2011.5 Citroen DS5 HYBRID4 RHD Owner's Manual

247Technical data





Dimensions (in mm)

Identifi cation markings
A.Vehicle Identification Number (VIN) under the bonnet.This number is engraved on the bodyworknear the damper support.


The tyre pressures must be checked when the tyres are cold, at least oncea month.


If the tyre pressures are too low, thisincreases fuel consumption.
B.Vehicle identification Number (VIN) on
the windscreen lower crossmember.This number is indicated on a self-adhesive label which is visible through the windscreen.
C.Manufacturer's label. The VIN is indicated on a self-destroyinglabel affixed to the door aper ture, on the
passenger's side.
D.Tyre/paint label. This label is affixed to the centre pillar, on
the driver's side. It bears the followin
g information:


- the tyre inflation pressures with and without
load,

- the wheel rim and tyre sizes,

- the brands of tyre recommended by the manufacturer,

- the inflation pressure of the spare wheel,

- the paint colour code.
The use of snow chains is onlyauthorised on the front wheels.
The selector must be in 4WD mode.

249Technical data

011
Audio and telematics

EMERGENCY OR ASSISTANCE CALL

253














EMERGENCY OR ASSISTANCE CALL
CITROËN LOCALISED EMERGENCY CALL
In an emergency, press this button for more than 2 seconds.
Flashing of the green LED and a voice message confirm that
the call has been made to the CITROËN Emergency team * .
Pressin
g this button again immediately cancels the request. The green LEDgoes off.
A press (at any time) of more than 8 seconds on this button, cancels the request.
CITROËN LOCALISED ASSISTANCE CALL

When the ignition is switched on, the green
LED comes on for 3 seconds indicating that
the system is operating correctly.

If the oran
ge LED flashes: there is a system fault.
If the orange LED is on continuously: thebackup battery must be replaced.
In either case, contact a CITROËN dealer. Pressin
g this button again immediately cancels the request.
The cancellation is confirmed by a voice message.
Press this button
for more than 2 seconds to request assistance if the vehicle breaks down.A voice message confirms that the call has been made *
.
OPERATION OF THE SYSTEM The green LED remains on (without flashing) when communication is
established. It goes off at the end of communication.
If
you purchased your vehicle outside the CITROËN dealer network, we
invite you to have a dealer check the configuration of these ser vices and, if
desired, modified to suit your wishes. In a multi-lingual country, configuration
is possible in the official national language of your choice. This call is dealt with b
y the CITROËN Emergency team which receiveslocating information from the vehicle and can send a detailed aler t to theappropriate emergency services. In countries in which the team is not
operational, or when the locating service has been expressly declined, thecall is dealt with directly by the emergency services (112) without the vehicle location.

I
f an impact is detected by the airbag control unit, and independently of the deployment of any airbags, an emergency call is made
automatically.
*
These ser vices are sub
ject to conditions and availability.Consult a CITROËN dealer. If
you benefit from the CITROËN eTouch offer, you also have availableadditional services in your MyCITROËN personal space, via the CITROËN Internet website in your country, accessible on www.citroen.com.
For technical reasons, par ticularly to improve the quality of Telematic ser vices
to customers, the manufacturer reser ves the right to carry out updates to the
vehicle's on-board telematic system.
