EC-82
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
37
(V) 175
(B) Cooling fan speed Input [Ignition switch: ON]
 Engine stopped
5 V
[Engine is running]
 Idle speed
 After warm-up condition BATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
 Idle speed
 Before warm-up condition BATTERY VOLTAGE
(11 - 14 V)
39
(P/B) 45
(L/O) Power steering pressure sensor Input [Engine is running]
 Steering wheel: Being turned
0.5 - 4.5 V
[Engine is running]
 Steering wheel: Not being turned 0.4 - 0.8 V
40
(W/L) —Sensor ground
(Fuel rail pressure sensor/En-
gine coolant temperature sen-
sor/Engine oil temperature
sensor) —— —
42
(L/Y) 40
(W/L) Engine oil temperature sensor Input [Engine is running] 0 - 4.8 V
Output voltage varies with engine
oil temperature.
45
(L/O) —Sensor ground
(Power steering pressure sen-
sor/ Low fuel pressure sensor/
Electrically-controlled cooling
fan coupling) —— —
46
(SB) 175
(B) Fuel injector driver power supply Input [Ignition switch: ON]
BATTERY VOLTAGE
(11 - 14 V)
[Ignition switch: OFF] 1.5 V
47
(G) 175
(B) Heated oxygen sensor 2 heater
(bank 1)
Input[Engine is running]
 Engine speed: Below 3,600 rpm af-
ter the following conditions are met
- Engine: after warming up
- Keeping the engine speed between 3,500 and 4,000 rpm for 1 minute
and at idle for 1 minute under no
load 10 V
[Ignition switch: ON]
 Engine: Stopped
[Engine is running]
 Engine speed: Above 3,600 rpm BATTERY VOLTAGE
(11 - 14 V)
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ – Signal name Input/
Output
JPBIA3332ZZ
JPBIA3733ZZ
JMBIA0037GB
Revision: 2010 May2011 QX56

EC-94
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
DTC No. Detected items Engine operating condition in fail-safe mode
U0113
U1003
U1024 Can communication circuit VVEL actuator
motor relay is turned off, and VVEL value is become at a minimum angle.
Engine speed will not rise more than 3,500 rpm due to the fuel cut.
P0011
P0021 Intake valve timing control The signal is not energized to the intake valve timing control solenoid valve and the valve
control does not function.
P0087 FRP control system  Engine torque is limited.
 VVEL value is maintained at a fixed angle.
P0088 Engine speed is limited.
P008A Low fuel pressure control
system Engine torque is limited.
P0090 FRP control system  Engine torque is limited.
 VVEL value is maintained at a fixed angle.
P0102
P0103 Mass air flow sensor circuit Engine speed will not rise more than 2,400 rpm due to the fuel cut.
P0117
P0118 Engine coolant tempera-
ture sensor circuit
Engine coolant temperature will be determined by ECM based on the following condition.
CONSULT-III displays the engine coolant temperature decided by ECM.
Condition Engine coolant temperature decided
(CONSULT-III display)
Just as ignition switch is turned ON
or START 40
°C (104 °F)
Approx. 4 minutes or more after
engine starting 80
°C (176 °F)
Except as shown above 40 - 80 °C (104 - 176 °F)
(Depends on the time)
When the fail-safe system for engine coolant temperature sensor is activated, the cooling
fan operates while engine is running.
P0122
P0123
P0222
P0223
P2135 Throttle position sensor The ECM controls the electric throttle control actuator in regulating the throttle opening in
order for the idle position to be within +10 degrees.
The ECM regulates the opening speed of the throttle valve to be slower than the normal
condition.
Therefore, the acceleration will be poor.
P0190 FRP sensor  Engine speed is limited.
 High pressure fuel pump is activated at maximum discharge pressure.
P0201
P0202
P0203
P0204
P0205
P0206
P0207
P0208 Injector  Engine torque is limited.
