicle weight (GV W)
-
-


- Gross train weight (GTW)
on a 12 % gradient
-
-


- Braked trailer (within GTW limit)
on a 10 % or 12 % gradient
-
-


- Braked trailer ** (with load transfer within the
GTW limit)
-
-


- Unbraked trailer
-
-


- Recommended nose weight
-
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

10
221
Technical data


ENGINES AND GEARBOXES



Diesel engine


1.6 litre HDi

110 h p



Gearbox
es

Manual
(5 -speed)
Electronic gear control
(6 -speed)

Model codes

8D9HL0 - 8E9HL0
8D9HR8/PS - 8E9HR8/PS

Outline

Saloon
SW
Saloon
SW
Cubic capacity (cc)
1 560
1 560
Bore x stroke (mm)
75 x 88.3
75 x 88,3
Max power: EU standard (kW)
82
82
Max power engine speed (rpm)
3 600
3 600
Max torque: EU standard (Nm)
240
270
Max torque engine speed (rpm)
1 750
1 750
Fuel

Diesel
Catalytic conver ter

yes
Particle emission filter

yes

OIL CAPACITIES (in litres)



Engine (with filter replacement)
3.25

222
Technical data


ENGINES AND GEARBOXES



Diesel engines


2.0 litre HDi
14 0 hp



2.0 litre HDi
163 hp



2.0 litre HDi




Gearboxes

Manual
(6 -speed)
Automatic
(6 -speed)
-

Model codes

8DRHR8 - 8ERHR8
8DRHF8 - 8ERHF8
8DRHHA - 8ERHHA
8DRHDA - 8ERHDA
-

Outline

Saloon
SW
Saloon
SW
Saloon
SW
Cubic capacity (cc)
1 997
1 997
-
Bore x stroke (mm)
85 x 88
85 x 88
-
Max power: EU standard (kW)
10 0
103
10 0
120
-
Max power engine speed (rpm)
4 000

3 750
-
Max torque: EU standard (Nm)
320
340
-
Max torque engine speed (rpm)
2 000
2 000
-
Fuel

Diesel
Catalytic conver ter

yes
Particle emission filter
yes
no

OIL CAPACITIES (in litres)






Engine (with filter replacement)
5.25
5
-
