2011 Citroen DS4 Owner's Manual

367


2
3
1
05 USING THE TELEPHONE


DIRECTORY


The telephone directory is sent to the system, depending on the
compatibility of the telephone.
The directory is provisional and depends on the Bluetooth
connection.

Contacts imported from the telephone to the audio system directory
are saved in a permanent directory visible to all, whatever the
telephone connected.
To modify the contacts saved in the
system, press MENU
then select
" Telephone
" and confi rm.
Select " Directory management
" and
confi rm.
You can:


- " Consult an entry
",

- " Delete an entry
",

- " Delete all entries
".


Select " Directory
" to see the list of
contacts.

Make a long press on SOURCE
for
access to the directory
or press OK
, and
select " Call
" and confi rm.

368
1
2
06
3

Press ‘
to display the audio settings
menu.

The settings available are:


- Ambience,

- Bass,

- Treble,

- Loudness,

- Distribution: Personalised or Driver * ,

- Left/right balance,

- Fader (front/rear balance),

- Auto. volume.



SCREEN C


The distribution, or spatialisation of sound, is an audio process
which allows the sound quality to be improved according to the
setting chosen, corresponding to the position of the listeners in
the vehicle.

AUDIO SETTINGS


*
According to equipment.
Select and confi rm " Other settings…
"
to display the next setting in the list.
The Ambience, Treble and Bass audio settings are different and
independent for each sound source.

369
5
63
4
07
2
1
CONFIGURATION










SETTING THE DATE AND TIME


Select the setting to be modifi ed.
Confi rm by pressing OK
, then make
the change and confi rm again to
save the modifi cation.

Using the arrows, select " Display
confi guration
" and confi rm. Press the MENU
button.



Using the arrows, select
" Personalisation-confi guration
"
and confi rm.
SCREEN C

Using the arrows, select " Date and
time adjustment
" and confi rm.

Adjust the settings one by one,
confi rming by pressing the OK

button. Next select the " OK
" tab on
the screen then confi rm to exit from
the " Date and time adjustment
"
menu.

370



08 TRIP COMPUTER


Each press of the button, located at the end of the
wiper stalk, displays the different trip computer
information in succession, depending on the screen.


- the "vehicle " tab with:


●
the range, the current fuel consumption and
the distance remaining to the destination or the
Stop & Start time counter,

- the "1" tab (trip 1) with:


●
the average speed, the average consumption
and the distance travelled calculated over
trip " 1
",

- the "2" tab (trip 2) with the same information for
a second trip.

Zero reset
When the required trip is displayed, press the control
for more than two seconds.

Range:
displays the distance which can travelled with the remaining fuel
detected in the tank, based on the average fuel consumption over the last
few miles (kilometres).
This displayed value may vary signifi cantly following a change in
the vehicle speed or the relief of the route.
When the range falls below 20 miles (30 km), dashes are displayed.
After fi lling with at least 5 litres of fuel, the range is recalculated and is
displayed when it exceeds 60 miles (100 km).
If, whilst driving, dashes are displayed continuously in place of the digits,
contact a CITROËN dealer.
A FEW DEFINITIONS

Current fuel consumption:
only calculated and displayed above 20 mph (30 km/h).

Average fuel consumption:
this is the average fuel consumption since
the last trip computer zero reset.

Distance travelled:
calculated since the last trip computer zero reset.

Distance remaining to the destination:
calculated with reference
to the fi nal destination, entered by the user. If guidance is activated,
the navigation system calculates it as a current value.

Average speed:
this is the average speed calculated since the last trip
computer zero reset (ignition on).







Stop & Start time counter
(minutes/seconds or hours/minutes)
If your vehicle is fi tted with Stop & Start, a time counter calculates
the time spent in STOP mode during a journey.
It resets to zero every time the ignition is switched on with the key.