 Fuel injection shut-off of malfunction cylinder.
 Mixture ratio feedback control does not function.
 Idle engine speed is increased.
P0500 Vehicle speed sensor The cooling fan operates (Highest) while engine is running.
P0524 Engine oil pressure The signal is not energized to the intake valve timing control solenoid valve and the valve
control does not function.
Engine speed will not rise more than 2,400 rpm due to the fuel cut.
P0605 ECM (When ECM calculation function is malfunctioning:)
ECM stops the electric throttle control actuator control, throttle valve is maintained at a
fixed opening (approx. 5 degrees) by the return spring.
ECM deactivates ASCD operation.
P0607 ECM VVEL actuator motor relay is
turned off, and VVEL value is become at a minimum angle.
Engine speed will not rise more than 3,500 rpm due to the fuel cut.
Revision: 2010 May2011 QX56

ECM
EC-97
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Priority Detected items (DTC)
1  U0101 CAN communication line  U0113 U1003 CAN communication line
 U1001 CAN communication line
 U1024 VVEL CAN communication line
 P006A P0101 P0102 P0103 Mass air flow sensor
 P010A Manifold absolute pressure sensor
 P0112 P0113 P0127 Intake air temperature sensor
 P0116 P0117 P0118 P0125 Engine coolant temperature sensor
 P0122 P0123 P0222 P0223 P1225 P1226 P2135 Throttle position sensor
 P0128 Thermostat function
 P0181 P0182 P0183 Fuel tank temperature sensor
 P0196 P0197 P0198 Engine oil temperature sensor
 P0327 P0328 P0332 P0333 Knock sensor
 P0335 Crankshaft position sensor
 P0340 P0345 Camshaft position sensor
 P0460 P0461 P0462 P0463 Fuel level sensor
 P0500 Vehicle speed sensor
 P0527 Cooling fan speed sensor
 P0605 P0607 P0611 P062B ECM
 P0643 Sensor power supply
 P0700 TCM
 P0705 P0850 Transmission range switch
 P1089 P1092 P1608 VVEL control shaft position sensor
 P1197 Out of gas*
 P1220 Fuel pump control module (FPCM)
 P1421 P1423 P1424 Cold start control
 P1550 P1551 P1552 P1553 P1554 Battery current sensor
 P1556 P1557 Battery temperature sensor
 P1606 P1607 VVEL control module
 P1610 - P1615 NATS
 P2122 P2123 P2127 P2128 P2138 Accelerator pedal position sensor
 P2539 P2541 P2542 Low fuel pressure sensor
Revision: 2010 May2011 QX56

EC-98
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
NOTE:
*: If “P1197” is displayed with other DTC in priority 1, perform trouble diagnosis for “P1197” first.
DTC IndexINFOID:0000000006217733
×
:Applicable —: Not applicable
2  P0031 P0032 P0051 P0052 Air fuel ratio (A/F) sensor 1 heater
 P0037 P0038 P0057 P0058 Heated oxygen sensor 2 heater
 P0075 P0081 Intake valve timing control solenoid valve
 P0130 P0131 P0132 P0133 P0150 P0151 P0152 P015 3 P2A00 P2A03 Air fuel ratio (A/F) sensor 1
 P0137 P0138 P0139 P0157 P0158 P0159 Heated oxygen sensor 2
 P0190 - P0193 FRP sensor
 P0441 EVAP control system purge flow monitoring
 P0443 P0444 P0445 EVAP canister purge volume control solenoid valve
 P0447 P0448 EVAP canister vent control valve
