2010 SUZUKI KIZASHI Owners Manual

5-86
OTHER CONTROLS AND EQUIPMENT
57L20-03E
57L51030
The glove box light stays on while the lid is
open.
Overhead Console
57L51031
Use this stowage to keep small articles.
You can open the lid (1) by pressing the
raised portion on it.
(1)
CAUTION
 Do not drive with the overhead con-
sole lid open, or the articles stowed
inside could fall down during brak-
ing, acceleration or in the event of a
collision. Always close the lid after
putting something into or taking
something out of the console.
 If you park your vehicle outdoors in
direct sunlight or in hot weather,
the overhead console can get very
hot since it is close to the roof. So,
when parking in such conditions:
– Do not leave eyeglasses in the
overhead console. The heat may
distort plastic lenses or frames.
– Do not place flammable items,
such as a lighter, in the overhead
console. The heat may cause a
fire.
 Do not apply undue force to the lid
when closing it. Doing so could
break the lid and articles inside.
 Place glasses in a case when stow-
ing them in the overhead console,
or the lenses may be damaged.

5-87OTHER CONTROLS AND EQUIPMENT
57L20-03E
Lidded Instrument Panel Box
57L51032
Use this stowage to keep small articles.
You can open the lid (1) by pressing the
raised portion on it.
Cup Holder and Storage Area
(if equipped)
57L51069
Cup holders (1) are provided in the center
console.
You can open the lid (2) by pressing the
raised portion on it.
57L51046
The cup holder (1) for rear seat passen-
gers is extended ready for use when the
armrest is tilted down and the button (2) is
pressed. Push the cup holder backward to
store it.
WARNING
Never drive with the lid of the lidded
instrument panel box open. It could
cause injury if an accident occurs.
(1)
(1)(2)
(2)
(1)

5-88
OTHER CONTROLS AND EQUIPMENT
57L20-03E
Bottle holderFront
57L50041
(1) Bottle holder
Rear
57L50042
(1) Bottle holderYou should hold a bottle with a cap in the
holder.
WARNING
Do not use the cup holder or the stor-
age bin to hold cups containing hot
liquids or sharp-edged, hard or
breakable objects. Objects in these
bins may be thrown about during a
sudden stop or impact, and could
cause personal injury.
If a drink is spilled over the audio
system (if equipped) or electric
switches, or if a spilled drink reaches
the under-floor wiring or electric
components, it could cause the sys-
tem to malfunction or even a fire, and
impair normal operation of the SRS
air bag system.
(1)(1)
WARNING
Prevent drink from spilling by cap-
ping the bottle as necessary.
If a hot drink is spilled, you may be
scalded.
If a drink is spilled over the audio
system (if equipped) or electric
switches, or if a spilled drink reaches
the under-floor wiring or electric
components, it could cause the sys-
tem to malfunction or even a fire, and
impair normal operation of the SRS
air bag system.

5-89OTHER CONTROLS AND EQUIPMENT
57L20-03E
Front Seat Back Pocket
(if equipped)
57L50043
(1) Front seat back pocket
This pocket is provided for holding light
and soft things such as gloves, newspa-
pers or magazines.
Footrest
57L51033
Use the footrest (1) as a support for your
left foot.
Center Console BoxUse this stowage for keeping small arti-
cles.
The box consists of upper and lower com-
partments. The upper compartment forms
a tray, which also serves as a lid of the
lower compartment.Upper compartmentOpen the upper compartment by raising
the top lid (2) while keeping the lever (1)
up.
57L50045
WARNING
Do not put hard or breakable objects
in the pocket. If an accident occurs,
objects such as bottles, cans, etc.
can injure the occupants in the rear
seat.
(1)
(1)
(2)
(1)

5-90
OTHER CONTROLS AND EQUIPMENT
57L20-03E
Lower compartmentOpen the lower compartment by raising
the top lid and tray (4) together while keep-
ing the lever (3) up.
57L51035
NOTE:
 Always close the lid after you put some-
thing into or take something out of the
box.
 The upper compartment (tray) and lower
compartment have slots on their edges
so that the cable of an appliance con-
nected to the accessory socket can be
led through them. When the top lid or the
top lid and tray combination is raised or
lowered to open or close the upper or
lower compartment, be careful not to
trap a cable under it.
ArmrestFront
57L50069
The lid of the center console box serves as
the front armrest when it is closed.
Rear
57L51047
The armrest (1) is stowed in the center of
the seatback. Tilt it down forward to use.
57L50070
(4)
(3)
(1)
(1)
WARNING
 The seat belt must always be
passed under the armrest. It cannot
provide the intended protection if it
runs over the armrest.
 In an accident or sudden stop, the
rear armrest could fall forward. If
there is a child in a rearfacing child
restraint in the center seating posi-
tion, the falling armrest could injure
the child. Make sure the armrest is
secured in the stowed position
when not in use.
(1)
(2)

