2011 Citroen DS4 Owner's Manual

335
10
1
2
3a
3b
1
2
3
4
CONFIGURATION


Press SETUP
to display the
" Confi guration
" menu.

Select " Adjust luminosity
" and confi rm
to adjust the screen brightness.
Press " OK
" to save the changes.
The settings for day and night are
independent.

Select " Choose colour
" and confi rm to
select the screen colour harmony and
the map presentation mode:


- day mode,

- night mode,

- automatic day/night mode,
according to whether the
headlamps are on.


















SETTING THE DATE AND TIME


Select " Set date and time
" and
confi rm.

Select the setting to adjust.
Confi rm by pressing OK
, then adjust
the setting and confi rm again to save
the modifi cation.
Select " Display confi guration
" and
confi rm.
Press SETUP
to display the
" Confi guration
" menu.

Select " Display confi guration
" and
confi rm.

Adjust the settings one by one.
Then select " OK
" on the screen and
confi rm to save the settings.



DISPLAY CONFIGURATION


Select " Synchronize the minutes with GPS
" so that setting the
minutes is done automatically by satellite reception.

336
11 SCREEN MENU MAP


"Navigation - guidance"
MENU

Enter an address

Select destination


Directory

GPS coordinates (Archive)



Journey leg and route


Add a stage

Enter an address


Directory

Previous destinations



Order/delete journey legs

Divert route

Chosen destination



Guidance options


Defi ne calculation criteria

Set speech synthesis

Delete last destinations


Map management


Map orientation


Select TMC station


Automatic TMC

Manual TMC

List of TMC stations



Display/Do not display
messages








MAIN FUNCTION


option A1


option A2


OPTION A

OPTION B...


Map details

Move the map/"Vehicle monitoring"

Mapping and updating

Description of risk areas database



Stop/Restore guidance
"TRAFFIC" MENU
Geographic filter


Retain all the messages:

Retain the messages:

Around the vehicle


On the route





Set parameters for risk areas

1
2
3
1
2
2
2
1
2
2
3
3
1
1
3
3
2
2
2
2
1
3
1
1
2
2
2
2
2
2
2
2
2
2
2
1
2
1

337
11 SCREEN MENU MAP

Dial

Directory of contacts


Call

Open

Import


Phone MENU
1
2
2
2
1
2
2
2
2
1
2
3
3
3
2
2
2
1
1
1
3
3
3
2
3
2
2
31
2
2
1
1
3
3
3
3
3
3
2


List of the paired peripherals

Connect


Disconnect


Delete


Delete all


Contact mem. status



Phone functions


Ring options

Delete calls log



Bluetooth functions

Equalizer


"RADIO" MENU
Following waveband

Guidance options


Activate/Deactivate TA

Activate/Deactivate RDS



Audio settings


Peripherals search

Rename radiotelephone



Hang up


Display all phone contacts



Delete



Contacts management


New contact

Delete all contacts

Import all the entries

Synchronizing contacts

Display telephone contacts

No synchronization


Display SIM card contacts

None


Classical


Jazz


Rock


Techno


Vocal

338
11 SCREEN MENU MAP
2
3
3
1
4
2
2
1
4
4
2
2
1
1
1
2
1
1
2
2
2
2
2
2
2
3
3
2
2
2
1


Random on all media

Repetition



Audio settings (same as RADIO)


Activate/Deactivate AUX input


"MEDIA" MENU
Following media source

Eject USB support

Read mode


Normal

Random
All passengers



Le-Ri balance

Fr-Re balance

Auto. Volume



Update radio list


Bass

Treble

Loudness

Distribution

Driver

Night mode
Auto Day/Night

Adjust luminosity

Set date and time


"SETUP" MENU
Display configuration


Choose colour

Harmony


Cartography

Day mode


Voice synthesis


Guidance instructions volume

Select male voice/Select female voice

339
FREQUENTLY ASKED QUESTIONS


The following tables groups together the answers to the most frequently asked questions concerning your audio system.


QUESTION



ANSWER



SOLUTION


The route calculation is
not successful. The guidance criteria may confl ict with the current location (exclusion of
toll roads on a toll motorway). Check the guidance criteria on the Navigation
Menu, "Guidance options"\"Defi ne calculation
criteria".
The Risk area POIs do
not appear. The Risk area POIs have not been selected. Select the Risk area POIs in the list of POIs.
The Risk area POIs have not been downloaded. Download the Risk area POIs from the CITROËN
website.
The speed camera
audible warning does not
work. The audible warning is not active. Activate audible warnings in the Guidance options
menu, "Navigation - guidance", "Set parameters
for risk areas".
The system does not
suggest a detour around
an incident on the route. The guidance criteria do not take account of TMC messages. Select the "Traffi c info" function in the list of
guidance criteria.
I receive a speed camera
alert for a speed camera
which is not on my route. Other than guidance, the system announces all speed cameras
positioned in a cone located in front of the vehicle. It may provide an alert
for speed cameras located on nearby or parallel roads. Zoom in on the map to view the exact position of
the speed camera. Select "On the route" to no
longer receive alerts other than guidance or to
reduce the time for the announcement.