 P0451 P0452 P0453 EVAP control system pressure sensor
 P0550 Power steering pressure sensor
 P0603 ECM power supply
 P0710 P0717 P0720 P0729 P0730 P0731 P0732 P0733 P0734 P0735 P0740 P0744 P0745 P0750 P0775 P0780 P0795 P1730 P1734 P2713 P2722 P2731 P2807 A/T related sensors, solenoid valves and switches
 P1087 P1088 VVEL system
 P1090 P1093 VVEL actuator motor
 P1091 VVEL actuat or motor relay
 P1217 Engine over temperature (OVERHEAT)
 P1650 Starter motor relay 2
 P1651 Starter motor relay
 P2101 Electric throttle control function
 P2118 Throttle control motor
 P1805 Brake switch
 P2100 P2103 Throttle control motor relay
 P2101 Electric throttle control function
3  P0011 P0021 Intake valve timing control  P0087, P0088, P0090 FRP control system
 P008A Low fuel pressure control system
 P008B Low fuel pressure control system
 P0171 P0172 P0174 P0175 Fuel injection system function
 P0201 - P0208 Injector
 P0300 - P0308 Misfire
 P0420 P0430 Three way catalyst function
 P0456 EVAP control system (VERY SMALL LEAK)
 P0506 P0507 Idle speed control system
 P050E Cold start control
 P0524 Engine oil pressure
 P1148 P1168 Closed loop control
 P1212 TCS communication line
 P1421 Cold start control
 P1564 ASCD steering switch / ICC steering switch
 P1652 Starter motor system communication
 P2119 Electric throttle control actuator
 P1564 ASCD steering switch / ICC steering switch
 P1568 ICC command value
 P1572 ASCD brake switch / ICC brake switch
 P1574 ASCD vehicle speed sensor / ICC vehicle speed sensor
Priority Detected items (DTC)
DTC*1
Items
(CONSULT-III screen terms) SRT code Trip MIL
Reference
page
CONSULT-III
GST*
2ECM*3
U0101 0101 LOST COMM (TCM) — 1 ×EC-171
U0113 0113 CAN COMM CIRCUIT — 1 ×EC-173
U1001
1001*4CAN COMM CIRCUIT — 1 or 2 — EC-172
U1003 1003 CAN COMM CIRCUIT — 2 — EC-173
Revision: 2010 May2011 QX56

ECM
EC-101
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OP0327 0327 KNOCK SEN/CIRC-B1 — 2 —
EC-297
P0328 0328 KNOCK SEN/CIRC-B1 — 2 —
P0332 0332 KNOCK SEN/CIRC-B2 — 2 —
P0333 0333 KNOCK SEN/CIRC-B2 — 2 —
P0335 0335 CKP SEN/CIRCUIT — 2×EC-299
P0340 0340 CMP SEN/CIRC-B1 — 2 ×
EC-303
P0345 0345 CMP SEN/CIRC-B2 — 2 ×
P0420 0420 TW CATALYST SYS-B1 ×2 ×
EC-307
P0430 0430 TW CATALYST SYS-B2 ×2 ×
P0441 0441 EVAP PURG FLOW/MON ×2 ×EC-312
P0443 0443 PURG VOLUME CONT/V — 2 ×EC-317
P0444 0444 PURG VOLUME CONT/V — 2 ×
EC-322
P0445 0445 PURG VOLUME CONT/V — 2 ×
P0447 0447 VENT CONTROL VALVE — 2 ×EC-325
P0448 0448 VENT CONTROL VALVE — 2 ×EC-329
P0451 0451 EVAP SYS PRES SEN — 2 ×EC-333
P0452 0452 EVAP SYS PRES SEN — 2 ×EC-336
P0453 0453 EVAP SYS PRES SEN — 2 ×EC-341
P0456 0456 EVAP VERY SML LEAK
×*82 ×EC-346
P0460 0460 FUEL LEV SEN SLOSH — 2 ×EC-352
P0461 0461 FUEL LEVEL SENSOR — 2 ×EC-353
P0462 0462 FUEL LEVL SEN/CIRC — 2 ×EC-355
P0463 0463 FUEL LEVL SEN/CIRC — 2 ×EC-355
P0500 0500
VEH SPEED SEN/CIRC*5—2 ×EC-356
P0506 0506 ISC SYSTEM — 2 ×EC-358
P0507 0507 ISC SYSTEM — 2 ×EC-360