5-91OTHER CONTROLS AND EQUIPMENT
57L20-03E
NOTE:
There is a lid (1) behind the armrest stow-
age in the seatback.
 When carrying a long cargo, the lid (1)
can be opened by folding it forward while
keeping the lever (2) pressed down.
 When closing the lid (1), raise and push
it into position.
Floor Mats (if equipped)
57L51063
(1) UNLOCK
(2) LOCK
Both driver-side and passenger-side floor
mats are retained with fasteners to prevent
them from sliding forward and possibly
interfering with the pedals. Whenever you
put the mats back after removing them,
correctly position and secure the mats by
passing the fastener knob through each
hole in the mats and turning it to the lock
position as shown in the illustration so that
the mats will neatly fit under your feet and
the passenger’s feet.
When you replace the floor mats in your
vehicle with a different type such as all-
weather floor mats, we highly recommend
using genuine SUZUKI floor mats for
proper fitting.
(1)
(2)
WARNING
Failure to take the following precau-
tions may result in the driver’s side
floor mat interfering with the pedals
and causing a loss of vehicle control
or an accident.
 Make sure that all fastener knobs
are in their holes in the floor mats
and correctly locked.
 Never place additional floor mats
on top of the existing floor mats.

5-92
OTHER CONTROLS AND EQUIPMENT
57L20-03E
Luggage Under-boxUse this stowage for carrying small bag-
gage or the like.
 To access the stowage, raise the floor-
board by holding the handle (1) on it and
hang the hook (2) on the edge of the
trunk.
57L51050
Net/Rope Hooks
57L50049
There are two net hooks (1), one on each
of the trunk opening sides.
There are four rope hooks (2) provided on
the trunk floor.
Pull out these hooks to use as shown in
the illustration.
An optional rubber net can be hooked to
these hooks to help keep cargo from mov-
ing around in the luggage compartment
during normal driving.
Roof Rack Anchors (if
equipped)
80J082
You can use the roof rack anchors to
attach the optional roof rack which is avail-
able at your SUZUKI dealer. If you use a
roof rack, observe the instructions and pre-
cautions in this section and provided with
the roof rack.
 Make sure the roof rack is securely
installed.
 To mount various types of cargo (such
as skis, bicycles, etc.) properly, use suit-
able attachments which are available
from your SUZUKI dealer. Be sure to
install the attachments properly and
securely according to the instructions
provided. Do not mount cargo directly on
the roof panel. The cargo can damage
the roof panel.
(1) (2)
(2)
CAUTION
Use the net and rope hooks only for
holding light objects.
(2) (1)

5-93OTHER CONTROLS AND EQUIPMENT
57L20-03E
 The gross weight of the roof rack plus
cargo must not exceed the loading
capacity (50 kg (110 lbs)). Also, do not
let the gross vehicle weight (fully loaded
vehicle including driver, passengers,
cargo, roof load and trailer tongue
weight) exceed the Gross Vehicle
Weight Rating (GVWR) listed in the
driver’s door lock pillar.
 Mount and secure the cargo onto the
roof rack properly according to the
instructions provided. Be sure to stow
the heaviest items at the bottom and dis-
tribute the cargo as evenly as possible.
 Do not carry items so large that they
hang over the bumpers or the sides of
the vehicle, or block your view.
 Secure the front and rear ends of long
items – such as wood panels, surfboards
and so forth – to both the front and rear
of the vehicle. You should protect the
painted surfaces of the vehicle from
scuffing caused by tie-down ropes.
 Check periodically to make sure the roof
rack is securely installed and free from
damage.
 For vehicles with roof rack anchors,
make sure the anchors are covered with
the caps when not in use.
HomeLink
® (if equipped)
66J092
HomeLink
®: HomeLink
® is a registered
trademark of Johnson Controls Technology
Company.
The HomeLink
® Wireless Control System
provides a convenient way to replace up to
three hand-held radio-frequency (RF)
transmitters used to activate devices such
as gate operators, garage door openers,
entry door locks, security systems, even
home lighting. Additional HomeLink
® infor-
mation can be found on the Internet at
www.homelink.com
or by calling 1-800-
355-3515.
Before programming HomeLink
® to a
garage door opener or gate operator, make
sure that people and objects are out of the
way of the device to prevent potential harm
or damage. When programming a garage
door opener, it is advised to park outside of
the garage. Do not use HomeLink® with
any garage door opener that lacks safety
stop and reverse features as required by
U.S. federal safety standards (this includes
WARNING
 Abrupt maneuvers or failure to
properly secure cargo can allow the
cargo to fly off the vehicle and hit
others, causing personal injury or
property damage.
 Mount cargo securely and avoid
abrupt maneuvers such as “jack-
rabbit” starts, sharp turns, fast cor-
nering and sudden braking. Check
periodically to make sure that
cargo is securely fastened.
 Large, bulky, long, or flat items can
affect vehicle aerodynamics or be
caught by the wind, and can reduce
vehicle control resulting in an acci-
dent and personal injury. Drive cau-
tiously at a safely reduced speed
when carrying this type of cargo.