371
09 SCREEN MENU MAP





SCREEN C


Multimedia


Media parameters

Choice of playback mode


Choice of track listing



Telephone


Call

Dial


Directory


Calls list


Voice mail box



Directory management

Consult an entry


Delete an entry


Delete all entries

Normal
Random
Random all
Repeat
By folders
By artists












MAIN FUNCTION


Option A1


Option A2


OPTION A


OPTION B

1
2
2
1
2
2
2
2
1
2
2
2
3
3
3
3
3
3
1
2
2
1

By genres
By playlists

Radio parameters
3
3
1


Telephone management

Telephone status




Hang up

1
2
1

372
09 SCREEN MENU MAP







Personalisation-
configuration

Defi ne the vehicle parameters

Access to the vehicle

Plip action
Driving position setting
Unlocking boot only

Driving assistance

Parking brake automatic
Rear wipe in reverse gear
Speeds memorised

Vehicle lighting

Directional headlamps
Daytime lights
Interior lighting

Follow-me-home headlamps
Welcome lighting

Choice of language

Display confi guration

Choice of units


Date and time adjustment


Display parameters


Brightness



Choice of sounds



Trip computer


Vehicle diagnosis *




Bluetooth connection


Connections management

Search for a device



*
The parameters vary according to the vehicle.
1
2
3
3
3
2
3
3
3
2
3
3
2
3
3
1
1
2
2
2
2
1
1
1
1

373
FREQUENTLY ASKED QUESTIONS



QUESTION



ANSWER



SOLUTION


There is a difference in
sound quality between
the different audio
sources (radio, CD…).
For optimum sound quality, the audio settings (Volume, Bass, Treble,
Ambience, Loudness) can be adapted to the different sound sources,
which may result in audible differences when changing source (radio,
CD…). Check that the audio settings (Volume, Bass,
Treble, Ambience, Loudness) are adapted to
the sources listened to. It is advisable to set
the AUDIO functions (Bass, Treble, Front-Rear
Fader, Left-Right Balance) to the middle position,
select the musical ambience "None" and set the
loudness correction to the "Active" position in CD
mode or to the "Inactive" position in radio mode.
When changing the
settings for treble and
bass, the ambience
setting is deselected.
When changing the
ambience setting, treble
and bass are reset to
zero. Choosing an ambience imposes settings for treble and bass. Modifying
one without the other is not possible. Modify the treble and bass settings or the
ambience setting to obtain the desired sound
quality.
When changing the
balance setting,
distribution is deselected. Choosing a distribution setting imposes a balance setting. Modifying one
without the other is not possible. Modify the balance setting or the distribution
setting to obtain the desired sound quality. The following tables contain answers to the most frequently asked questions.

374
FREQUENTLY ASKED QUESTIONS



QUESTION



ANSWER



SOLUTION


The quality of reception
of the radio station
listened to gradually
deteriorates or the stored
stations do not function
(no sound, 87.5 MHz is
displayed…). The vehicle is too far from the transmitter used by the station listened
to or there is no transmitter in the geographical area through which the
vehicle is travelling. Activate the RDS function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.
The environment (hills, buildings, tunnels, basement car parks…) block
reception, including in RDS mode. This phenomenon is normal and does not indicate
a failure of the audio equipment.
The aerial is absent or has been damaged (for example when going
through a car wash or into an underground car park). Have the aerial checked by a CITROËN dealer.
Sound cut-outs of 1 to
2 seconds in radio mode. During this brief sound cut-out, the RDS searches for any frequency
permitting better reception of the station. Deactivate the RDS function if the phenomenon is
too frequent and always on the same route.
The traffi c announcement
(TA) is displayed. I do
not receive any traffi c
information. The radio station does not broadcast traffi c information. Tune to a radio station which broadcasts traffi c
information.
The stored stations are
not found (no sound,
87.5 MHz is displayed…). An incorrect waveband is selected. Press the BAND button to return to the waveband
(AM, FM1, FM2, DAB * ) on which the stations are
stored.

* Digital Audio Broadcasting.