P050E 050E COLD START CONTROL — 2 ×EC-362
P0524 0524 ENGINE OIL PRESSURE — 2 ×EC-364
P0527 0527 COOLING FAN SPD SEN — 2 — EC-367
P0550 0550 PW ST P SEN/CIRC — 2 —EC-371
P0603 0603 ECM BACK UP/CIRCUIT — 2×EC-374
P0605 0605 ECM — 1 or 2 × or — EC-376
P0607 0607 ECM — 1 ×EC-378
P0611 0611 FIC MODULE — 2 ×EC-379
P062B 062B ECM — 2 × or — EC-380
P0643 0643 SENSOR POWER/CIRC — 1 ×EC-381
P0705 0705 T/M RANGE SENSOR A — 2 ×TM-106
P0710 0710
FLUID TEMP SENSOR*7—2 ×TM-107
P0717 0717 INPUT SPEED SENSOR A — 2 ×TM-109
P0720 0720
OUTPUT SPEED SENSOR*5—2 ×TM-110
P0729 0729
6GR INCORRECT RATIO*7—2 ×TM-114
P0730 0730 INCORRECT GR RATIO — 2 ×TM-116
DTC*1
Items
(CONSULT-III screen terms) SRT code Trip MIL Reference
page
CONSULT-III
GST*
2ECM*3
Revision: 2010 May2011 QX56

EC-154
< BASIC INSPECTION >[VK56VD]
FUEL PRESSURE
4. Connect fuel hose for fuel pressure check (1) to fuel tube
(engine side) with clamp (2) as shown in the figure.
CAUTION:
 Wipe off oil or dirt from hose insertion part using clothmoistened with gasoline.
 Apply proper amount of gasoli ne between top of the fuel
tube (3) and No.1 spool (4).
 Insert fuel hose for fuel pressure check until it touches the No.1 spool on fuel tube.
 Use NISSAN genuine hose clamp (part number: 16439
N4710 or 16439 40U00).
 When reconnecting fuel line, always use new clamps.
 Use a torque driver to tighten clamps.
 Install hose clamp to the position within 1 - 2 mm (0.04 - 0.08 in).
 Make sure that clamp screw does not contact adjacent parts.
5. Connect fuel tube adapter (C) to fuel feed hose (1) in the same manner as instructed in Step 4.
6. After connecting fuel hose for fuel pressure check, pull the hose with a force of approximately 98 N (10 kg,
22 lb) to confirm fuel tube does not come off.
7. Reinstall the part removed at Step 3. NOTE:
Install the part to allow smooth engine starts.
8. Turn ignition switch ON and check for fuel leakage.
9. Start engine and check for fuel leakage.
10. Read the indication of fuel pressure gauge. CAUTION:
 Do not perform fuel pressure check with system operating. Fuel pressure gauge may indicate
false readings.
 During fuel pressure check, confirm for fuel leakage from fuel connection every 3 minutes.
HIGH FUEL PRESSURE CHECK
NOTE:
Since the fuel pressure gauge kit cannot be connected, follow the method shown below to check high fuel
pressure.
WITH CONSULT-III
1. Start engine.
2. Check “FUEL PRES SEN V” in “DATA MONITOR” mode with CONSULT-III.
5 : No.2 spool
Tightening torque : 1.0 - 1.5 N·m (0.1 - 0.15 kg-m, 9 - 13 in-
lb)
A : Fuel pressure gauge
B : Fuel hose for fuel pressure check
PBIB2983E
JSBIA0491ZZ
At idling: Approximately 450 kPa (4.5 bar, 4.6 kg/cm2,
65 psi)
Revision: 2010 May2011 QX56

EC-164
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
TROUBLE DIAGNOSIS - SPECIFICATION VALUE
NOTE:
Check “A/F ALPHA-B1” and “A/F ALPHA-B2” for approxim
ately 1 minute because they may fluctuate. It is
NG if the indication is out of the SP value even a little.