340
FREQUENTLY ASKED QUESTIONS



QUESTION



ANSWER



SOLUTION


Certain traffi c jams
along the route are not
indicated in real time. On starting, it is several minutes before the system begins to receive the
traffi c information. Wait until the traffi c information is being received
correctly (display of the traffi c information icons on
the map).
The fi lters are too restrictive. Modify the "Geographic fi lter" settings.
In certain countries, only major routes (motorways...) are listed for the
traffi c information. This phenomenon is normal. The system is
dependent on the traffi c information available.
The altitude is not
displayed. On starting, the initialisation of the GPS may take up to 3 minutes to
receive more than 4 satellites correctly. Wait until the system has started up completely.
Check that there is a GPS coverage of at least
4 satellites (long press on the SETUP button, then
select "GPS coverage").
Depending on the geographical environment (tunnel...) or the weather,
the conditions of reception of the GPS signal may vary. This phenomenon is normal. The system
is dependent on the GPS signal reception
conditions.
I cannot connect my
Bluetooth telephone. The telephone's Bluetooth function may be switched off or the telephone
may not be visible.

- Check that your telephone's Bluetooth
function is switched on.

- Check in the telephone settings that it is
"visible to all".
The Bluetooth telephone is not compatible with the system. A list of compatible Bluetooth mobile telephones is
available from the dealer network.
The volume of the
telephone connected
in Bluetooth mode is
inaudible. The volume depends both on the system and on the telephone. Increase the volume of the audio system,
to maximum if required, and increase the volume
of the telephone if necessary.
The ambient noise level has an infl uence on the quality of telephone
communication. Reduce the ambient noise level (close the windows,
reduce the booster fan speed, slow down, ...).

341
FREQUENTLY ASKED QUESTIONS



QUESTION



ANSWER



SOLUTION


Some contacts are
duplicated in the list. The options for synchronizing contacts are synchronizing the contacts
on the SIM card, the contacts on the telephone, or both. When both
synchronizations are selected, some contacts may be duplicated. Select "Display SIM card contacts" or "Display
telephone contacts".
Contacts are not shown
in alphabetical order. Some telephones offer display options. Depending on the settings
chosen, contacts can be transferred in a specifi c order. Modify the display setting in the telephone
directory.
The system does not
receive SMS text messages. The Bluetooth mode does not permit sending SMS text messages to the
system.
The CD is ejected
automatically or is not
played by the player. The CD is inserted upside down, is unplayable, does not contain any
audio data or contains an audio format which the player cannot play.
Le CD has been recorded in a format that is not compatible with the
player.
The CD is protected by an anti-pirating protection system which is not
recognised by the audio system.

- Check that the CD is inserted in the player the
right way up.

- Check the condition of the CD: the CD cannot
be played if it is too damaged.

- Check the content in the case of a recorded
CD: consult the advice in the "Audio" section.

- The audio system's CD player does not play
DVDs.

- Some recorded CDs will not be played by
the audio system because they are not of the
correct quality.

There is a long waiting
period following the insertion
of a CD or connection of a
USB memory stick. When a new medium is inserted, the system reads a certain amount of
data (directory, title, artist, etc.). This may take from a few seconds to a
few minutes. This phenomenon is normal.
The CD player sound is
poor. The CD used is scratched or of poor quality. Insert good quality CDs and store them in suitable
conditions.
The audio equipment settings (bass, treble, ambiences) are unsuitable. Set the treble or bass level to 0, without selecting
an ambience.

342
FREQUENTLY ASKED QUESTIONS



QUESTION



ANSWER



SOLUTION


Some characters in the
media information are not
displayed correctly while
playing. The audio system does not display some types of characters. Use standard characters to name tracks and
folders.
Playing of streaming fi les
does not start. The peripheral device connected does not support automatic play. Start the playback from the device.
The names of tracks and
the track length are not
displayed on the screen
when streaming audio. The Bluetooth profi le does not allow the transfer of this information.
The quality of reception
of the radio station
listened to gradually
deteriorates or the stored
stations do not function
(no sound, 87.5 Mhz is
displayed...). The vehicle is too far from the transmitter used by the station listened
to or there is no transmitter in the geographical area through which the
vehicle is travelling. Activate the "RDS" function by means of the
short-cut menu to enable the system to check
whether there is a more powerful transmitter in the
geographical area.
The environment (hills, buildings, tunnels, basement car parks...) block
reception, including in RDS mode. This phenomenon is normal and does not indicate
a fault with the audio system.
The aerial is absent or has been damaged (for example when going
through a car wash or into an underground car park). Have the aerial checked by a CITROËN dealer.
I cannot fi nd some radio
stations in the list of
stations received. The station is not received or its name has changed in the list.
Some radio stations send other information in place of their name
(the title of the song for example).
The system interprets this information as the name of the station.
The name of the radio
station changes.