Is the measurement value within the SP value?
YES >> GO TO 14.
NO-1 >> Less than the SP value: GO TO 2.
NO-2 >> More than the SP value: GO TO 3.
2.CHECK “B/FUEL SCHDL”
Select “B/FUEL SCHDL” in “SPEC” of “DATA MONITOR” mode, and check that the indication is within the SP
value.
Is the measurement value within the SP value?
YES >> GO TO 4.
NO >> More than the SP value: GO TO 16.
3.CHECK “B/FUEL SCHDL”
Select “B/FUEL SCHDL” in “SPEC” of “DATA MONITOR” mode, and check that the indication is within the SP
value.
Is the measurement value within the SP value?
YES >> GO TO 6.
NO-1 >> More than the SP value: GO TO 6.
NO-2 >> Less than the SP value: GO TO 22.
4.CHECK “A/F ALPHA-B1”, “A/F ALPHA-B2”
1. Stop the engine.
2. Disconnect PCV hose, and then plug it.
3. Start engine.
4. Select “A/F ALPHA-B1” and “A/F ALPHA-B2” in “ SPEC” of “DATA MONITOR” mode, and check that each
indication is within the SP value.
Is the measurement value within the SP value?
YES >> GO TO 5.
NO >> GO TO 6.
5.CHANGE ENGINE OIL
1. Stop the engine.
2. Change engine oil. NOTE:
This symptom may occur when a large amount of gasoline is mixed with engine oil because of driving
conditions (such as when engine oil temperature does not rise enough since a journey distance is too
short during winter). The symptom will not be detec ted after changing engine oil or changing driving con-
ditions.
>> INSPECTION END
6.PERFORM POWER BALANCE TEST
1. Perform “POWER BALANCE” in “ACTIVE TEST” mode.
2. Check that each cylinder produces a momentary engine speed drop.
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 7.
7.DETECT MALFUNCTIONING PART
Check the following below.
 Ignition coil and its circuit (Refer to EC-506, "
Component Function Check".)
 Fuel injector and its circuit (Refer to EC-498, "
Component Function Check".)
 Intake air leakage
 Low compression pressure (Refer to EM-16, "
Inspection".)
Is the inspection result normal?
Revision: 2010 May2011 QX56

EC-178
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0011, P0021 IVT CONTROL
CAUTION:
Always drive at a safe speed.
3. Check 1st trip DTC.
WITH GST
Follow the procedure “With CONSULT-III” above.
Is 1st trip DTC detected?
YES >> Go to EC-178, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217773
1.CHECK OIL PRESSURE WARNING LAMP
1. Start engine.
2. Check that oil pressure warning lamp is not illuminated.
Is oil pressure warning lamp illuminated?
YES >> Go to LU-7, "Inspection".
NO >> GO TO 2.
2.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE
Refer to EC-179, "
Component Inspection (Intake Valve Timing Control Solenoid Valve)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace malfunctioning intake valve timing control solenoid valve. Refer to EM-61, "
Exploded
View".
3.CHECK CRANKSHAFT POSITION SENSOR
Refer to EC-301, "
Component Inspection (Crankshaft Position Sensor)".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace crankshaft position sensor. Refer to EM-106, "
Exploded View".
4.CHECK CAMSHAFT POSITION SENSOR
Refer to EC-306, "
Component Inspection (Camshaft Position Sensor)".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace malfunctioning camshaft position sensor. Refer to EM-106, "
Exploded View".
5.CHECK CAMSHAFT (INTAKE)
Check the following.
Selector lever 1st or 2nd position
Driving location uphill Driving vehicle uphill
(Increased engine load will help maintain the driving
conditions required for this test.)
PBIA8559J
Revision: 2010 May2011 QX56
